- Page 1 DESCRIPTION: ReNegaDE Runner CODE: ARUN100 VERSION: 20190626 PLEASE READ THIS INSTRUCTION MANUAL BEFORE YOU BEGIN ASSEMBLY INSTRUCTION MANUAL...
-
Page 2: Table Of Contents
contents safety information customer support assembly instructions Runner features explained computer instructions - quick start - button functions - console display and feedback - using workout programs how to take care of your Runner exercising with your Runner I-1 console assembly exploded diagrams and parts list your warranty... -
Page 3: Safety Information
Safety Information PLEASE READ THIS INSTRUCTION MANUAL BEFORE YOU BEGIN ASSEMBLY. GREAT CARE HAS BEEN TAKEN TO DESIGN THESE INSTRUCTIONS AND FOLLOWING THEM WILL HELP YOU WITH QUICKER ASSEMBLY AND MINIMISE THE RISK OF INJURY YOU ARE RESPONSIBLE FOR YOUR OWN SAFETY - Losing grip or suddenly releasing the handle could result in an uncontrolled return, ensure there is freee space around THIS LIST IS NOT EXHAUSTIVE. -
Page 4: Customer Support
Care & Maintenance Always place the equipment in a dry environment. Use a warm, damp cloth to keep the product clean. No wet cleaning of electrical components, unplug before any care and maintenance The safety level of the equipment can be maintained only if it is regularly examined for damage and wear. This includes any ropes, pulleys, nuts, bolts, moving parts, bushes, chains, wheels, bearings &... -
Page 5: Assembly Instructions
Assembly Instruction Before you start 1. Prepare your work area - 2. Work with a friend - 3. Open the carton - 4. Unpack the carton it is important you assemble we recommend you have checking any warnings on Remove all of the parts and the product in a clean and someone assist you with the carton and make sure you... - Page 6 1. Attach the Upright Posts FIXINGS: FIXINGS: 1-1. Attach the Left Upright Post Part Ask some one to help you hold the Left Upright Post Assembly (2) in front of the Left side Main Frame (1) closely. Attach the Left Upright Post (2) to the FIXINGS: TOOLS: front end of the left side Main Frame (1)
- Page 7 2. Attach the Bottom Handle FIXINGS: FIXINGS: Ask someone to help you hold the Bottom Handle assembly (4) in front of the Part Upright Posts (2 / 3) closely. Connect the Middle Section Wires (2 pins & 3 pins) (15 /17) and Top Section Wires (2pins &...
- Page 8 4. Attach the Console FIXINGS: FIXINGS: Remove the four M5 x 10mm Fixing Screws (74) which are located in the Part back of the Console (5). Slide the Console Cables (2pins & 3 pins) through the open hole of the Console Bracket carefully as shown. Attach the Console (5) to the Console Bracket Make sure the screws are fully...
-
Page 9: Runner Features Explained
Runner Features Explained Levelling your Runner 1. To help you level the Runner on uneven surface, 2 height adjusters are included on the rear stabilisers. Simply turn it to adjust the height of the Runner. Height Adjuster Transporting your Runner Your Runner has 2 transport wheels on the front stabilizer. -
Page 10: Computer Instructions
Computer Instructions Quick Start Use this mode if you just want a quick workout session and are not interested in setting up any personal data. Walk for a few seconds to power the console on. Press the “ START “ button. The values of WATTS, SPEED, RPM, HEART RATE ( if heart rate signal is detected ) will start displaying. -
Page 11: Console Display And Feedback
Console Display and Feedback INTERVAL TOTAL TIME REST Indicates the current section is in GO TOTAL TIME 88:88 > INTERVAL READY period or REST period of the interval Shows the count up GO & REST total program. run time of the program. 8:88 >... -
Page 12: Using Workout Programs
INTERVAL Programs Using Workout Programs This console features 3 interval programs : interval 20/10, interval 20/30 & interval custom. TOTAL TIME The interval 20/10 and interval 20/30 programs offer users a series of eight high-intensity workout intervals with preset time segments. REST These High Intensity Interval Training ( H.I.I.T.) programs will automati- INTERVAL... - Page 13 7. Use the “ “ buttons to set your total interval numbers TOTAL TIME ( 1 ~ 99 ) REST 8. Press “ ENTER ” to confirm your setting. INTERVAL 9. Press “ START ” to begin the workout and then start running.
- Page 14 Target CALORIES TARGET CALORIES 7. Make sure the console is switched on. CALORIES? 8. Press the “ target calories ” to select the program mode you want. 9. The default value of “ 50 “ is flashing in the “ CALORIES ” window.
-
Page 15: How To Take Care Of Your Runner
How to Take Care of Your Runner Storage Keep the equipment in a dry place with as little temperature variation as possible. Try to protect from dust and always unplug when not in use (if applicable). The safety level given by the design of this runner can only be maintained when this runner is regularly examined for damage and wear. -
Page 16: Exercising With Your Runner
Exercising with Your Runner Troubleshooting If you have a problem with your equipment, before you do anything else please check that all the cables have been connected correctly. Loose cables are very common and many problems can be solved by making sure the cables are properly connected If you are having problems with your heart rate reading please note that some fibres used in clothes eg) polyester, create static electricity that may prevent a reliable heart rate reading. -
Page 17: I - 1 Console Assembly
I - 1 Console Assembly 2 PIN 3 PIN... -
Page 18: Exploded Diagrams And Parts List
Product Profile Bottom Handle Top Handle Console Adjustable Resistance Handle Right Upright Post Bottle Holder Left Upright Post Running Slat Side Foot Rail Side Cover Rear Lifting Handle... - Page 19 Main Parts Part Console Part Part Magnetic / Resistance Part Adjustable Handle Left / Rright Upright Posts Front Roller Assembly Part Rear Roller Assembly Running Belt Part Part Part Aluminum Slat Assembly Curve Bearing Trajectory Assembly Part Part Part Part Part Part Side Foot Rail...
- Page 20 Exploded Diagram...
- Page 22 Parts List Descrip on Q'ty Descrip on Q'ty Main Frame Hexagon head full thread bolt - M8 × 30 Upright post - le side Rear roller assembly adjustable fixing plate Upright post - right side Reinforcement rear covered plate Bo om handle bar assembly Hexagon socket head full thread screw - M8 ×...
-
Page 23: Your Warranty
Your Warranty This product is supplied with a 1 year warranty as follows: This product is warranted for use in a commercial environment This warranty excludes damage to the finish of the machine, damage sustained as a result form neglect, abuse, or failure to follow the suggested maintenance requirements (see Maintanance), shipping charges and if applicable, labor for the installation of any parts shipped to the owner under this warranty.
