Epic 800mx Treadmill User Manual

English manual
Hide thumbs

Advertisement

Table of Contents

Model No. EPTL15605.0
USER'S MANUAL
Serial No.
Write the serial number in the space
above for future reference.
Serial Number Decal
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
Customer Hot Line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-866-997-6999
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this man-
ual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 800mx Treadmill and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Epic 800mx Treadmill

Summary of Contents for Epic 800mx Treadmill

  • Page 1 Model No. EPTL15605.0 USER'S MANUAL Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? If you have questions, or if there are missing parts, we will guar- antee complete satisfaction through direct assistance from our factory.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 BEFORE YOU BEGIN .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure trol system of the treadmill. If the control sys- that all users of this treadmill are adequately tem is damaged, the walking belt may change informed of all warnings and precautions.
  • Page 4 21. Inspect and properly tighten all parts of the motor hood unless instructed to do so by an treadmill every three months. authorized service representative. Servicing other than the procedures in this manual 22. Never drop or insert any object into any open- should be performed by an authorized service ing.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Congratulations for purchasing the EPIC 800 MX manual. To help us assist you, note the product model treadmill. The 800 MX treadmill offers an impressive number and serial number before contacting us. The array of features to help you achieve your fitness goals model number of the treadmill is EPTL15605.0.

  • Page 6: Assembly

    ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton.
  • Page 7 2. Slide the Right Upright (95) fully onto the bracket on the Base (99). Be careful to avoid pinching your hands or the Upright Wire Harness (108). Attach the Right Upright (95) with four Upright Bolts (86) and two 3/8” Star Washers (88) as shown. If necessary, adjust the position of the Right Upright to align the Upright Bolts with the holes.
  • Page 8 5. While pressing down on the Handrails (87), tighten eight Upright Bolts (86) and four 3/8” Star Washers (88) into the Uprights (90, 95) and the Handrail (87) as shown. Be careful to avoid pinching the Upright Wire Harness (108). Note: The CD Holder (38) and the Cup Holder (43) are replaceable.

  • Page 9: Treadmill Operation

    TREADMILL OPERATION THE PRE-LUBRICATED WALKING BELT tric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding Your treadmill features a walking belt coated with high- plug. Plug the power cord into a surge suppressor, performance lubricant.
  • Page 10 Clip FEATURES OF THE CONSOLE HOW TO TURN ON THE POWER Note: If there is a sheet of clear plastic on the con- The treadmill console offers an impressive array of sole, remove the plastic. To prevent damage to the features designed to make your workouts more effec- tive.
  • Page 11 When you set either one goal or two goals, the HOW TO USE THE MANUAL MODE console will display the length of time you will ex- ercise, the distance that you will walk or run, the approximate number of calories you will burn, and Insert the key into the console.
  • Page 12 set, the display will show the number of calories Follow your progress with the matrix and the still to be burned during your workout. Note: When displays. a preset program or a custom program is selected, the display will show the number of calories still to The matrix—When the be burned during the program.
  • Page 13 your pulse is detected, two dashes (– –) will ap- Measure your heart rate if desired. pear in the Pulse display, and then your heart rate will be shown. For the most accurate heart rate You can measure your heart rate using either the reading, continue to hold the contacts for handgrip pulse sensor or the optional chest pulse about 15 seconds.
  • Page 14 Press the Start button to start the program. HOW TO USE A PRESET PROGRAM A moment after the button is pressed, the tread- Insert the key into the console. mill will automatically adjust to the first speed and incline settings of the program. Hold the handrails See HOW TO TURN ON THE POWER on page and begin walking.
  • Page 15 The program will continue in this way until the Follow your progress with the displays. speed setting for the last segment is shown in the Current Segment column and the last segment See step 6 on page 12. ends. The walking belt will then slow to a stop. Measure your heart rate if desired.
  • Page 16 is shown in the flashing HOW TO CREATE A CUSTOM PROGRAM Current Segment Current Segment col- umn of the matrix. (The incline settings are not Insert the key into the console. shown in the matrix.) To program a speed setting See HOW TO TURN ON THE POWER on page and an incline setting for the first segment, simply...
  • Page 17 the columns to the right. HOW TO USE A CUSTOM PROGRAM When only three seconds remain in the first seg- Insert the key into the console. ment of the program, both the Current Segment column and the column to the right will flash, a se- ries of tones will sound, and the Speed display See HOW TO TURN ON THE POWER on page and the Incline display will flash.
  • Page 18 Enter a target heart rate setting. HOW TO USE A HEART RATE PROGRAM If the first heart rate program is selected, the CAUTION: target heart rate setting If you have heart prob- for the entire program will lems, or if you are over 60 years of age and flash in the display.
  • Page 19 When the first segment ends, all target heart rate If your pulse is not detected during the program, settings will move one column to the left. The tar- the letter “P” will flash in the Pulse display and the get heart rate setting for the second segment will speed of the treadmill may automatically then be shown in the flashing Current Segment decrease.
  • Page 20 THE INFORMATION MODE/DEMO MODE HOW TO ADJUST THE CUSHIONING SYSTEM The console features an information mode that keeps The treadmill features a cushioning system that re- track of the total number of hours that the treadmill has duces the impact as you walk or run on the treadmill. been used and the total number of miles that the walk- To increase the firmness of the walking platform, slide ing belt has moved.

  • Page 21: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be permanently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) to raise, lower, or move the treadmill.
  • Page 22 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the frame with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the frame down until it is past the latch pin.

  • Page 23: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 24 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 9. b. If the walking belt is overtightened, treadmill perfor- 3–4” mance may decrease and the walking belt may be permanently damaged.

  • Page 25: Exercise Guidelines

    EXERCISE GUIDELINES ergy. Only after the first few minutes does your body WARNING: begin to use stored fat calories for energy. If your goal Before beginning this is to burn fat, adjust the speed or incline of the tread- or any exercise program, consult your physi- mill until your heart rate is near the lowest number in cian.
  • Page 26 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 27: Part List

    PART LIST—Model No. EPTL15605.0 R1205A To locate the parts listed below, see the EXPLODED DRAWING attached in the center of this manual. No. Qty. Description No. Qty. Description No. Qty. Description Foot Rail Cover Reed Switch Clip Console Back 3/4” Screw Hood Bracket Upright Bolt Left Foot Rail...

  • Page 30: How To Order Replacement Parts

    HOW TO ORDER REPLACEMENT PARTS To order replacement parts, see the front cover of this manual. To help us assist you, please be prepared to give the following information: • The MODEL NUMBER of the product (EPTL15605.0) • The NAME of the product (EPIC 800 MX treadmill) •...

This manual is also suitable for:

Eptl15605.0
