- Page 1 110 SERIES SUBWOOFERS OWNER/OPERATOR/INSTALLER MANUAL 110TB (Tile Bridge) 110SR (Sheet Rock) 110CS (Corner Sub)
-
Page 2: Warranty/Damage Claims
When unpacking equipment, take note of any damages to the cardboard container and carefully inspect your Tannoy equipment for any impact in that area. Should you have any damage, immediately notify your carrier and our Tannoy customer service department. A return claim may be issued. You may be required to repack the equipment for pick-up by your local carrier. - Page 3 The 110 Series subwoofers feature a 10" long excursion driver capable of low end response down to 31 Hz and power handling in excess of 100 Watts. Its design is fully complementary to any Tannoy full range wall or ceiling mount loudspeaker.
- Page 4 NOTES...
-
Page 5: Table Of Contents
INPUT MODULE OPTIONS Passive Crossover Passive 70 V Passive 70 V Crossover Active w/2 channel feed-through ACTIVE MODULE CONTROLS MECHANICAL INSTALLATION 110TB 110SR 110CS SPECIFICATIONS 110TB Dimensions 110SR Dimensions 110CS Dimensions Technical Specifications TANNOY IN-CELING & IN-WALL LOUDSPEAKERS 10, 11... -
Page 6: Cabinet Options
110SR (Sheet Rock) Cabinet The second in the Tannoy family of true ceiling mounted subwoofers, the 110SR is engineered to deliver low frequency extension (-3 dB @ 31 Hz) and impact from a concealed position. It is specifically designed for flush mount in sheet rock ceilings, walls, overhangs or any position offering adequate clearance and suitable struc- tural support. -
Page 7: Input Module Options
Passive (standard) The basic connection panel supplied with any of the 110 Series subwoofers is an 8 Ohm speaker level input via barrier strip. It is highly recommended that the audio signal be low pass filtered via an outboard active crossover. This input module is ideal for systems requiring several subs that share a common outboard crossover and amplifier. -
Page 8: Passive 70 V
INPUT MODULE OPTIONS Passive 70 Volt Available for either option on passive units from page 7 A 70 Volt distribution amplifier is capable of supplying power to a number of remote speakers without concern of long cable runs or varied impedance loads (limited to amplifier power and line load). The passive 70 Volt module takes advantage of this type of installation with a 150 Watt interface transformer, definitely placing this 70 Volt unit above the "wimpy"... -
Page 9: Active W/2 Channel Feed-Through
INPUT MODULE OPTIONS Active (active subwoofer with 2-channel feed-through) A dedicated power amplifier that really brings your 110 Series subwoofer to life. Balanced line level inputs with switchable, balanced 80 Hz high pass feed-throughs provide appropriate signals to your satellite speaker's amplifier. An auto stand- by feature automatically switches power on and off in response to an audio signal. - Page 10 INPUT PHASE BOOST O dB +4 dB EARTH LIFT X-OVER MODE PASS PASS X-OVER FREQ 110 Series 150 Hz 40Hz LEVEL HI PASS OUTPUT 120VAC - 60 Hz 1.25A 250 Volts Auto ON...
-
Page 11: Active 110 Input Module Controls
ACTIVE 110 INPUT MODULE CONTROLS 1) INPUT - Two channel (stereo) balanced line level input. Connect via XLR male plugs from your signal source. Use high quality 2 conductor shielded audio cable (Belden 8451) for runs of up to 200'. The XLR pinout is: pin 1 (Shield), pin 2 (Signal high), pin 3 (Signal low). -
Page 12: Mechanical Installation 110Tb
Please read and understand all of these instructions thoroughly before beginning any work. Note that construction work for the installation of all Tannoy products must be done to local building codes by qualified, licensed installers. A local building inspector should approve any overhead installations. Tannoy assumes no liability for cause and effect of improper installation work. - Page 13 MECHANICAL INSTALLATION 110TB Figure 1: Hanger Bolt Figure 5: Turnbuckle 2’ x 2’ Tile Grid Installation Procedures: The 110TB was designed for quick and simple installation directly into a 2’ x 2’ T-bar ceiling grid (Figs. 9 & 10). Remove several tiles around the installation location to gain easier access for lacing the subwoofer in the ceiling grid.
- Page 14 MECHANICAL INSTALLATION 110TB Back off the coupling nut completely (Fig. 11) and thread on a backing nut with which to lock threads to the coupler. Hold the coupler up to the hanger bolt to estimate the half way point of the coupler, and set the backing nut to that height before re-installing the coupler and tightening it in place with a socket and an open end wrench.
