3.4: CARE OF YOUR SUBWOOFER

The 5.1 SUB 15 is robustly designed, and capable of high sound level outputs. If however distortion is heard, this indicates the
unit is being overdriven, and to avoid damage, the input level should be reduced immediately. The unit also has over temperature
protection, which if activated will give rise to partial or full shutdown. If activated, switch the unit off, until the rear panel cools
down. In the event of being overdriven, over current protection will also activate, again resulting in shutdown.
Do not use any chemicals or solvents to clean the cabinet. Wipe with a soft barely damp cloth.

4.0: TECHNICAL SPECIFICATION

Frequency Response
Input Sensitivity
Input Connectors
Output Connectors
Additional Features
Enclosure Volume
Enclosure (H x W x D)
Enclosure Weight
Enclosure Finish
8
Power Ratings 150W RMS (Sub)
75W RMS @ 8( (Centre/FL/FR/RL/RR)
-6dB at 25Hz to 120 Hz (low pass on)
-6dB at 25Hz to 500Hz (All pass on)
Variable input gain control on each channel
Sub/Centre/FL/FR/RL/RR. XLR Balanced
High Pass Filter Centre/FL/FR/RL/RR
On - Fixed at 65Hz, 2nd Order
Off - All pass (20Hz - 20kHz)
Binding post speaker connectors (FL/FR/Centre/RR/RL)
Level control for each 5.1 channel (+/- 6dB)
Phase invert switch on sub channel (0 & 180deg)
Thermal and over current protection
Provision of spikes for floor coupling
Power LED
Driver Type 380mm long throw bass unit
Enclosure Type Twin ducted port
95 litre
475 x 520 x 505 mm, incl. grille
34kg
Grey suedette vinyl, black grille
230V nominal (220-240V), 50-60Hz
Mains Voltage
Mains Fuse T1.25A (250V)
Our policy commits us to incorporating improvements to our products through continuous research and development. Please confirm current
specifications for critical applications with your supplier.
