- Page 1 USER’S MANUAL EVO2 MOTORIZED TREADMILL MODEL NUMBER: EVO2 USER WEIGHT LIMITATION: 400lbs. (180kgs.) TOLL FREE CUSTOMER SERVICE NUMBER: 1.888.800.1167 SERIAL NUMBER (found on frame): V-04-20051005...
- Page 2 EVO2 MOTORIZED TREADMILL PRECAUTIONS For future service or related questions: Please staple your receipt and/or write in the name and phone number of the retail store where you purchased your Smooth Fitness treadmill. Name: ______________________________ Phone Number: ___________________ Receipt: ______________________ Precautions: WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill.
-
Page 3: Power Requirements
EVO2 MOTORIZED TREADMILL POWER REQUIREMENTS Power Requirements: IMPROPER CONNECTION OF THE EQUIPMENT GROUNDING CONNECTOR CAN RESULT IN A RISK OF AN ELECTRIC SHOCK. CHECK WITH A QUALIFIED ELECTRICIAN OR SERVICE MAN IF YOU ARE IN DOUBT AS TO WHETHER THE PRODUCT IS PROPERLY GROUNDED. DO NOT MODIFY THE PLUG PROVIDED WITH THE PRODUCT, IF IT WILL NOT FIT THE OUTLET;... -
Page 4: Pre-Assembly
EVO2 MOTORIZED TREADMILL PREASSEMBLY Open the boxes: You are now ready to open the boxes of your new equipment. Make sure to inventory all of the parts that are included in the boxes. Check the Hardware Comparison Chart for a full count of the number of parts included for this product to be assembled properly. -
Page 5: Hardware Comparison Chart
EVO2 MOTORIZED TREADMILL HARDWARE COMPARISON CHART Hardware chart: For your convenience, we have identified the hardware used in the assembly of this product. This chart is provided to help you identify those items that may be unfamiliar to you. DESCRIPTION QTY. -
Page 6: Parts List
EVO2 MOTORIZED TREADMILL PARTS LIST Description Qty. Order No. Description Qty. Order No. Computer EVO2-01 Console Support Tube EVO2-30 Safety Key EVO2-02 M6 x 12mm Screw EVO2-31 Console Support Tube EVO2-03 Plastic Cover EVO2-32 Wire Protect Key EVO2-04 M6 x 55mm Bolt EVO2-33 M6 x 20mm Console Screw EVO2-05... - Page 7 EVO2 MOTORIZED TREADMILL PARTS LIST Description Qty. Order No. Description Qty. Order No. Rail Guide EVO2-59 Plastic Clamp - Bottom EVO2-89 M8 x 25mm Screw EVO2-60 Bracket EVO2-90 Running Deck EVO2-61 M8 x 19mm Allen Head Bolt EVO2-91 Deck Cushion EVO2-62 Rear Roller EVO2-92...
-
Page 8: Parts Diagram
EVO2 MOTORIZED TREADMILL PARTS DIAGRAM A MAJORITY OF THE PARTS SHOWN HERE HAVE BEEN PREASSEMBLED AT THE FACTORY. Visit us at: www.evofitness.com... - Page 9 EVO2 MOTORIZED TREADMILL PARTS DIAGRAM A MAJORITY OF THE PARTS SHOWN HERE HAVE BEEN PREASSEMBLED AT THE FACTORY. Visit us at: www.evofitness.com...
- Page 10 EVO2 MOTORIZED TREADMILL ASSEMBLY STEP 1: Remove your treadmill from the carton and place it on the floor in an open area as shown in FIG-1. Remove the pre-assembled M6 x 55mm Bolt (33) and 6 x 13mm Washer (34) from lower upright. Make sure to connect the wires from the Left Upright (26) to the Base Frame (43).
- Page 11 EVO2 MOTORIZED TREADMILL ASSEMBLY STEP 2: Rotate the Computer (1) up to the correct position as shown in FIG-2 and secure in place using two M6 X 20mm Screws (5). FIG-2 Visit us at: www.evofitness.com...
- Page 12 EVO2 MOTORIZED TREADMILL ASSEMBLY STEP 3: Attach the Cross Brace (25) to the Left and Right Uprights (26 and 27) using two M8 x 80mm Allen Head Bolts (21) and Metal Caps (22). Do not fully tighten the M8 x 80mm Allen Head Bolts (21).
- Page 13 EVO2 MOTORIZED TREADMILL ASSEMBLY STEP 4: Connect the wires from the Left Handlebar (16) and Left Upright (26). Attach the Left Handlebar (16) to the Left Upright (26) using two M8 x 50mm Allen Bolts (104) and one Connection Plate (23). Repeat this procedure to attach the Right Handlebar (17) to the Right Upright (27).
- Page 14 EVO2 MOTORIZED TREADMILL ASSEMBLY STEP 5: Connect the wires from the Front Handlebar (13) and Left Upright (26). Attach the Front Handlebar (13) to the Left and Right Uprights (26 and 27) using two M6 x 12mm Screws (31). Visit us at: www.evofitness.com...
