Summary of Contents for Tannoy 110 Series
- Page 1 110 SERIES SUBWOOFERS 110TB (Tile Bridge) 110SR (Sheet Rock) 110 Series Subwoofer O W N E R ’ S M A N U A L...
-
Page 2: Table Of Contents
M A N U A L C ONTE NTS TABLE OF CONTENTS ACTIVE 110 INPUT MODULE CONTROLS WARRANTY / DAMAGE CLAIM MECHANICAL INSTALLATION - 110TB 110 SERIES SUBWOOFERS & MECHANICAL INSTALLATION - 110TB INPUT MODULES Cabinet Options MECHANICAL INSTALLATION - 110TB INPUT MODULE OPTIONS... -
Page 3: Warranty / Damage Claim
Claims will not be considered if the serial number had been altered or removed. Work under warranty should only be carried out by a Tannoy Professional Dealer or Service Agent. This warranty in no way affects your statutory rights. -
Page 4: Cabinet Options
110 SERIES SUBWOOFERS AND INPUT MODULES This manual is intended for the owner, operator or installer of Tannoy 110 Series Subwoofers. It is a guide for installing, setting up and operating the 110 Series in accordance with established codes and practices available at the time of publication. -
Page 5: Passive
PASSIVE (STANDARD) The basic connection panel supplied with any of the 110 Series Subwoofers is a 8 Ohm speaker level input via barrier strip. It is highly recommended that the audio signal be lo pass filtered via an outboard active crossover. This input module is ideal for systems requiring several subs that share a common outboard crossover and amplifier. -
Page 6: Input Module Options
ACTIVE (ACTIVE SUBWOOFER WITH 2-CHANNEL FEED-THROUGH) A dedicated power amplifier that really brings your 110 Series Subwoofer to life. Balanced line level inputs with switchable, balanced 80 Hz high-pass feed through’s provide appropriate signals to your satellite speaker’s amplifier. An auto stand-by feature automatically switches power on and off in response to an audio signal. -
Page 7: Active 110 Input Module Controls
ACTIVE 110 INPUT MODULE CONTROLS ACTIVE MODULE WITH OUTPUT FOR 2 SPEAKERS LEVEL SA 110 PASS PASS A C T I V E S U B W O O F E R XOVER CAUTION FREQ. RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK DO NOT OPEN 50Hz 150Hz... -
Page 8: Mechanical Installation 110Tb
Please read and understand all of these instructions thoroughly before beginning any work. Note that construction work for the installation of all Tannoy products must be done to local building codes by qualified, licensed installers. A local building inspector should approve any overhead installations. Tannoy assumes no liability for cause and effect of improper installation work. -
Page 9: Mechanical Installation 110Tb
MECHANICAL INSTALLATION 110TB 2’ x 2’ Tile grid installation procedures: The 110TB was designed for quick and simple installation directly into a 2’ x 2’ T-bar ceiling grid (Figs. 9 & 10). Remove several tiles around the installation location to gain easier access for placing the subwoofer in the ceiling grid. -
Page 10: Mechanical Installation 110Tb
MECHANICAL INSTALLATION 110TB Fig. 8: Wire rope detailing Fig. 9: Installed subwoofer top view, Fig. 10: Completed subwoofer suspension or seismic tether. only two chains attached. installation. Fig. 11: Installing the hanger bolt. Fig. 12: Installed hanger bolt. Fig. 13: Suspension points with turnbuckles installed. -
Page 11: Mechanical Installation 110Sr
Please read and understand all of these instructions thoroughly before beginning any work. Note that construction work for the installation of all Tannoy products must be done to local building codes by qualified, licensed installers. A local building inspector should approve any overhead installations. Always use safety goggles when cutting material using a RotoZip™. -
Page 12: Mechanical Installation 110Sr
MECHANICAL INSTALLATION 110SR NEW / EXISTING CONSTRUCTION INSTALLATION PROCEDURES: Leave some excess wire hanging through the opening in the pre-installation ring so the drywall contractors can cut a hole and drop the wires through. You may also want to consult with them on cutting the opening for the sub as they will likely have power tools. -
Page 13: Mechanical Installation 110Sr
MECHANICAL INSTALLATION 110SR Fig. 4: Pre-installation ring on steel Fig. 5: Cutting drywall using the Rotozip™. Fig. 6: Completed install showing the furring channel prior to drywall reveal of the pre-installation ring being placed. relative to the ceiling board. Fig. 9: Completed subwoofer detail. Fig. -
Page 14: Dimensions 110Tb 110Sr
DIMENSIONS 110TB SHIPPING WEIGHT WITH ACTIVE MODULE: 40 LBS. 2” 10 1/4" 19 5/8” 23 5/8”" 10” ......................................................................................................8” ...................... 18” ............................ -
Page 15: Technical Specifications
The sub turns “auto on” when signal is re-introduced. Want to meet the rest of the family? In addition to our complete family of 110 series subwoofers, Tannoy offers an extensive range of full frequency loudspeaker solutions suitable for virtually any application. - Page 16 Tannoy United Kingdom T: +44 (0) 1236 420199 E: enquiries@tannoy.com TC Group Americas Inc. T: 00 1 (519) 745 1158 E: inquiries@tcg-americas.com Tannoy Deutschland T: 00 49 (0180) 1111 881 E: info@tannoy.com Tannoy France T: 00 33 (0) 1 7036 7473...
