Lightolier ProSpec 37075 Specification

Page 1 of 1
5/16 in
[8 mm]
2

Ordering Information

Catalog Number

Finish

37075WH White
37075BK Black

Features

1. Track Attachment Fitting
2. Locking Lever: Steel pin locks and detaches contact housing to track.
3. Clamping Knobs: Rotation of clamping knobs secure steel clamp to track.
4. Steel Clamping Toggles: 1/8" thick plated steel with 1/4 – 20 thread
secures fixture mechanically to track.
5. Electrical Post: .20 x .032 thick brass contacts enclosed in a high
temperature thermoplastic insulator.
6. 4" Round Junction Box: Die cast aluminum cavity volume is 17.8 cubic
inches.
7. Adapter Wires: (2) 18 ga, strand, 600V 200 C
8. Ground Wire: 18ga, strand, 600V 200 C
Finish
All painted finishes are baked enamel.

Mechanical

Max load, 30 lbs Max height of fixture is 35".
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • B0609
ProSpec
6 in
[152 mm]
4 3/16 in
[107 mm]
4
3
1 9/16 in
[40 mm]
7
4 1/4 in
[108 mm]
Mounting
ProSpec 277V Track Systems, ceiling mount only.

Electrical

Electrical ratings of adapter 277V 60 Hz 2 Amps

Labels

U.L. Listed
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
277V Track Lighting
™
Junction Box Pendant Adapter
1
4
6
8
4 1/2 in
[114 mm]
Type:
37075
5
