Lightolier Lytecaster 330X Specification

Page 1 of 2
4 1/2"
Complete fixture consists of Reflector Trim & Frame-in Kit. Select each separately
Reflector Trim
330BKX Black Paint
330WHX White Paint
Features
1. Housing: 25ga galvanized steel.
1. Residence Mounting Clip: Factory-installed; zinc plated spring steel;
free-hand installation.
2. Flange Housing: Cold rolled steel 22ga.
3. Adjustable Lampholder Support: 27ga. steel; Rotates 358˚ horizontally
and 0˚ to 30˚ vertically.
4. Mounting Clips (2): 24ga. spring steel, zinc plated. Provide easy snap-in /
snap-out action.
Frame-In Kit
Note : For complete Frame-In Kit specifications, see 300 frame
specification sheets
Lytecaster Recessed Downlighting
1/8"
Frame-In Kit
REMODELER
NON-IC
IC
AIR SEAL/IC
3 3/4" (95mm) aperture Gimbal ES/ESD16
2 3/4"
4 1/2"
Face Plate
300ESX
302ESX
302ESICX
302ESAICX
Labels:
CSA , UL Suitable for damp and wet locations.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte company
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
© 2012 Genlyte Group LLC • C0208
330X
1"MAX
Lamp
50W ES/ESD16 (GZ10)
50W ES/ESD16 (GZ10)
50W ES/ESD16 (GZ10)
50W ES/ESD16 (GZ10)
Type:
www.lightolier.com
