Lightolier Lytecaster 372X Specification

Page 1 of 2
4 1/2"
Complete fixture consists of Reflector Trim & Frame-In Kit. Select each separately
Reflector Trim
372CHX
Chrome Baffle and White Flange
372WHX White Baffle and Flange
Features
1. Housing: 25ga galvanized steel.
1. Residence Mounting Clip: Factory-installed ; zinc plated spring steel ;
free-hand installation.
2. Flange: Die-cast aluminum .060" (1.5mm) thick ; white finish.
3 Cone: 18ga. aluminum.
4. Adjustable Lampholder Support: 27ga. Steel
5. Mounting Clips (3): (3):24ga. spring steel, zinc plated.
Provides easy snap-in /snap-out action.
6. Lamp Guard: 1 3/4" (45mm) dia. borosilicate glass.
Frame-In Kit
Note: For complete Frame-In Kit specifications,
see 300 frame specification sheets
Accessories
Square Face Plate
300SQWH White
300SQBK Black
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • I0711
Lytecaster Recessed Downlighting
3/16"
Frame-In Kit
Remodeler
Remodeler
Remodeler
Non-IC
Non-IC
Non-IC
IC
IC
IC
Air Seal / IC
Air Seal / IC
Air Seal / IC
3 3/4" (95mm) aperture Cross Baffle MR16 & ES/ESD16
2 7/8"
4 1/2"
300MRX/300MRSPX
3401MREX
300ESX
302MRX/302MRSPX
302MREX
302ESX
302MRIC7X/302MRIC7SPX
302MRIC9X/302MRIC9SPX
302ESICX
302MRAICX/302MRAICSPX
302MRAICEX
302ESAICX
Labels:
CSA , UL (Suitable for damp locations.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
372X
1"MAX
Lamp
50W MR16
50W MR16
50W ES/ESD16
50W MR16
50W MR16
50W ES/ESD16
50WMR16
50W MR16
50W ES/ESD16
50W MR16
50W MR16
50W ES/ESD16
Type:
