Lightolier Lytecaster 378X Specification

Page 1 of 2
Complete fixture consists of Reflector Trim & Power Pack. Select each separately.
Reflector Trim
378STX
Stainless Steel Plated
378WHX White Paint
378BKX Black Paint
Features
1. Flange: Die-cast aluminum .070" (2mm) thick.
2. Elbow Housing: Die-Cast aluminum; provides 358° horizontal rotation and
0° to 70° vertical adjustment. Retracts to provide fully recessed downlight.
85° vertical adjustment. Retracts to provide fully recessed downlight.
3. Mounting Clips (2): 24ga. spring steel, zinc plated. Provide easy snap-in /
snap out action.
4. Lamp Guard: 1 3/4" (45mm) dia. borosilicate glass.
Frame-In Kit
Note: For complete Frame-In Kit specifications, see 300 frame specification
sheets.
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2012 Philips Group • D0212
Lytecaster Recessed Downlighting
1/4"
7-3/8"
(6mm)
(187mm)
3 3/4" (95mm) Aperture Adjustable Elbow MR16
1-1/8" MAX.
(29mm)
70°
4-1/2"
(114mm)
Frame-In Kit
Remodeler 300MRSPX
Remodeler 3401MREX
Remodeler 303MRE*
Non-IC 302MRSPX
Non-IC 302MREX
IC 302MRIC9SPX
IC 302MRIC7SPX
Airseal / IC 302MRAICSPX
Airseal / IC 302MRAICEX
* Certified for wall application with 303MRE with 37W MR16
Labels
CSA, UL Suitable for damp locations.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
378X
Lamp
50W MR16
50W MR16
37W MR16
50W MR16
50W MR16
37W MR16
37W MR16
50W MR16
50W MR16
Type:
