SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
PELLET STOVE
MERIDIAN
OWNER'S MANUAL
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE
OF THIS PELLET BURNING ROOM HEATER. FAILURE TO FOLLOW THESE
INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY
OR EVEN DEATH
Contact your building or fire officials about restrictions and
installation inspection requirements in your area.
50-765
Advertisement
Table of Contents
Related Manuals for Enviro Meridian C-10135
Summary of Contents for Enviro Meridian C-10135
- Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE PELLET STOVE MERIDIAN OWNER’S MANUAL PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET BURNING ROOM HEATER. FAILURE TO FOLLOW THESE...
-
Page 2: Table Of Contents
Operating Instructions...6 Stove Controls...6 Automatic Safety Features...6 Thermostat Installation...7 Slider/Damper Setting...8 Operating Your Pellet Stove...9 Turning Your Pellet Stove Off...9 Routine Cleaning and Maintenance...10 Installation...12 Deciding Where to Locate your Pellet Appliance:...12 Removing your Pellet Appliance From The Pallet:...12 Floor Protection...13 Freestanding Dimensions...13... -
Page 3: Introduction
ASH: The ash content of the fuel and operation of your stove will directly determine the frequency of cleaning. The use of high ash fuels may result in the stove needing to be cleaned daily. A low ash fuel may allow longer intervals between cleaning. -
Page 4: Rating Label Location
There will be some build up of fly ash and small amounts of creosote in the exhaust. This will vary due to the ash content of the fuel used and the operation of the stove. It is advisable to inspect and clean the exhaust vent annually or every two tons of pellets. -
Page 5: Save This Instruction Manual For Future Reference
Do not abuse the glass by striking or slamming the door. Do not attempt to operate the stove with broken glass. The stove uses ceramic glass. Replacement glass must be purchased from an ENVIRO dealer. Do not attempt to open the door and clean the glass while the unit is in operation or if glass is hot. -
Page 6: Operating Instructions
Your pellet Stove has the following safety features: A) The stove will shut off when the fire goes out and the exhaust temperature drops below 120°F (49°C). B) The stove has a high temperature safety switch. If the temperature on the hopper reaches 200°F (93°C) the auger will automatically stop, and the stove will shut off when the exhaust temperature cools. -
Page 7: Thermostat Installation
If the unit has been placed in the ON /OFF thermostat mode, when the thermostat calls for heat, the unit will go through an ignition sequence and light the stove. Once lit the unit will operate at the selected setting displayed on the control board Heat Output Indicator. Once the thermostat stops calling for heat, the unit will stop feeding pellets and begin its’... -
Page 8: Slider/Damper Setting
SPECIAL NOTES: Pellet quality is a major factor in how the pellet stove will operate. If the pellets have a high moisture content or ash content the fire will be less efficient and has a higher possibility of the fire building up and creating clinkers (hard ash build-up). -
Page 9: Operating Your Pellet Stove
To START: Press the ON / OFF Button. The stove will turn on. The System Light will flash. The Auger Light will flash with each pulse of the auger (the Auger Feed Rate is pre-programmed during start-up). The Heat Level Indicator will show the Heat Level that the stove will run at after start-up. -
Page 10: Routine Cleaning And Maintenance
Then dispose of the scrapped ashes from the liner and from inside the burn-pot. Place the burn-pot back into the stove, making sure that the pipes are properly inserted into the burn pot. Place the liner back into the burn-pot, making sure that the ignitor hole in the liner is aligned with the ignitor tube. -
