Installing Optional HSIM or VHSIM Interface Modules

B.4 INSTALLING OPTIONAL HSIM OR VHSIM INTERFACE MODULES
Figure B-4 shows the location of the two connectors for an optional HSIM or VHSIM. Depending
on the HSIM or VHSIM installed, one or both connectors are used.
NOTE: The installation instructions for the optional HSIM or VHSIM are in the
associated user's guide. Do not install the HSIM or VHSIM without referring to the
proper installation guide.
Figure B-4 HSIM and VHSIM Connector Locations
Optional HSIM
or VHSIM
B-6 Mode Switch Bank Settings and Options
HSIM/VHSIM Connectors