- Page 15 MECHANICAL INSTALLATION 110TB In this photo (Fig. 15) we have removed the threaded rod, and installed eyebolts with backing nuts into the couplers, as described earlier. Detail of the connection with wire rope is shown in (Fig. 8), which is identical top and bottom.
-
Page 16: 110Sr
Please read and understand all of these instructions thoroughly before beginning any work. Note that all construction work for the installation of all Tannoy products must be done to local building codes by qualified, licensed installers. A local building inspector should approve any overhead installations. Always use safety goggles when cutting material using a Rotozip™... - Page 17 MECHANICAL INSTALLATION 110SR Figure 1: Instalation of blocking for flush mounting of PIR to joists. Figure 3: Attaching PIR to blocking. (Fig. 4) shows the PIR installed against a steel stud furring channel. Attach the PIR with screws directly through the furring and into 24”...
- Page 18 MECHANICAL INSTALLATION 110SR Leave some excess wire hanging through the opening in the PIR so the drywall contractors can cut a locate hole and drop the wires through. You may also want to consult with them on cutting out the opening for the sub as they will likely have the power tools (Fig.
- Page 19 MECHANICAL INSTALLATION 110SR After clearing the remaining debris and dust from the opening, it should look like (Fig. 6). Take note of the location and color of the 11 “T”-nuts, and the location and orientation of the cutout in the PIR. The four corner “T”-nuts are gold in color, to differentiate them from the remaining seven which are for securing the 110SR in place.
-
Page 20: 110Cs
Be sure to follow instructions carefully and conform to any and all local codes regarding this type of installation. A qualified, licensed installer should be retained for any behind the wall pre-wiring with final approval of a local building inspector. Tannoy assumes no liability for cause and effect of improper installation work. Your Package Includes: •... - Page 21 MECHANICAL INSTALLATION 110CS At your desired location, establish a “bottom” mark in the corner. For a minimum recommended space of 6” between the top of the subwoofer and the ceiling (to access the connector panel), this mark should fall at least 20”...
- Page 22 MECHANICAL INSTALLATION 110CS Install the 4 supplied 3/4” wood screws being careful not to strip the holes in the subwoofer. Two additional anchor screws should be installed up near the top rear edge of the subwoofer in the cavity where the control panel is located. The position of these two screws should correspond to the vertical pencil lines drawn earlier.
-
Page 23: Side View
DIMENSIONS 110TB SHIPPING WEIGHT WITH ACTIVE MODULE 40 LBS 2" " " 18" " FRONT VIEW " TOP VIEW SIDE VIEW 10" 8" SIDE VIEW... -
Page 24: Bottom View
DIMENSIONS 110SR 10" 19" BOTTOM VIEW 20" GRILLE 10" 8" PANEL SIDE VIEW SHIPPING WEIGHT WITH ACTIVE MODULE 4" 19" 20" 1" PRE-INSTALLATION RING SIDE VIEW " " 17" TOP VIEW " PRE-INSTALLATION " RING TOP VIEW " 1/4" 11/16" SIDE VIEW 37 LBS 14"... -
Page 25: Front View
DIMENSIONS 110CS SHIPPING WEIGHT WITH ACTIVE MODULE 56 LBS " " " FRONT VIEW 7" " " PANEL 30" TOP VIEW... -
Page 26: Technical Specifications
TECHNICAL SPECIFICATIONS ACTIVE MODULE Frequency Response: Power Rating: Maximum SPL (2) @ 1 meter: Driver Complement: LF Cutoff (-3 dB): Inputs: Outputs: Protection Limiter: Input Level: Low Pass Filter: All Pass: High Pass Filter: High Pass output: High Pass output Bandwidth: Amplifier type: AC Power Requirement: Power Consumption:... -
Page 27: Tannoy In-Celing & In-Wall Loudspeakers
CEILING & IN-WALL LOUDSPEAKERS Want to meet the rest of the family? In addition to our complete family of 110 series subwoofers, Tannoy offers an extensive range of full frequency loudspeaker solutions suitable for virtually any application. Marry your subwoofer to any of our ceiling, in wall or surface mount loudspeakers for the complete system that will enhance the sound quality of all your installations. - Page 28 Tannoy North America Inc. 335 Gage Avenue, Suite #1 Kitchener, Ontario Canada N2M 5E1 Tel: 519-745-1158 Fax: 519-745-2364 E-mail: inquiries@tannoyna.com www.tannoy.com I 0903...
