Lightolier Lytespan 8259WH Specification

Page 1 of 2
Ordering Information
Catalog No.
8259WH
8259BK
Features
1. Lytespan Attachment Fitting: molded polycarbonate. Integral color. Fitting
twists onto track and locks in place.
2. Movable Brass Contact: extends for 2nd circuit in Advent
3. Lamp Retainer: silicone Rubber. Temperature range -- 65°F to +600°F.
Hardness 50 durometer. Integral color.
4. Trunion Mounting: permanently tensioned with internal spring washer. 90°
stop (UL requirement).
5. Push Tab: integral to fitting unit. Detaches unit.
6. Pivot Mounting: permanently tensioned, 350° stop for horizontal
adjustment.
7. Fitting Housing: die-cast aluminum.
8. Wire Form Ring: 1/4" Dia. formed steel rod. Chrome plated.
9. Socket Cover: molded Valox . Integral color. Matte finish.
®
Electrical
Porcelain socket, medium base, nickel plated screw shell. No. 18 braided SF-1
leads with a silicone sleeving.
Options & Accessories
4 3/4" Beam Smoother, Beam Elongator, Louver and Barndoors. All require
Accessory Holder 8594.
(See Lightolier Specification Sheets 8591, 7559, 7558, 7557 and 8542).
Lytespan
Mounting
All Lytespan
Track Systems
Finish
All painted finishes baked enamel.
Labels
™ Lytespan Track.
UL, I.B.E.W.
Valox
Advent
Lightolier
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
® Track Lighting System
Finish
Matte White
Matte Black
® is a registered trademark of General Electric.
™ is a registered trademark of Lightolier.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
a Genlyte Thomas Company
8259WH
Par-Tech ™
Lamps
PAR38, 150W Max.
(Including Cool Beam)
90W Max. with accessories
Type:
www.lightolier.com
Lasso 38
