Epic Tl 2710 Treadmill User Manual

English manual
Hide thumbs

Advertisement

Table of Contents

Model No. EPTL14211.0
Serial No.
Write the serial number in the space
above for reference.
QUESTIONS?
If you have questions, or if parts
are damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-866-997-6999
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.iconservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Serial
Number
Decal
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tl 2710 Treadmill and is the answer not in the manual?

Questions and answers

Steve
March 27, 2025

How do I perform a factory reset on my epic to 2710 treadmill. The treadmill is currently frozen on the ifit logo

0

Related Manuals for Epic Tl 2710 Treadmill

Summary of Contents for Epic Tl 2710 Treadmill

  • Page 1 Model No. EPTL14211.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE; please contact Customer Care. IMPORTANT: Please register this product (see the limited warranty on the back cover of this manual)

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . 2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precations and in- structions in this manual and all warnings on your treadmill before using your treadmill. ICON as- sumes no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 4 19. The heart rate monitor is not a medical 23. Never insert any object into any opening on device. Various factors, including the user’s the treadmill. movement, may affect the accuracy of heart rate readings. The heart rate monitor is in- 24.

  • Page 5: Before You Begin

    Thank you for selecting the revolutionary EPIC reading this manual, please see the front cover of this ® 2710 treadmill. The TL 2710 treadmill offers an im- manual. To help us assist you, please note the product pressive selection of features designed to make your model number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • To hire a service technician to assemble this prod- • To identify small parts, see page 6. uct in your home, call 1-800-445-2480. • Assembly requires the following tools: • Assembly requires two persons. the included hex keys •...
  • Page 8 2. Identify the Right Upright (92), which is marked with a “Right” sticker. Wire Have a second person hold the Right Upright (92) near the Right Base Cover (102). See the inset drawing. Tie the wire tie in the lower end of the Right Upright securely around the end of the Upright Wire (93).
  • Page 9 4. Have a second person hold the console assem- bly near the Uprights (91, 92). Console Connect the Upright Wire (93) to the Console Assembly Wire (88). See the inset drawing. The connec- tors should slide together easily and snap into place.
  • Page 10 6. Partially tighten three 3/8" x 1 1/4" Screws (2) with three 3/8" Star Washers (6) into the Right Upright (92); do not fully tighten the Screws yet. Repeat this step with the Left Upright (91). Firmly tighten all six 3/8" x 1 1/4" Screws (2). 7.
  • Page 11 8. Raise the Frame (67) to the position shown. Have a second person hold the Frame until this step is completed. Orient the Storage Latch (87) so that the large barrel and the latch knob are in the positions shown. Attach the Storage Latch (87) to the bracket on the Base (103) with a 3/8”...

