3 TARGET PROGRAM AND DEBUGGING

3 Target Program and Debugging
This chapter describes precautions for debugging using the debug monitor.

3.1 Notes for Creating Target Programs

Follow the instructions below when creating the target program to be debugged:
Since the debug monitor uses the debugging exception of the CPU, addresses 0x0 to 0xF of the built-in RAM area
are used as the vector and stack for processing debugging exceptions. Therefore, the target program cannot use this
area. Furthermore, do not use addresses 0x10 to 0x2F.
Wh e n d eb ug gi ng t he t ar g e t p ro gr a m b y wr i ti ng i n t he RA M o r Fl as h me mor y o n t he t ar g e t b oa r d, ma p t he
program to that address.
Th e d eb ug mo ni to r d oe s n ot a ll ow f or c e d b re a k f un c ti on s s uc h a s k ey b re a k s. Fo rc e d b re a k f un c ti on s s ho ul d b e
ma de i n t he t ar g e t p ro gr a m u si ng a k ey i np ut i nt er r u pt o r a n NMI i np ut . Se tt in g a h ar d wa r e PC b re a k i n t he
interrupt processing routine makes it possible to execute a forced break.

3.2 Parameter File for Debugging

A debug-parameter file is required to start the debugger. Create the file according to the memory configuration of
the target system. When using the debug monitor, the debugger ignores all the settings for the ICE emulation
memory.
When using a Flash memory, specify it as a RAM.
Example: "dmt33004\sample\33104_m.par"
CHIP 33104
IROM 1000
FOPT 0000
PRC VER 00 ff
PRC STATUS ****************
MPU
VER 1
; Emulation memory allocation (max 8 areas, 1MB/area, 1MB boundary)
EMROM c00000 cfffff
; Map allocation (max 31 areas, 256bytes boundary)
RAM 0 7FF
IO 40000 4ffff
RAM 200000 2fffff
RAM 600000 6fffff
EROM c00000 cfffff
; Stack area except internal RAM area (max 8 areas, 256bytes boundary)
STACK 600000 6fffff
END
10
; chip name (33XXX)
; internal ROM is 80000 to 80FFF
; f option size
; allow any PRC board
; allow any PRC board status
; 0xC00000 external boot address
; this file version
; external ROM 1MB
; internal RAM area 2KB
; internal IO area 64KB
; external FLASH 1MB
; external SRAM 1MB
; external ROM 1MB
; external stack area 1MB
EPSON
S1C33 FAMILY DEBUG MONITOR
OPERATION MANUAL
