Lightolier Lytecaster 375X Specification

Page 1 of 2
4 5/8"
Complete fixture consists of Reflector Trim & Frame-In Kit. Select each separately
Reflector Trim
375BKX Black Phenolic Step Baffle and White Flange
375WHX White Phenolic Step Baffle and White Flange
Features
1. Housing: 25ga. galvanized steel.
2. Residence Mounting Clip: Factory-installed; zinc plated spring steel; free-
hand installation.
3. Flange: Die-cast aluminum .060" (1.5mm) thick ; white finish.
4. Baffle: Molded Phenolic. Available in molded black or white.
5. Lampholder Support: 27ga. steel.
6. Mounting Clips (3): 24ga. spring steel, zinc plated. Provide easy
snap-in /snap-out action.
7. Lamp Guard: 1 3/4" (45mm) dia. borosilicate glass.
Frame-In Kit
Note: For complete Frame-In Kit specifications,
see 300 frame specification sheets.
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2012 Philips Group • G0212
Lytecaster Recessed Downlighting
1/8"
Frame-In Kit
Remodeler
Remodeler
Remodeler
Non-IC
Non-IC
Non-IC
IC
IC
Air Seal / IC
Air Seal / IC
Air Seal / IC
3 3/4" (95mm) Aperture Basic Baffle MR16 & ES/ESD16
3"
4 1/2"
300MRSPX
3401MREX
300ESX
302MRSPX
302MREX
302ESX
302MRIC9SPX
302ESICX
302MRAICSPX
302MRAICEX
302ESAICX
Labels
CSA, UL Suitable for damp locations.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
375X
1" MAX
Lamp
50W MR16
50W MR16
50W ES/ESD16 (GZ10)
50W MR16
50W MR16
50W ES/ESD16 (GZ10)
50W MR16
50W ES/ESD16 (GZ10)
50W MR16
50W MR16
50W ES/ESD16 (GZ10)
Type:
