Lightolier 1050SQDL_3D Specification

3 Dimensional Supplement
For complete details please see specification sheet
Adobe Reader 7.0 or above is required to fully utilize Lightolier's 3D PDF file. You can download the latest free Adobe Reader at www.adobe.com.
Complete Fixture consists of Frame-In Kit and Reflector Trim. Select each separately.
Xceed Compact Fluorescent Lensed Square Reflector Trims
Lightolier is a Philips group brand
Downlight
1050SQDLWB
White Baffle with White Flange
1050SQDLCDW
Clear Diffuse with White Flange
1050SQDLCDP
Clear Diffuse with Clear Diffuse Flange
1050SQDLWDW
Warm Diffuse with White Flange
1050SQDLWDP
Warm Diffuse with Warm Diffuse Flange
Lensed Recessed CFL Downlighting
Click on the image below to launch the Acrobat 3D toolbar. Once the toolbar
appears make a selection and begin exploring the three-dimensional model.
Compatible Xceed Frame-In Kits
(See Individual Frame-In Kit Specification Sheets)
Catalog No.
1050SQ13ES*
1050SQ18ES*
1050SQ26ES*
1050DSQ26ES*
*All frames come standard with preset mounting screws and
a 2700K lamp. Models are available with preset nails and/or a
3500K lamp. (13ES = 2700K only). Simply add an N and/or 35 to
the end of the model number for those options.
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2008 Philips Group • A1008
1050SQDL_3D
5" Square Horizontal Lensed, CFL, Reflector Trim
Installation Type
IC Airseal ® 120v
IC Airseal 120v
®
IC Airseal 120v
®
IC Airseal Energy Star
®
Dimming 120V
Lamping
13w Triple
18w Triple
26w Triple
26w Triple
®
