EPSON Endeavor L
SVGA pass-through interface built into
SVGA feature
connector
main system board; 26-pin connector
One standard 8-bit parallel uni- or
Parallel
bi-directional interface built into main
system board; I/O address selectable
through SETUP; 25-pin, D-shell connector
Serial
Two RS-232C, programmable,
asynchronous interfaces built into main
system board; 9-pin, D-shell connectors
Keyboard
PS/2 compatible keyboard interface built
into main system board; 6-pin, mini DIN
connector
Mouse
PS/2 compatible mouse interface built into
main system board; 6-pin mini DIN
connector
Option slots
Four 16-bit (or 8-bit) I/O expansion slots,
ISA compatible, 8.33 MHz bus speed; three
slots accommodate any size card, bottom
slot can hold a half size card
Speaker
Internal, piezo-electric speaker on main
board
Mass storage
Internal mounts:
One 3!4-inch wide, half-height
Externally accessible mounts:
Two 5.25-inch wide, half-height
Diskette drives
3.5-inch
storage capacity
5.25-inch diskette drive, 360KB or 1.2MB
storage capacity
Combination diskette drive; 3.5-inch,
1.44MB and 5.25-inch, 1.2MB
Hard disk
drives
to half-height size; the first mounted in the
vertical internal bay and the second
mounted in an externally accessible,
horizontal bay
Other devices
Half-height tape drive, CD-ROM drive,
optical drive, or other storage device;
Detachable, two-position height; 101 or
102 sculpted keys; country-dependent
main typewriter keyboard; numeric/
cursor control keypad; four-key cursor
control keypad; 12 function keys
Stored in ROM; accessible by pressing the
Delete
key at the SETUP prompt during
P r o g r a m
boot
EPSON Endeavor L - 2
diskette drive, 720KB or 1.44MB
with mounting frames
or
System security Password (up to 8 characters) defined in
SETUP for system boot and keyboard
unlock; definable hot key combination
locks the keyboard and mouse
Virus protection Write protection feature for boot sector of
the hard disk drive
Width
14.8 inches (370
16.5 inches (412
Depth
Height
4.8 inches (120
16.7 lb (7.5 kg), with one diskette drive and
weight
one hard disk, but without keyboard
85 Watt, Autosensing, UL listed, fan-cooled
Type
Input ranges
100V to 125V
200V to 240v
Maximum
+5
VDC at 11 Amps, -5 VDC at 0.3 Amp,
+12 VDC at 2.0 Amps, -12 VDC at 0.3 Amp
outputs
Frequency
50/60Hz
Cables
Two to main system board; four to mass
storage devices
Maximum current
+5 Volts
slot
For each
7 Amps
For all slots*
11 Amps
Condition
range
Temperature
41° to 90° F
(5° to 32° C)
Humidity (non
20% to 90%
condensing)
-330 to 9,900 ft
Altitude
(-100 to 3,000 m) (-100 to 12,000 m) (-100
Maximum wet
68° F (20° C)
bulb
Acoustical noise
37.5 dB
mm)
mm)
mm)
+12 Volts
-12 volts
-5 volts
1.5 Amps
0.3 Amp
0.3 Amp
0.3 Amp
0.3 Amp
2 Amps
Storage range
range
-4° to 140° F
-4° to 140° F
(-20° to 60°C)
(-20° to 60° C)
1O% to 90%
1O% to 90%
-330 to 39,600 ft
-330 to 39,600 ft
to
12,000 m)
104° F (40° C)
134° F (57° C)
N/A
N/A
