4. Remove screws "2" and "3" (Figure 6 - 7) from the shielding
plate, and lift the plate up off the computer.
5. Locate the Memory sockets "1" and "2" (Figure 6 - 8).
3
6. If there is a module currently installed which needs to be
upgraded/replaced then remove it.
7. Gently pull the two latches ("3" and "4" in Figure 6 - 8) on the
memory socket toward the sides of the computer, as indicated
in Figure 6 - 8.
1
2
4
Upgrading The System Memory 6 - 13
Upgrading The Computer
Contact Warning
Be careful not to touch
the metal pins on the
module's connecting
edge Even the clean-
est hands have oils
which can attract parti-
cles, and degrade the
module's perform-
ance.
Figure 6 - 8
Memory Sockets
6