Page 11: Fresh Air Intake
062). Substitute materials will not be permitted. POST SEASON CLEAN-UP Once you are finished using the pellet appliance for the season, unplug the stove for added electrical protection. It is very important that the stove be cleaned and serviced as stated above. -
Page 12: Installation
3. Do not install the stove in a bedroom. 4. You can vent the stove through an exterior wall behind the unit or connect it to an existing masonry or metal chimney (must be lined if the chimney is over 6” (15.2cm) in diameter, or over 28 sq. inches (180.6 cm²) cross sectional area). -
Page 13: Floor Protection
LOOR ROTECTION Your MERIDIAN pellet stove requires floor protection. The floor protection must be non-combustible, extending beneath the stove the full width and depth of the unit including 6 “ (15cm) in front for ember protection. REESTANDING IMENSIONS WIDTH: 24 7⁄8 inches (63.2 cm) HEIGHT: 32 1⁄2 inches (82.6 cm) -
Page 14: Insert Dimensions
NSERT IMENSIONS WIDTH: HEIGHT: DEPTH: DEPTH FROM FRONT OF UNIT TO SURROUND: REESTANDING LEARANCES TO �� �� Maintain these clearances to combustibles. SIDE WALL TO UNIT 6 inches (20.4 cm) BACK WALL TO UNIT 3 inches ( 7.6 cm) ADJACENT WALL 2 inches ( 5.0 cm) NSERT LEARANCES TO... -
Page 15: Vent Termination Requirements
Since these factors are beyond Sherwood Industries Ltd’s. control, we grant no guarantee against such incidents. IT IS RECOMMENDED THAT AN AUTHORIZED DEALER/INSTALLER INSTALL YOUR PELLET STOVE Installation NOTE: Measure clearance to the nearest edge of the exhaust hood MINIMUM 4 feet (1.2m) below or beside any door or window that opens. -
Page 16: Outside Fresh Air Connection
(47.3 cm) ” ” (17.0 cm) 6 1⁄8” ” (33.2 cm) ” ” (29.1 cm) 10 7⁄8” ENVIRO MERIDIAN HEARTH PAD FLOORING STEEL FRAME (22.9 cm) (15.6 cm) (8.7 cm) (27.7 cm) GROUND WIRE DIRECTLY TO METAL CHASSIS 1/4” LAG BOLTS... -
Page 17: Through Wall Installation
Choose a location for your stove that meets the requirements stated in this manual and allows installation with the least amount of interference to house framing, plumbing, wiring, etc. Place the appliance 15” (37.5 cm) away from the wall. If the stove is to be set on a hearth pad, set the unit on it. -
Page 18: Straight Through Wall Installations
������ �������� Installation to use if there is a concrete or retaining wall in line with exhaust vent on pellet stove. The termination must be 12 inches (30 cm) from the outside wall and 12 inches (30 cm) above the ground. -
Page 19: Vertical Installation
ERTICAL NSTALLATION Choose a stove location that is ideal. See the section Deciding Where to Locate Your Pellet Appliance. Place the unit on the hearth pad (if installed on a carpeted surface) and space the unit in a manner so when the pellet vent is installed vertically, it will be 3”... -
Page 20: Hearth Mount Installation
EARTH OUNT NSTALLATION Lock fireplace damper in the open position. Install positive flue connector at the fireplace dampers. Connect a Tee or a 90° degree elbow to the exhaust pipe. Install flexible stainless steel liner or listed pellet vent to the top of the chimney. Installation �����... -
Page 21: Exterior Mounted Exhaust Blower
Choose a location for your stove that meets the requirements stated in this manual and allows installation with the least amount of interference to house framing, plumbing, wiring, etc. - Page 22 XTERIOR OUNTED NOTE: Ensure that all vent connections are installed by placing three screws evenly spaced and a small bead of high temperature silicone at each chimney connection. Also ensure that all vertical vent sections are properly supported and that all clearances to combustibles are maintained in accordance with the vent manufacturer’s specifications. ����...
