Epic EPTL09106.0 User Manual

Epic fitness user's manual treadmill eptl09106.0
Hide thumbs
Table of Contents

Advertisement

Quick Links

Model No. EPTL09106.0
USER'S MANUAL
Serial No.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-866-997-6999
Mon.–Fri., 6 a.m.–6 p.m. MST
ON THE WEB:
www.iconservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EPTL09106.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Epic EPTL09106.0

Summary of Contents for Epic EPTL09106.0

  • Page 1 Model No. EPTL09106.0 USER'S MANUAL Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if parts are damaged or missing, PLEASE CONTACT OUR CUSTOMER SERVICE DEPARTMENT DIRECTLY.

  • Page 2: Table Of Contents

    HOW TO FOLD AND MOVE THE TREADMILL ........

  • Page 3: Important Precautions

    2. Use the treadmill only as described. 3. Place the treadmill on a level surface, with at least eight feet of clearance behind it and two feet on each side. Do not place the treadmill on any surface that blocks air openings.
  • Page 4 AND MOVE THE TREADMILL on page 24.) You must be able to safely lift 45 pounds (20 kg) to raise, lower, or move the treadmill. 21. When folding or moving the treadmill, make sure that the storage latch is fully closed.
  • Page 5 SAVE THESE INSTRUCTIONS The decals shown here have been placed on the treadmill. If a decal is missing, or if it is not legible, call the toll-free tele- phone number on the front cover of this manual and order a free replacement decal.

  • Page 6: Before You Begin

    To help us assist you, note the product model number and serial number before calling. The model number of the treadmill is EPTL09106.0. The serial number can be found on a decal attached to the tread- mill (see the front cover of this manual for the location).

  • Page 7: Assembly

    During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. This is a normal condition and does not affect treadmill perfor- mance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
  • Page 8 2. With the help of a second person, carefully raise the Uprights (84) to a vertical position. Have the second person hold the console assembly near the Uprights (84) as shown. Look under the console as- sembly and locate the Console Wire Harness (78). Cut the plastic ties securing the Upright Wire Harness (77) to the right Upright (84).
  • Page 9 6. Place the treadmill in the storage position (see HOW TO FOLD AND MOVE THE TREADMILL on page 24). Next, place the cylinder end of the Gas Spring (92) near the bracket on the base of the Uprights (84).
  • Page 10 75 ohm antenna terminal (see page 11). 9. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of clear plastic on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the tread- mill.
  • Page 11 Before the personal television can be used, you must connect an antenna, a 75 ohm CATV cable, or a VCR to the 75 ohm antenna terminal on the treadmill frame. Note: No antenna, cable, or adapter is included. HOW TO CONNECT AN ANTENNA Indoor Antenna 1.

  • Page 12: Operation And Adjustment

    Failure to use a properly functioning surge suppressor could result in damage to the control system of the treadmill. If the control system is damaged, the walking belt may change speed, accelerate or stop unexpect- edly, which may result in a fall and serious injury.

  • Page 13: Features Of The Console

    In addition, the console offers eight preset programs. Each program automatically controls the speed and in- cline of the treadmill as it guides you through an effec- tive workout. You can even create custom workout pro- grams and store them in memory for future use.

  • Page 14: How To Turn On The Power

    Next, stand on the foot rails of the treadmill. Find the clip attached to the key (see the drawing on page 13) and attach the clip securely to the waistband of your clothes.
  • Page 15 Step onto the foot rails, press the Stop button, and adjust the incline of the treadmill to the lowest setting. The incline must be at the lowest setting when the treadmill is folded to the storage posi- tion or the treadmill will become damaged.

  • Page 16: How To Use A Preset Program

    If the speed and/or in- cline of the treadmill is about to change, the speed setting and/or the incline setting will flash in the right display to alert you.
  • Page 17 When the program ends, make sure that the in- cline of the treadmill is at the lowest setting. Next, remove the key from the console and put it in a secure place. Note: If the displays and various indicators remain lit after the key is removed, the console is in the “demo”...

  • Page 18: How To Use A Heart Rate Program

    HOW TO USE A HEART RATE PROGRAM During heart rate program 9, your heart rate will reach approximately 85% of your age-predicted maximum heart rate. (Note: Your age-predicted maximum heart rate is calculated by subtracting your age from 220. For example, if you are 30 years old, your age-pre- dicted maximum heart rate is 190 beats per minute).
  • Page 19 Speed or Incline buttons. However, when the console compares your heart rate to the target heart rate setting, the speed of the treadmill may automatically change to bring your heart rate closer to the target heart rate setting.

  • Page 20: How To Create A Custom Program

    Speed and Incline buttons. Every few times a Speed but- ton is pressed, an additional indicator will appear or disappear in the Current Segment column.

  • Page 21: How To Use A Custom Program

    The speed setting for the second segment will then be shown in the flashing Current Segment column and the treadmill will automatically adjust to the second speed and incline settings that you pro- grammed previously.
  • Page 22 IMPORTANT: If the letter “d” appears in the right display, the “demo” mode is selected. This mode is intended to be used only when a treadmill is displayed in a store. When the demo mode is se- lected, the power cord can be plugged in, the key...
  • Page 23 Note: The setting that you select will not appear on the screen. If you have connected an antenna to the treadmill, the Air setting should be selected. If you have connected a CATV cable, one of the three Cable settings should be selected; try all three Cable settings, if necessary, to find the best setting.

  • Page 24: How To Fold And Move The Treadmill

    1. Hold the upper ends of the handrails. Place one foot against one of the wheels. 2. Tilt the treadmill back until it rolls freely on the front wheels. Carefully move the treadmill to the desired location. To re- duce the risk of injury, use extreme caution while mov- ing the treadmill.
  • Page 25 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand. Pull the latch knob to the left and hold it. Pivot the frame down until the catch is past the latch pin.

  • Page 26: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 27 1/2 of a turn. Be careful not to overtighten the walking belt. Then, plug in the power cord, insert the key, and run the treadmill for a few minutes. Repeat until the walking belt is centered. b. If the walking belt slips when walked on, first re- move the key and UNPLUG THE POWER CORD.
  • Page 28 • Blue Screen—If the treadmill is located in the fringe area of a television station where the signal is weak, the picture may be of poor quality or a blue screen may appear. If the signal is weak, it may be necessary to install an external antenna to improve the picture.

  • Page 29: Conditioning Guidelines

    For maximum fat burning, adjust the speed and incline of the treadmill until your heart rate is near the middle number in your training zone. Aerobic Exercise If your goal is to strengthen your cardiovascular sys- tem, your exercise must be “aerobic.”...

  • Page 30: Suggested Stretches

    SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 31: Part List

    PART LIST—Model No. EPTL09106.0 To locate the parts listed below, see the EXPLODED DRAWING attached in the center of this manual. Key No. Qty. Description Isolator Decal 3/4” Tek Screw Screw Catch Foot Rail Screw Front Isolator Isolator Washer Star Washer...

  • Page 34: Ordering Replacement Parts

    To order replacement parts, see the front cover of this manual. To help us assist you, please be prepared to give the following information: • the MODEL NUMBER of the product (EPTL09106.0) • the NAME of the product (EPIC 475 MX treadmill) •...

This manual is also suitable for:

475 mxEptl09106.2
