Appendix A: Specifications; Switch Specifications - Enterasys SecureStack B2 B2G124-24 Hardware Installation Manual

This appendix provides information about the following:
For information about...

Switch Specifications

Mini-GBIC Input/Output Specifications
Gigabit Ethernet Specifications
MGBIC-02 Specifications (1000BASE-T)
Regulatory Compliance
Enterasys Networks reserves the right to change the specifications at any time without
notice.
Switch Specifications
Table
specifications for the B2G124‐24, B2G124‐48, and B2H124‐48.
Table A-1 Switch Specifications
Item
B2G124-24
RJ45 ports 1 through 24
SFP ports 21 through 24
A‐1 provides the I/O ports, processors and memory, physical, and environmental
Specification
Twenty-four, 10BASE-T/100BASE-TX /1000BASE-T compliant
ports with auto-sensing and auto-negotiation via RJ45 UTP
connectors.
Four slots that support optional Mini-GBICs 1000BASE-FX
fiber-optic connections and 1000BASE-T copper connections.
When an SFP transceiver (Mini-GBIC) is installed in ports 21
through 24 and establishes a link, the associated RJ45 fixed front
panel 10BASE-T/100BASE-TX/1000BASE-T port is disabled.
Enterasys SecureStack B2 Installation Guide
A
Specifications
Refer to page...
A-1
A-4
A-4
A-7
A-8
A-1
