Troubleshooting Checklist
Table 4-2 Troubleshooting Checklist (Continued)
Problem
Cannot contact
the 6H352-25
through in-band
management.
Port(s) goes into
standby for no
apparent reason.
User parameters
(IP address,
Device and
Module name,
etc.) were lost
when the
6H352-25 power
was cycled or the
front panel

RESET button

was pressed.
4-6 Troubleshooting
Possible Cause
IP address not assigned.
Port is disabled.
No link to device.
Loop condition detected.
1. Position of Mode switch
(7), NVRAM Reset, was
changed sometime
before either cycling
power or pressing the
RESET button, causing
the user-entered
parameters to reset to
factory default settings.
2. Clear NVRAM was set
through Local
Management.
Recommended Action
Refer to the MATRIX E7 Series and
SmartSwitch 6000 Series Modules Local
Management User's Guide for the IP address
assignment procedure.
Enable port. Refer to the MATRIX E7 Series
and SmartSwitch 6000 Series Modules Local
Management User's Guide for instructions
to enable/disable ports.
1. Verify that all network connections
between the network management station
and the 6H352-25 are valid and operating.
2. If the problem continues, contact
Enterasys Networks for technical support.
1. Verify that Spanning Tree is enabled.
Refer to MATRIX E7 Series and
SmartSwitch 6000 Series Modules Local
Management User's Guide for the
instructions to set the type of STA.
2. Review the network design and delete
unnecessary loops.
3. If the problem continues, contact
Enterasys Networks for technical support.
1. Reenter the lost parameters as necessary.
Refer to MATRIX E7 Series and
SmartSwitch 6000 Series Modules Local
Management User's Guide for the
instructions to configure the device
through Local Management.
2. If the problem continues, contact
Enterasys Networks for technical support.