  • Page 12: Operation And Adjustment

    OPERATION AND ADJUSTMENT HOW TO PLUG IN THE POWER CORD This product is for use on a nominal 120-volt circuit (see drawing 1). A temporary adapter may be used to connect the surge suppressor to a 2-pole receptacle if DANGER: a properly-grounded outlet is not available (see Improper connec- drawing 2).
  • Page 13 CONSOLE DIAGRAM FEATURES OF THE CONSOLE As you exercise, the console will display instant ex- ercise feedback. You can also measure your heart The treadmill console offers an impressive array of rate using the handgrip heart rate monitor or the chest features designed to make your workouts more effec- heart rate monitor.
  • Page 14 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the treadmill has been exposed to The console features a tablet with a full-color touch cold temperatures, allow it to warm to room tem- screen. The following information will help you become perature before you turn on the power.
  • Page 15 HOW TO SET UP THE CONSOLE The browser will open to the iFit.com registration page. Touch an entry box to view the keyboard. Before using the treadmill for the first time, set up the Slide your finger up or down the screen to scroll up console.
  • Page 16 HOW TO USE THE MANUAL MODE Note: The first time you adjust the incline, you must first calibrate the incline system (see step 4 1. Insert the key into the console. on page 22). For your safety, as you adjust the incline setting to negative levels, the maximum speed of the treadmill will decrease at set See HOW TO TURN ON THE POWER on page...
  • Page 17 To measure your heart rate, stand on the foot The displays at the top of the screen can show two rails and hold the pulse bar with your palms on types of information. Touch each display until the display shows the desired information. the metal contacts for approximately ten seconds;...
  • Page 18 HOW TO USE AN ONBOARD WORKOUT If the speed or incline setting is too high or too low at any time during the workout, you can override 1. Insert the key into the console. the setting by pressing the Speed or Incline but- tons;...
  • Page 19 HOW TO USE A SET-A-GOAL WORKOUT The workout will function in the same way as the manual mode (see pages 16 and 17). 1. Insert the key into the console. The workout will continue until you reach the goal See HOW TO TURN ON THE POWER on page that you set.
  • Page 20 HOW TO USE AN IFIT LIVE WORKOUT Before some workouts will download, you must add them to your schedule on iFit.com. Note: To use an iFit Live workout, you must have ac- cess to a wireless network (see HOW TO USE THE For more information about the iFit Live work- outs, please see www.iFit.com.
  • Page 21 HOW TO USE THE EQUIPMENT SETTINGS MODE To turn on or turn off the display demo mode, first touch the Demo Mode button. Next, touch the On The console features an equipment settings mode checkbox or the Off checkbox. Then, touch the that allows you to select a language and the unit of back button on the screen.
  • Page 22 HOW TO USE THE MAINTENANCE MODE power switch into the off position. Wait for several seconds, and then press the power switch into the The console features a maintenance mode that allows reset position. Note: It may take a few minutes for you to update the console firmware, calibrate the in- the console to be ready for use.
  • Page 23 HOW TO USE THE WIRELESS NETWORK MODE An information box will ask if you want to connect to the wireless network. Touch the Connect button The console features a wireless network mode that al- to connect to the network or touch the Cancel but- lows you to set up a wireless network connection.
  • Page 24 HOW TO USE THE STEREO SOUND SYSTEM To enter a different web address in the URL bar, first, slide your finger down the screen to view the URL bar, To play music or audio books through the console’s if necessary. Then, touch the URL bar, use the key- speakers, you must connect your MP3 player, CD board to enter the address, and touch the Go button.

  • Page 25: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to the lowest position before you fold the treadmill. left.

  • Page 26: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following SYMPTOM: The console displays remain lit when the simple steps below. Find the symptom that you remove the key from the console applies, and follow the steps listed. If further assis- tance is needed, see the front cover of this manual.
  • Page 27 SYMPTOM: The walking belt slows when walked on Lower the treadmill (see HOW TO LOWER THE TREADMILL FOR USE on page 25). Remove the four indicated #8 x 3/4" Screws (1), and remove a. Use only a single-outlet surge suppressor that the Motor Hood (75).
  • Page 28 SYMPTOM: The walking belt is off-center or slips SYMPTOM: The iFit Live mode does not function when walked on correctly a. If the walking belt is off-center, first remove the a. If the iFit Live mode is not functioning correctly, key and UNPLUG THE POWER CORD.

  • Page 29: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 30: Part List

    PART LIST Model No. EPTL14211.0 R0911A Key No. Qty. Description Key No. Qty. Description #8 x 3/4" Screw Belt Guide 3/8" x 1 1/4" Screw Isolator 3/8" x 1 3/4" Bolt Reed Switch 3/8" x 2" Bolt Hood Mount 3/8" x 3 3/4" Screw Lift Arm Spacer 3/8"...
  • Page 31 Key No. Qty. Description Key No. Qty. Description Wheel Console Base Right Base Cover Console Ground Wire Base Console Plate Console Clamp – User’s Manual Base Foot Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.

  • Page 32: Exploded Drawing

    EXPLODED DRAWING A Model No. EPTL14211.0 R0911A...
  • Page 33 EXPLODED DRAWING B Model No. EPTL14211.0 R0911A...
  • Page 34 EXPLODED DRAWING C Model No. EPTL14211.0 R0911A...
  • Page 35 EXPLODED DRAWING D Model No. EPTL14211.0 R0911A...

  • Page 36: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
