Quick Installation Guide

00825-0100-4801, Rev HA

February 2008

Rosemount 3051S Series Pressure

Transmitter with HART

Rosemount 3051SF Series Flowmeter

Transmitter with HART

Step 1: Mou

Step 2: Consider Housing Rotation

Step 3: Set Switches and Jumpers

Step 4: Connect Wiring and Power Up

Step 5: Verify Configuration

Step 6: Trim the Transmitter

Safety Instrumented Systems

Product Certifications

Rosemount logotype are registered trademarks of Rosemount Inc.

HART

¢00825-0100-4801J¤

www.rosemount.com

Start

nt the Transmitter

End

Rosemount 3051S

Protocol

Table of Contents

Summary of Contents for Emerson Rosemount 3051S Series

Page 1 Quick Installation Guide 00825-0100-4801, Rev HA February 2008 Rosemount 3051S Series Pressure Transmitter with HART Rosemount 3051SF Series Flowmeter Transmitter with HART Step 1: Mou Step 2: Consider Housing Rotation Step 3: Set Switches and Jumpers Step 4: Connect Wiring and Power Up...
Page 2: Important Notice
Singapore 128461 T (65) 6777 8211 F (65) 6777 0947/65 6777 0743 This installation guide provides basic guidelines for Rosemount 3051S transmitters (reference manual document number 00809-0100-4801). It also provides the basic electronics guidelines for the 3051SFA (reference manual document number 00809-0100-4809), 3051SFC (reference manual document number 00809-0100-4810), and 3051SFP (reference manual document number 00809-0100-4686).
Page 3 Installation of this transmitter in an explosive environment must be in accordance with the appropriate local, national, and international standards, codes, and practices. Please review the approvals section of the 3051S reference manual for any restrictions associated with a safe installation. • Before connecting a HART communicator in an explosive...
Page 4: Step 1: Mount The Transmitter
Rosemount 3051S 1: M OUNT THE Liquid Flow Applications 1. Place taps to the side of the line. 2. Mount beside or below the taps. 3. Mount the transmitter so that the drain/vent valves are oriented upward. Gas Flow Applications 1.
Page 5 Quick Installation Guide 00825-0100-4801, Rev HA Rosemount 3051S February 2008 CONTINUED Panel Mount Pipe Mount ™ Coplanar Flange Traditional Flange In-line Housings ™ PlantWeb Junction Box Remote Mount Display...
Page 6 Rosemount 3051S 2: C ONSIDER To improve field access to wiring or to better view the optional LCD display: 1. Loosen the housing rotation set screw. 2. First rotate the housing clockwise to the desired location. If the desired location cannot be...
Page 7: Step 4: Connect Wiring And Power Up
Figure 3. Transmitter Wiring PlantWeb Housing Wiring RL ≥ 250 Ω NOTE Installation of the transient protection terminal block does not provide transient protection unless the 3051S case is properly grounded. Rosemount 3051S IRING AND Junction Box Housing Wiring Power...
Page 8 The Remote Mount Display and Interface system consists of a local transmitter and a remote mount LCD display assembly. The local 3051S transmitter assembly includes a Junction Box housing with a three position terminal block integrally mounted to a SuperModule.
Page 9 Alternate cable may be used as long as the transmitter with remote display and cable is configured according to the installation control drawing or certificate. Refer to appropriate approval certificate or control drawing in Appendix B of the 3051S reference manual for remote cable IS requirements. IMPORTANT Do not apply power to the remote communications terminal.
Page 10 SuperModule or the Remote Display, but not both. Quick Connect Wiring As standard, the 3051S Quick Connect arrives properly assembled to the SuperModule and is ready for installation. Cordsets and Field Wireable Connectors (in shaded area) are sold separately.
Page 11 Conduit Electrical Connector Wiring (Option GE or GM) For 3051S transmitters with conduit electrical connectors GE or GM, refer to the cordset manufacturer’s installation instructions for wiring details. For FM Intrinsically Safe, non-incendive or FM FISCO Intrinsically Safe hazardous locations, install in accordance with Rosemount drawing 03151-1009 to maintain outdoor rating (NEMA 4X and IP66.) See Appendix B of the 3051S reference manual.
Page 12: Power Supply
Rosemount 3051S CONTINUED Power Supply The dc power supply should provide power with less than two percent ripple. The total resistance load is the sum of the resistance of the signal leads and the load resistance of the controller, indicator, and related pieces.
Page 13: Step 5: Verify Configuration
Use any HART-compliant master to communicate with and verify configuration of the 3051S. For the HART Diagnostics transmitter (option code DA1), DD revision 3051S HDT Dev. 1 Rev. 1 is required. A check ( ) indicates the basic configuration parameters. At a minimum, these parameters should be verified as part of the configuration and startup procedure.
Page 14 Rosemount 3051S CONTINUED Function Saturation Level Configuration Scaled D/A Trim (4–20 mA Output) Scaled Variable Configuration Self Test (Transmitter) Sensor Information Sensor Temperature Sensor Trim Sensor Trim Points Status Temperature Alert Configuration Transfer Function (Setting Output Type) Transmitter Security (Write Protect)
Page 15: Step 6: Trim The Transmitter
