Summary of Contents for Elo TouchSystems 1524L Series
- Page 1 Touchmonitor User Guide For 15" LCD Desktop Touchmonitors and Non-Touchmonitors 1524L Series Auto Enter Menu/Exit Revision B...
-
Page 2: User Guide
User Guide 15" LCD Desktop Touchmonitor 1524L Series Revision B P/N 008549... -
Page 3: Trademark Acknowledgments
Elo TouchSystems. Disclaimer The information in this document is subject to change without notice. Elo TouchSystems makes no representations or warranties with respect to the contents hereof, and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose. Elo TouchSystems reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Elo TouchSystems to notify any person of such revisions or changes. -
Page 5: Table Of Contents
Table of Contents Chapter 1 Introduction Product Description ....7 Precautions ....7 About the Product . -
Page 7: Product Description
Product Description Your new touchmonitor combines the reliable performance of touch technology with the latest advances in LCD display design. This combination of features creates a natural flow of information between a user and your touchmonitor. This LCD monitor incorporates 15” color active matrix thin-film-transistor (TFT) liquid crystal display to provide superior display performance. -
Page 8: About The Product
About the Product Your LCD Desktop Touchmonitor is a 15” XGA TFT color display with the following features: • The internal microprocessor digitally controls auto-scanning. For horizontal scan frequencies between 31.5 KHz and 60.2 KHz, and vertical scan frequencies between 56.3 Hz and 75.0 Hz. In each frequency mode, the microprocessor-based circuitry allows the monitor to function at the precision-of a fixed frequency. -
Page 9: Installation And Setup
This chapter discusses how to install your LCD touchmonitor and how to install the driver software. Unpacking Your Touchmonitor Check that the following 7 items are present and in good condition: LCD monitor Power cable US/Canada NSTALLATION AND HAPTER Serial cable European power cable USB Cable H A P T E R... -
Page 10: Product Overview
Product Overview Main Unit Rear View 2-10 U s e r G u i d e... -
Page 11: Touch Interface Connection
Touch Interface Connection Before connecting the cables to your touchmonitor and PC, be sure that the computer and touchmonitor are turned off. Connect one end of the power cord to the monitor and the other end to the outlet. Connect one end of the video cable to the rear side of computer and the other to the LCD monitor. -
Page 12: Installing The Driver Software
Installing the Driver Software Elo TouchSystems provides driver software that allows your touchmonitor to work with your computer. Drivers are located on the enclosed CD-ROM for the following operating systems: • Windows • Windows 2000 • Windows Me • Windows 98 •... -
Page 13: Installing The Serial Touch Driver
Installing the Serial Touch Driver Installing the Serial Touch Driver for Windows XP, Windows 2000, Me, 95/98 and NT4.0 For Windows 2000 and NT 4.0 you must have administrator access rights to install the driver. 1 Insert the Elo CD-ROM in your computer's CD-ROM drive. 2 If the AutoStart feature for your CD-ROM drive is active, the system automatically detects the CD and starts the setup program. -
Page 14: Installing The Serial Touch Driver For Ms-Dos And Windows 3.1
Installing the Serial Touch Driver for MS-DOS and Windows 3.1 You must have a DOS mouse driver (MOUSE.COM) installed for your mouse if you wish to continue using your mouse along with your touchmonitor in DOS. To install Windows 3.x and MS-DOS from Windows 95/98, follow the directions below: Insert the CD-ROM in your computer’s CD-ROM drive. -
Page 15: Installing The Usb Touch Driver R
Browse to select the \EloUSB directory on the Elo CD-ROM. 4 Choose Next. Once the Elo TouchSystems USB touchscreen driver has been detected, choose Next again. 5 You will see several files being copied. Insert your Windows 98 CD if prompted. - Page 16 2-16 U s e r G u i d e...
-
Page 17: Chapter 3 Operation
H A P T E R PERATION HAPTER About Touchmonitor Adjustments Your touchmonitor will unlikely require adjustment. Variations in video output and application may require adjustments to your touchmonitor to optimize the quality of the display. For best performance, your touchmonitor should be operating in native resolution, that is 1024x768 at 60k-75 Hz. -
Page 18: Front Panel Controls
Front Panel Controls Auto Control Power Switch Power LED Menu/Exit Enter Auto Enable/Disable 3-18 U s e r G u i d e Enter Menu/Exit Function Turns the display system power on or off. Lights up to indicate the power is turned ON. To enter or exit OSD manual. -
Page 19: Controls And Adjustment
Controls and Adjustment OSD Menu Functions To Display and Select the OSD Functions: Press Menu/Exit key to activate the OSD menu. Use + or - to move clockwise or counterclockwise through the menu. Then press the Enter key, the parameter will be highlighted when selected. Then use + or - to increase or decrease the value of the parameter, or make selection between different options. -
Page 20: Osd Control Options
OSD Control Options Control Brightness Contrast H-Position V-Position Phase Clock OSD H-Position OSD V-Position Color Balance Auto-Adjust Recall Defaults OSD Language Information 3-20 U s e r G u i d e Description Increases or decreases brightness Increases or decreases contrast Moves the screen left or right Moves the screen up or down Increases or decreases the snow noise of the image after auto... -
Page 21: Preset Modes
Preset Modes To reduce the need for adjustment for different modes, the monitor has default setting modes that are most commonly used as given in the table below. If any of these display modes are detected, the monitor automatically adjusts the picture size and centering. -
Page 22: Power Management System
Power Management System The monitor is equipped with the power management function which automatically reduces the power consumption when not in use into four power saving modes. Mode Standby Suspend We recommend switching the monitor off when it is not in use for a long time. The monitor automatically goes through the Power Management System (PMS) steps when it is idle. -
Page 23: Chapter 4 Troubleshooting
If you are experiencing trouble with your touchmonitor, refer to the following table. If the problem persists, please contact your local dealer or our service center. Solutions to Common Problems Problem The monitor does not respond after you turn on the system. Characters on the screen are dim The screen is blank Screen flashes when initialized... - Page 24 4-24 U s e r G u i d e...
