Catalog No. Finishes
8320WH
Matte White
8320BK
Matte Black
8320AL
Aluminum
General Description
The minimal silhouette of the die-cast ring houses the lamp. Lightoliers unique
"Cool-Grip"
™
aiming system incorporates a bold silicone rubber band which sur-
rounds the lighting element and allows you to aim the fixture even when hot.
Integral cross-blade louver provides glare reduction and holds one accessory.
Lamps are slightly regressed to provide better cut-off than typically found in
par rings.
Finish
All painted finishes baked enamel.
Electrical
Porcelain socket, medium base, nickel plated screw shell. No. 18 braided
SF-1 leads with silicone sleeving.
Labels
UL; I.B.E.W.; cUL
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • C0711
Mounting
Lamp
All Lytespan Track
PAR20 50W Max.
Systems
Lytespan
Track Lighting
®
Accessories
AF25 Series
ADF25 Series
AL25 Series
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
8320
Sof-Tech
Ring PAR20
®
Type:
