Page 1: Lighting Systems
IS_CD7-Surface Lighting Systems 9" (22.86cm) 3-1/4" 3-5/8" (8.26cm) (9.22cm) Lens Louver We reserve the right to change details of design, materials and finish. - Page 2 IS_CD7-Surface Lighting Systems PROCEDURE TO INSTALL SURFACE MOUNT FIXTURE Step 1. Unpack Step 2. IMPORTANT! Be Sure Electrical Power Is Off Step 3. Mount Ceiling Pan Step 4. Mount Fixture 22-3/4” (57.79cm) for 4’ Fixt. 53-1/4” (135.26) for 8’ Fixt. 3/4”...
- Page 3 IS_CD7-Surface Lighting Systems PROCEDURE TO INSTALL TANDEM MOUNT FIXTURE Step 1. Be Sure Electrical Power Is Off Step 2. Remove End Covers Step 3. Tandem Mount Fixtures connections. Step 4. Replace Reflectors 8-32 HEX NUT END COVER 10-24 HEX NUTS END PLATE 10-24X1/2”...