3% of true zero, follow the “Using the Transmitter Zero Adjustment Button” instructions below to rerange. If hardware adjustments are not available, see the 3051S Reference Manual (document number 00809-0100-4801) to perform a rerange using the HART Communicator.
Page 16 Quick Installation Guide 00825-0100-4801, Rev HA Rosemount 3051S February 2008 Using the Transmitter Zero Adjustment Button Push and hold the zero adjustment button for at least two seconds but no longer than ten seconds. Figure 8. Transmitter Adjustment Buttons PlantWeb...
Page 17: Safety Instrumented Systems
00809-0100-4801). The manual is available electronically on www.rosemount.com or by contacting an Emerson Process Management representative. 3051S Safety-Certified Identification All 3051S transmitters must be identified as safety-certified before installing into SIS systems. NOTE There are two versions of safety-certified 3051S pressure transmitters.
Page 18: Installation
Configuration Use any HART-compliant master to communicate with and verify configuration of the 3051S Safety-Certified Pressure Transmitter (see Table 1 on page 13 and 14 to verify configuration). User-selected damping will affect the transmitters ability to respond to changes in the applied process.
Page 19 4 mA Namur Alarm Level Normal Operation 20 mA 4 mA Custom Alarm Level Normal Operation 20 mA 4 mA Rosemount 3051S 20 mA 20.8 mA high saturation 20.5 mA high saturation (3)(4) 20.2 - 23.0 20.1 - 20.5 mA high saturation 21.75...
Page 20 Rosemount 3051S Setting the alarm values and direction is dependent on whether or not the hardware switch option is installed. You can use a HART master or communicator to set the Alarm and Saturation values. Switches installed 1. If using a communicator, use the following fast key sequence to set the Alarm and Saturation values.
Page 21: Operation And Maintenance
Use "Table 1: HART Fast Key Sequence" to perform a Loop Test, Analog Output Trim, or Sensor Trim. See the 3051S reference manual for additional information. Proof Test 1...
Page 22 All failures detected by the transmitter diagnostics or by the proof-test must be reported. Feedback can be submitted electronically at www.emersonprocess.com/rosemount/safety/certtechdocumentation. htm. The 3051S is repairable by major component replacement. Follow the instructions in the 3051S reference manual (document number 00809-0100-4801) for additional information. Quick Installation Guide...
Page 23 IEC 61508 safety-certified SIL 2 Claim Limit. Specifications The 3051S Safety-Certified Pressure Transmitter must be operated in accordance to the functional and performance specifications provided in the 3051S reference manual. Failure Rate Data The FMEDA report includes failure rates and common cause Beta factor estimates.
Page 24: Product Certifications
Approved Manufacturing Locations Rosemount Inc. — Chanhassen, Minnesota USA Fisher-Rosemount GmbH & Co. — Wessling, Germany Emerson Process Management Asia Pacific Private Limited — Singapore Beijing Rosemount Far East Instrument Co., LTD — Beijing, China Emerson Process Management LTDA — Sorocaba, Brazil Emerson Process Management (India) Pvt.
Page 25 D, when installed per Rosemount drawing 03151-1013, CSA Enclosure Type 4X; conduit seal not required. Intrinsically Safe for Class I, Division 1, Groups A, B, C, and D when connected in accordance with Rosemount drawings 03151-1016; For entity parameters see control drawing 03151-1016. Rosemount 3051S...
Page 26 Rosemount 3051S European Certifications ATEX Intrinsic Safety Certificate No.: BAS01ATEX1303X EEx ia IIC T4 (T -HART/Remote Display/Quick Connect/HART Diagnostics 1180 Table 2. Input Parameters Loop / Power = 30V = 300 mA = 1.0W = 30nF = 11.4nF = 60 µH Special Conditions for Safe Use (X) 1.
Page 27 7J impact test. 5. The 3051S must be securely screwed in place to maintain the ingress protection of the enclosure. (The 3051S SuperModule must be properly assembled to the 3051S housing to maintain ingress protection.)
Page 28 The Model 3051S pressure transmitter must include a Series 300S housing integrally mounted to a Series Model 3051S Sensor module as per Rosemount drawing 03151-1023.
Page 29 Should the housing be replaced after initial supply to another Model 300S housing, the replacement housing shall have the same certification marking code information as the housing it replaces. = 60°C) IP66 = 60°C) IP66 Rosemount 3051S...
Page 30 3051S Profibus and 3051S FISCO are not capable of withstanding the 500V test as defined in clause 6.4.12 of IEC 60079-11. This must be taken into account during installation. 2. The terminal pins of the Types 3051S-T and 3051S-C must be protected to IP20 minimum. IECEx Type n Certificate No.: IECExBAS04.0018X...
Page 31 Combination of E6 and I6 Combination of E7, I7, and N7 Combination of E1, I1, E6, and I6 Combination of E5, I5, I6 and E6 Combination of E5, E1, I5 and I1 Combination of E5, I5, E6, I6, E1, and I1 Rosemount 3051S...
Page 32 Quick Installation Guide 00825-0100-4801, Rev HA Rosemount 3051S February 2008 D O C...
Page 33 Quick Installation Guide 00825-0100-4801, Rev HA Rosemount 3051S February 2008...
Page 34 Quick Installation Guide 00825-0100-4801, Rev HA Rosemount 3051S February 2008...
Page 35 Quick Installation Guide 00825-0100-4801, Rev HA Rosemount 3051S February 2008...
Page 36 Quick Installation Guide 00825-0100-4801, Rev HA Rosemount 3051S February 2008 NOTES...