- Page 25 The native resolution of a monitor is the resolution level at which the LCD panel is designed to perform best. For the LCD touchmonitor, the native resolution is 1024 x 768 for the 15 inch size. In almost all cases, screen images look best when viewed at their native resolution.
- Page 26 As an example, a SVGA resolution LCD panel has 800 pixels horizontally by 600 pixels vertically. Input video is also represented by the same terms. XGA input video has a format of 1024 pixels horizontally by 768 pixels vertically. When the input pixels contained in the video input format match the native resolution of the panel, there is a one to one correspondence of mapping of input video pixels to LCD pixels.
- Page 27 This manual contains information that is important for the proper setup and maintenance of your touchmonitor. Before setting up and powering on your new touchmonitor, read through this manual, especially Chapter 2 (Installation), and Chapter 3 (Operation). To reduce the risk of electric shock, follow all safety notices and never open the touchmonitor case.
-
Page 28: Care And Handling Of Your Touchmonitor
Care and Handling of Your Touchmonitor The following tips will help keep your touchmonitor functioning at the optimal level. • To avoid risk of electric shock, do not disassemble the brick supply or display unit cabinet. The unit is not user serviceable. Remember to unplug the display unit from the power outlet before cleaning. -
Page 29: Echnical Specifications
P P E N D I X ECHNICAL PECIFICATIONS HAPTER C-29... -
Page 30: Touchmonitor Specifications
Touchmonitor Specifications Model LCD Display Display Size Pixel Pitch Display Mode Max. Resolution Contrast Ratio Brightness Response Time Display Color Viewing Angle Input Signal Signal Connector Front Control Plug & Play Touch Panel (optional) Power Adapter Operating Conditions Storage Conditions Dimensions (HxWxD) Weight (Net) Certifications... -
Page 31: Accutouch Touchscreen Specifications
AccuTouch Touchscreen Specifications Mechanical Construction Positional Accuracy Touchpoint Density Touch Activation Force Surface Durability Expected Life Performance Optical Light Transmission (per ASTM D1003) Visual Resolution Haze (per ASTM D1003) Gloss (per ASTM D2457) Top: Polyester with outside hard-surface coating with clear or antiglare finish. -
Page 32: 15" Lcd Touchmonitor (Et1524L-Xxwc-1) Dimensions
15" LCD Touchmonitor (ET1524L-XXWC-1) Dimensions C-32 U s e r G u i d e... -
Page 33: Chapter 1 Regulatory Information
EGULATORY HAPTER I. Electrical Safety Information: A) Compliance is required with respect to the voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified herein will likely result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed. - Page 34 U s e r G u i d e This Information Technology Equipment (ITE) is required to have a CE Mark on the manufacturer’s label which means that the equipment has been tested to the following Directives and Standards: This equipment has been tested to the requirements for the CE Mark as required by EMC Directive 89/336/EEC indicated in European Standard EN 55 022 Class B and the Low Voltage Directive 73/23/EEC as indicated in European Standard EN 60 950.
- Page 35 "This application of this monitor is restricted to special controlled luminous environment. This screen surface trend to reflect annoying light of lamps and sunlight. To avoid these reflections the monitor should not be positioned in front of a window or directed to luminaries. The monitor is in compliance with Reflection Class III according to ISO 9241-7.
- Page 36 U s e r G u i d e...
-
Page 37: Introduction 7 Warranty
Except as otherwise stated herein or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the touchmonitors and components of the product is 1 (one) year. Seller makes no warranty regarding the model life of components. - Page 38 THESE REMEDIES SHALL BE THE BUYER’S EXCLUSIVE REMEDIES FOR BREACH OF WARRANTY. EXCEPT FOR THE EXPRESS WARRANTY SET FORTH ABOVE, SELLER GRANTS NO OTHER WARRANTIES, EXPRESS OR IMPLIED BY STATUTE OR OTHERWISE, REGARDING THE PRODUCTS, THEIR FITNESS FOR ANY PURPOSE, THEIR QUALITY, THEIR MERCHANTABILITY, THEIR NONINFRINGEMENT, OR OTHERWISE.
-
Page 39: Index
Numerics 15" LCD Touchmonitor (ET1524L-XXWC-1) Dimensions, 32 About the Product, 8 About Touchmonitor Adjustments, 17 AccuTouch Touchmonitor Specifications, 31 Brightness, 30 Care and Handling of Your Touchmonitor, 28 Certifications, 30 Cleaning Your Touchmonitor, 28 Construction, AccuTouch, 31 Contrast Ratio, 30 Controls and Adjustment, 19 Dimensions (HxWxD), 30 Display Angle, 22... - Page 40 Signal Connector, 30 Solutions to Common Problems, 23 Storage Conditions, 30 Surface Durability, AccuTouch, 31 SVGA, 25 SXGA, 25 Technical Specifications, 29 Touch Activation Force, AccuTouch, 31 Touch Interface Connection, 11 Touch not working, 23 Touch Panel (optional), 30 Touchmonitor Safety, 27 Touchmonitor Specifications, 30 Touchpoint Density, AccuTouch, 31 Troubleshooting, 23...
