SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
PELLET STOVE
Evolution
OWNER'S MANUAL
Contact your building or fire officials about restrictions and installation
inspection requirements in your area.
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION
AND USE OF THIS PELLET-BURNING ROOM HEATER. FAILURE TO
FOLLOW THESE INSTRUCTIONS COULD RESULT IN PROPERTY
DAMAGE, BODILY INJURY OR EVEN DEATH.
50-1021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVOLUTION 50-1021 and is the answer not in the manual?

Questions and answers

Related Manuals for Enviro EVOLUTION 50-1021

Summary of Contents for Enviro EVOLUTION 50-1021

  • Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE PELLET STOVE Evolution OWNER’S MANUAL Contact your building or fire officials about restrictions and installation inspection requirements in your area.

  • Page 2: Table Of Contents

    Safety Warnings And Recommendations...4 Specifications...6 Dimensions...6 Rating Label Location...6 Operating Instructions...7 Control Board Functions...7 Automatic Safety Features of Your Pellet Stove...7 Operating Your Pellet Stove...8 Turning Your Pellet Stove Off...9 Slider/Damper Set-Up...9 Routine Cleaning and Maintenance...11 Warranty...14 Installation Data Sheet...15...

  • Page 3: Introduction

    UALITY Pellet quality is important, please read the following: Your enviro pellet stove has been designed to burn wood pellets only. Do not use any other type of fuel, as this will void any warranties stated in this manual. The performance of your pellet stove is greatly affected by the type and quality of wood pellets being burned.

  • Page 4: Important Safety Data

    CLEANING: There will be some build up of fly ash and small amounts of creosote in the exhaust. This will vary due to the ash content of the fuel used and the operation of the stove. It is advisable to inspect and clean the exhaust vent semi-annually or every two tons of pellets.

  • Page 5: Save This Instruction Manual For Future Reference

    GLASS: Do not abuse the glass by striking or slamming the door. Do not attempt to operate the stove with broken glass. The stove uses ceramic glass. Replacement glass must be purchased from an ENVIRO dealer. Do not attempt to open the door and clean the glass while the unit is in operation or if glass is hot.

  • Page 6: Specifications

    IMENSIONS " (619 mm) " (565 mm) ATING ABEL OCATION The rating label is located on the inside of the ash pan cover. Specifications " When not installing the optional (708 mm) Hearth Pad on the unit, the minimum requirements for floor protection are a width of 24 depth of 26 "...

  • Page 7: Operating Instructions

    UTOMATIC AFETY EATURES OF A. The stove will shut off when the fire goes out and the exhaust temperature drops below 120°F (49°C). B. The stove has a high temperature safety switch. If the temperature on the hopper reaches 200°F (93°C), the auger will automatically stop and the stove will shut down when the exhaust temperature...

  • Page 8: Operating Your Pellet Stove

       To START: Press the ON / OFF button. The stove will turn on. The system light will flash. The Auger Light will flash with each pulse of the auger (the Auger Feed Rate is pre-programmed during start-up).

  • Page 9: Turning Your Pellet Stove Off

    • MANUAL and HI / LOW mode: To turn the unit OFF, simply press the ON / OFF button. This will stop  the feed of pellets. The blowers will continue to operate and cool the stove down. When cool enough, the stove will turn off.

  • Page 10: Routine Cleaning And Maintenance

    To remove the burn pot and burn pot liner, open the door using the door handle provided (located on the left-hand side of the stove). Swing the door open. Lift the liner from the burn pot. Lift the burn pot from the firebox by gently lifting up the front of the burn pot, then sliding the assembly from the air intake tube and the ignitor cartridge.
  • Page 11 DOOR GLASS CLEANING (2-3 days) Cleaning of the glass must only be done when stove is cold. Open the door by lifting the handle. The glass can be cleaned by wiping down the outside and inside of the glass with a dry soft cloth.

  • Page 12: Post Season Clean-Up

    BLOWER MECHANISMS (season) Unplug the stove then open the right and left side panels to access the two blowers. Vacuum all dust from motors. Only the convection blower motor (on the right side of the stove) will require lubrication.

  • Page 13: Warranty

    Consult an ENVIRO dealer. It is recommended than only an authorized ENVIRO dealer installs an ENVIRO unit. There will be no warranty coverage on parts destroyed or burnt out as a result of a consumer installation error or defect.

  • Page 14: Installation Data Sheet

    Installation Data Sheet The following information must be recorded by the installer for warranty purposes and future reference. NAME OF OWNER: _________________________________________ ADDRESS: _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________ MODEL:___________________________________ SERIAL NUMBER:___________________________ DATE OF PURCHASE: _____________ DATE OF INSTALLATION:___________ MAGNEHELIC AT INSTALL:___________________ INSTALLER’S SIGNATURE: _________________________________________ NAME OF DEALER:...