- Page 15 EVO2 MOTORIZED TREADMILL ASSEMBLY STEP 6: Attach the Left # 1 Handlebar Rear End Cap (7) and Left # 2 Handlebar Rear End Cap (8) to the Left Upright (26) using two Plastic Fixing Inserts (12) and four #8 x 12mm Screws (11). Attach the Right # 2 Handlebar Rear End Cap (9) and Right # 1 Handlebar Rear End Cap (10) to the Right Upright (27) using two Plastic Fixing Inserts (12) and four #8 x 12mm Screws (11).
- Page 16 EVO2 MOTORIZED TREADMILL ASSEMBLY STEP 7: Attach one Plastic Cover (32) to the Left Upright (26) using one M6 x 12mm Screw (31). Repeat this procedure for the Right Upright (27). Visit us at: www.evofitness.com...
- Page 17 EVO2 MOTORIZED TREADMILL ASSEMBLY STEP 8: Attach the Upright Plastic Shroud Left #3 (105), Upright Plastic Shroud Left #1 (46) and Upright Plastic Shroud Left #2 (47) to the Left Upright (26) and secure with four #8 x 19mm Screws (107) and six #8 x 15mm Screws (108). Repeat this procedure for the Right Upright (27).
-
Page 18: Transport Instructions
EVO2 MOTORIZED TREADMILL TRANSPORT INSTRUCTIONS TRANSPORT INSTRUCTIONS: To roll away for storage simply grab the rear deck, lift slightly and roll to desired location. Visit us at: www.evofitness.com... -
Page 19: Maintenance
EVO2 MOTORIZED TREADMILL MAINTENANCE HOW TO MAINTAIN THE EVO2 TREADMILL: Proper maintenance is very important to ensure your treadmill is always in top working condition. Improper maintenance could cause damage or shorten the life of your treadmill and exceed the LIMITED WARRANTY coverage. •... - Page 20 Your treadmill should not have to be lubricated usually within the first year or 500 hours of use. Call your local Smooth dealer for service or questions regarding EVO products. Every 3 months of operation lift the sides of the walking belt and feel the top surface of the walking board as far as you can reach.
-
Page 21: Warranty
You may be required to show proof of purchase prior to warranty service being initiated. Remedy Provided by Smooth Fitness: To obtain service on an EVO Fitness product, contact your local retailer. All labor for EVO Fitness products purchased through your local retailer shall be performed by that retailer and the product must be located within the retailer’s service... -
Page 22: Important Steps
EVO2 MOTORIZED TREADMILL IMPORTANT STEPS Warning: Before using this product, please consult your personal physician for a complete physical examination. Frequent and strenuous exercise should be approved by your doctor first. If any discomfort should result from your use of this product, stop exercising and consult your doctor. -
Page 23: Target Heart Rate
EVO2 MOTORIZED TREADMILL TARGET HEART RATE Finding your pulse: To make sure your heart is beating in its target zone, you’ll need to know how to monitor your heart rate. The easiest way is to feel the pulse in the carotid artery on either side of your neck, between the windpipe and the large neck muscles. Count the number of beats in ten seconds, and then multiply that number by six. -
Page 24: Muscle Chart
EVO2 MOTORIZED TREADMILL MUSCLE CHART Targeted muscle groups: The exercise routine that is performed on this product will develop primarily lower body muscle groups. These muscle groups are shown in gray color on the chart below. Shoulder muscles Pectoral muscles Bicep muscle Abdominal muscles Forearm muscles... -
Page 25: Stretching Routine
EVO2 MOTORIZED TREADMILL STRETCHING ROUTINE Warm up and cool down: A successful exercise program consists of a warm-up, aerobic exercise, and a cool-down. Do the entire program at least two and preferably three times a week, resting for a day between workouts. After several months, you can increase your workouts to four or five times per week. - Page 26 EVO2 MOTORIZED TREADMILL STRETCHING ROUTINE Hamstring Stretch: Sit with your right leg extended. Rest the sole of your left foot against your right inner thigh. Stretch toward your toe as far as possible. Hold for 15 counts. Relax and then repeat with left leg extended. Inner Thigh Stretch: Sit with the soles of your feet together with your knees pointing outward.
-
Page 27: Troubleshooting
EVO2 MOTORIZED TREADMILL TROUBLESHOOTING Troubleshooting NOTE: Do not touch any internal electric wires without consulting the manufacturer. Treadmill will not start: 1. Make sure the power cord is plugged into a surge protector, the surge protector is plugged into a properly grounded outlet and the surge protector is turned on (refer to the Power Requirements section in this manual). - Page 28 Smooth Fitness 112 Gaither Drive Mt. Laurel, NJ 08054 Toll Free Customer Service: 1.888.800.1167 Website: www.evofitness.com Copyright © 2003...
