ELECTRICAL HAZARD: Only qualified personnel should install the 6H352-25.
NOTE: Read the Release Notes shipped with the module to check for any exceptions to
the supported features and operation documented in this guide.
This chapter provides the instructions to install the 6H352-25 module. A Phillips screwdriver is
required to install options into the module. Follow the order of the sections listed below to
correctly install the module.
• Unpacking the 6H352-25
• Installing Optional HSIMs, VHSIMs or Memory Upgrade
•

Installing the 6H352-25 into the MATRIX E7 Chassis

•

Installing the 6H352-25 into the SmartSwitch 6000 Chassis

• Connecting to the Network
• Completing the Installation
(Section 3.1)
(Section 3.5)
(Section 3.6)

Installation

(Section 3.2)
(Section 3.3)
(Section 3.4)
3
Installation 3-1
