User's Manual
Warning
Before removing
the HDD, please
check with your
dealer to find out
if this will VOID
your warranty.
4
4 - 2

Replacing the HDD

1) Remove the HDD along with its case from the computer (refer to Remov-
ing the HDD on pages 2-8 to 2-9 for details).
2) Remove the two screws on the HDD connector board.
3) Gently disconnect the HDD connector board from the HDD being careful
not to bend any pins.
4) Remove the two screws on each
side of the case.
5) Slowly remove the
HDD from the case.
6) Place a new HDD into
the case.
7) Hold the HDD firmly
in place with two
screws on each side.
HDD case
HDD
Connector board
figure 4-1
