EverFocus EZ-VF325NH Operation Instructions Manual

1/3” 550 tvl high resolution dsp color mini bullet camera
Hide thumbs Also See for EZ-VF325NH:
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

Please read this manual first for correct installation and operation. This manual should be retained
for future reference. The information in this manual was current when published. The
manufacturer reserves the right to revise and improve its products. All specifications are therefore
subject to change without notice.
PRECAUTIONS
1.
Do not install the camera near electric or magnetic fields.
Install the camera away from TV, radio transmitter, magnet, electric motor, transformer,
audio speakers since the magnetic fields generate from above devices will distort the video
images.
2.
Never disassemble the camera nor put impurities in it.
Disassembly or impurities may result in trouble or fire.
3.
Never face the camera toward the sun.
Direct sunlight or severe ray may cause fatal damage to sensor and internal circuit.
4.
Keep the power cord away from water and fluid.
Touching the wet power cord may result in electric shock.
5.
Do not operate the camera beyond the specified temperature, humidity or
power source ratings.
Use the camera at temperatures within -10ºC ~ 50ºC (14ºF to 122ºF) and humidity between
20%~ 80%. The input power source is 12VDC.
EVERFOCUS
1/3" 550 TVL High Resolution
DSP Color Mini Bullet Camera
Operation Instructions
EZ-VF325NH
Model No.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZ-VF325NH and is the answer not in the manual?

Questions and answers

Related Manuals for EverFocus EZ-VF325NH

Summary of Contents for EverFocus EZ-VF325NH

  • Page 1 EVERFOCUS 1/3” 550 TVL High Resolution DSP Color Mini Bullet Camera Operation Instructions EZ-VF325NH Model No. Please read this manual first for correct installation and operation. This manual should be retained for future reference. The information in this manual was current when published. The manufacturer reserves the right to revise and improve its products.

  • Page 2: Package Contents

    PREFACE The stylish appearance can be applied as per installer's ideal locations on the ceiling or wall. The mini bullet camera designed with advanced digital processing circuitry for high resolution 1/3" color interline transfer CCD sensor. Very low power consumption of 150mA or less. FEATURES 1/3”...

  • Page 3: Specifications

    SPECIFICATIONS Video Format NTSC Image Sensor 1/3" Sony ICX638 Super HAD CCD Scanning System 2:1 Inter lace Scanning Frequency H: 15734 KHZ, V:59.94 Hz Sensitivity 0.2 Lux/F=2.0 Total Pixels 811 (H) x 508 (V), 401k Effective Pixels 768 (H) x 494 (V), 380K Horizontal Resolution 550 TVL S/N Ratio...
  • Page 4 DIMENSIONS 54.7mm / 2.15" 19mm / .75" ¼” UNC 50mm / 2" 40mm / 1.6" 28.6mm / 1.1 24.8mm / 1"...

  • Page 5: Installation

    MAJOR PARTS FUNCTIONS (1) Lens This Vari-Focal Lens allows users to adjust the Zoom and Focus manually. (3) Video Output BNC Connector BNC 1.0Vp-p, 75ohm. Use the connector to connect with the video in connector of a monitor. (2) Power input Use the connector to connect with 12VDC power adaptor.
  • Page 6 Figure 1-1 c. Fix the bracket to the mounting service with included screws see figure 1-1 2. Fix camera to mounting Bracket. Figure 2-1 a. Install camera on bracket by tuning the camera clockwise on to the ¼” screw on the bracket until camera is facing up.
  • Page 7 3. Connect Power and Video Figure 3-1 a. Connect pigtail (male power adapter) to the camera female power connector. See Figure 3-1. b. Connect power to pigtail wires (pigtail- male power adapter is purchased separately) Pigtail Polarity: (Important since DC voltage is used) Negative Positive (white stripe)

  • Page 8: Troubleshooting

    Troubleshooting No power Check to be certain that you have sufficient current or amperage from the power supply. Amount of current needed depends on voltage. See this manuals spec. sheet for information on power consumption. Picture output is horizontal. Depending on camera will be installed on wall or on ceiling, you may have to remove camera module and rotate it so can install for wall or ceiling.
  • Page 9 FAX: 631-436-5027 TEL: +81-43-212-8188 www.everfocus.com FAX: +81-43-297-0081 www.everfocus.com Your EverFocus product is designed and Ihr EverFocus Produkt wurde entwickelt und manufactured with high quality materials and hergestellt mit qualitativ hochwertigen components which can be recycled and Materialien und Komponenten, die recycelt reused.