-
Page 23: Through Wall Vertical Installation
Installation HROUGH ERTICAL NSTALLATION Follow the previous pages for through wall installations. Ensure that vent pipe is properly secured to wall using wall straps. Maintain clearances to combustibles on vent pipe as well as unit. ���� ��� ���� ��������� ����� ������ ����... -
Page 24: Masonry Fireplace Insert Installation
DO NOT cut or modify any factory firebox parts. If the fireplace insert does not fit into a zero clearance fireplace we recommend you use an ENVIRO freestanding model and install as a hearth mounted unit. Install a 3” (76 mm) flex pipe from the stove to the top of the chimney. -
Page 25: Installation Of Fireplace Insert Pedestal And Leveling Legs
NSTALLATION OF IREPLACE There are two parts to the Meridian insert pedestal and they can be found inside the hopper. Place unit on its’ back. Two hex head screws are used on each side of the pedestal (refer to figure on right). Using a wrench or socket attach the pedestal to the bottom of the unit. -
Page 26: Installation And Removal Of Control Panel In The Surround Panel
SSEMBLY AND NSTALLATION OF Place the assembled surround panel around the stove; align the slots with the screw heads. Push surround in then down to engage the surround slots on the mounting screws (see right). Make sure the top surround panel sits flat behind the stove top. -
Page 27: Plated Trim Installation
REMOVAL OF SIDE TRIMS: When stove is off and cool, open the door. Remove the two screws on the right cab side (at top and bottom of front flange) and the two screws on the left cab side (one above and one below hinge). The cab sides have hinges at the back so they can swing open when the screws have been removed. -
Page 28: Plated Door Installation
To avoid this, give the door a quick wipe with denatured alcohol on a soft cloth BEFORE lighting the stove. Never clean surfaces when hot. Do not use other cleaners or abrasives as they may leave a residue or scratches, which can become permanently etched into the surface. -
Page 29: Troubleshooting
Troubleshooting DO NOT: ● Service the stove with wet hands. The stove is an electrical appliance, which may pose a shock hazard if handled improperly. Only qualified technicians should deal with possible internal electrical failures. ● Do not remove from the firebox any screws without penetrating oil lubrication. - Page 30 Gauge (readings must be above .10” W.C. on low fire). If the motor fails to reach a 0.10” w.c. readings, then replace the Combustion Blower. üPoor Quality Fuel – Insufficient energy in the fuel to produce enough heat to keep the stove burning or operational.
- Page 31 üSet the auger trim till the #1 and #5 lights are illuminated. If the stove goes out and there are partially burned pellets left in the burn pot liner, the stove has shut down due to a lack of air, exhaust temperature, or power failure.
-
Page 32: Wiring Diagram
Wiring Diagram... -
Page 33: Parts List
Part Description Number 20-040 Control Panel Door 50-178 Circuit Board 115V 50-179 Circuit Board Decal - 115V 50-323 Control Panel Touch Latch 50-330 Circuit Board Control Panel 50-473 Combustion/ Exhaust Blower - 115V 50-474 Stainless Steel Burn Pot Liner 50-683 Door Cover - Painted 50-623 Door Cover - Pewter... -
Page 34: Parts Diagram - Freestanding Steel
Parts Diagram - Freestanding Steel... -
Page 35: Parts Diagram - Insert Steel
Parts Diagram - Insert Steel... -
Page 36: Parts Diagram - Components
Parts Diagram - Components... -
Page 37: Warranty
Consult an ENVIRO dealer. It is recommended than only an authorized ENVIRO dealer installs an ENVIRO unit. There will be no warranty coverage on parts destroyed or burnt out as a result of a consumer installation error or defect. -
Page 38: Installation Data Sheet
Installation Data Sheet The following information must be recorded by the installer for warranty purposes and future reference. NAME OF OWNER: _________________________________________ ADDRESS: _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________ MODEL:___________________________________ SERIAL NUMBER:___________________________ DATE OF PURCHASE: _____________ DATE OF INSTALLATION:___________ MAGNEHELIC AT INSTALL:___________________ INSTALLER’S SIGNATURE: _________________________________________ NAME OF DEALER:...
