1.0: INTRODUCTION

The Tannoy 5.1 SUB 15 is a powerful active subwoofer incorporating an additional 5 channels of amplification for powering a
full 5.1 monitoring system.
On each of the 6 channels of amplification there is user-switching of filtering to allow the internal crossovers to be used, or for
frequencies to be determined by an external processor.
For sub frequencies a 150W RMS amplifier drives the 380mm (15") bass unit. There are also 5 x 75W RMS amplifiers for the
centre, left, right and rear channels.
To ensure maximum benefit from ownership and for reasons of safety, please read the following information before using for
the first time.

2.0: WARNINGS AND PRECAUTIONS

Check that the voltage rating displayed on the rear panel and text above the mains inlet is correct for your area before connecting.
2.2: IMPORTANT
A mains cable is supplied with an IEC moulded socket at one end and a moulded mains plug appropriate to the country of use
at the other end. Where the moulded plug is fitted with a mains fuse, always replace with the same 5A rated fuse.
If the fitted plug is unsuitable for your type of outlet sockets, it should be cut off and disposed of safely, in case it is inserted into
a live socket elsewhere. The wires in the mains cable are coloured in accordance with the following code:
GREEN AND YELLOW EARTH
BLUE NEUTRAL
BROWN LIVE
AS THE COLOURS OF THE WIRES IN THE MAINS CABLE MAY NOT CORRESPOND WITH THE COLOURED MARKINGS
IDENTIFYING THE TERMINALS IN YOUR PLUG, PROCEED AS FOLLOWS:
The wire which is coloured GREEN AND YELLOW must be connected to the terminal in the plug which is marked either by the
letter E, the earth safety symbol
The wire which is coloured BLUE must be connected to the terminal in the plug which is marked by the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal in the plug which is marked by the letter L or coloured RED.
Ensure that the terminals are tightened securely, and no loose strands of wire are present. Ensure cord grip is clamped over
outer sheath of cable, rather than over the wires.

2.1: POWER REQUIREMENTS

, or coloured GREEN or GREEN AND YELLOW.
