Elo TouchSystems 1515L User Manual

15” lcd desktop touchmonitor
Hide thumbs Also See for 1515L:
Table of Contents

Advertisement

Quick Links

See also: User Manual
(shown with optional Magnetic Stripe Reader)
Touchmonitor User Guide
1515L 15" LCD Desktop Touchmonitor
(Optional Magnetic Stripe Reader Available)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1515L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Elo TouchSystems 1515L

Summary of Contents for Elo TouchSystems 1515L

  • Page 1 (shown with optional Magnetic Stripe Reader) Touchmonitor User Guide 1515L 15” LCD Desktop Touchmonitor (Optional Magnetic Stripe Reader Available)

  • Page 2: User Guide

    Elo TouchSystems 15” LCD Desktop User Guide Revision G P/N 008612E Elo TouchSystems 1-800-ELOTOUCH www.elotouch.com...

  • Page 3: Trademark Acknowledgments

    TE to notify any person of such revisions or changes. Trademark Acknowledgments AccuTouch, Elo (logo), Elo TouchSystems, IntelliTouch, TE Connectivity, TE connectivity (logo) and TE (logo) are trademarks of the TE Connectivity Ltd. family of companies. Windows is a trademark of the Microsoft group of companies. Other product names mentioned herein may be trademarks or registered trademarks of their respective companies.

  • Page 4: Table Of Contents

    Main Unit ..............12 Technical Specifications ..........31 Rear View .............12 Touchmonitor Specifications ........32 Kensignton Lock..........13 15" LCD Touchmonitor (1515L) Dimensions....33 Installing the Touch Driver Software ......14 Installing the Serial Touch Driver (not applicable Regulatory Information to Acoustic Pulse Recognition and Projected-Capacitive monitor) ..............14...

  • Page 5: Introduction

    C H A P T E R NTRODUCTION Product Description Your new touchmonitor combines the reliable performance of touch technology with the latest advances in (LCD) display design. This combination of features creates a natural flow of information between a user and your touchmonitor. This LCD monitor incorporates a 15”...

  • Page 6: About The Product

    About the Product The 1515L LCD Desktop Touchmonitor is a 15” XGA TFT color display with the following features: • The internal microprocessor digitally controls auto-scanning. For horizontal scan frequencies between 31.5 KHz and 60.2 KHz, and vertical scan frequencies between 56.3Hz and 75.0 Hz.

  • Page 7: Installation And Setup

    C H A P T E R NSTALLATION AND ETUP This chapter discusses how to install the 1515L LCD touchmonitor and the driver software. Unpacking Your Touchmonitor Check that the following items are present and in good condition: LCD monitor...
  • Page 8 Power cable for European models Europe/VDE power cable Power cable for Japan models Japanese/PSE power cable Adapter/Terminal Power cable for Asia models China/CCC power cable Taiwan/BSMI power cable Korea/KC power cable Power cable for Worldwide models USA/UL Power cable Europe/VDE power cable 2-10 User Guide...

  • Page 9: Touch Interface Connection

    Touch Interface Connection Note: Before connecting the cables to your touchmonitor and PC, be sure that the computer and touchmonitor are turned off. Power Cord USB Cable Serial Cable Video Cable For APR, Projected-Capacitive and IntelliTouch Plus model only Power Cord USB Cable Video Cable 1.

  • Page 10: Product Overview

    Product Overview Product Overview Main Unit Main Unit Rear View Kensington Lock The Kensington lock is a security device that prevents theft. To find out more about this security device, go to http://www.kensington.com. 2-12 User Guide...

  • Page 11: Installing The Driver Software

    Installing the Driver Software Elo TouchSystems provides driver software that allows your touchmonitor to work with your computer. Drivers are located on the enclosed CD-ROM for the following operating systems: • Windows 7 • Windows Vista • Windows XP • Windows 2000 •...

  • Page 12: Installing The Touch Driver Software

    Installing the Serial Touch Driver (not applicable to Acoustic Pulse Recognition and Projected-Capacitive monitor) Installing the Serial Touch Driver for Windows 7, Windows Vista, Windows XP, Windows 2000, 98/95, ME and NT4.0. NOTE: For Windows 2000 and NT4.0 you must have administrator access rights to install the driver. Make sure the serial connector (RS232) is plugged into the monitor and an open com port on the PC.

  • Page 13: Installing The Serial Touch Driver For Windows 3.1 And Ms-Dos

    Installing the Serial Touch Driver for Windows 3.1 and MS-DOS You must have a DOS mouse driver (MOUSE.COM) installed for your mouse if you wish to continue using your mouse along with your touchmonitor in DOS. To install Windows 3.x and MS-DOS touch driver from Windows 98/95, follow the directions below: 1 Insert the CD-ROM in your computer’s CD-ROM drive.

  • Page 14: Installing The Usb Touch Driver

    Installing the USB Touch Driver Installing the USB Touch Driver for Windows 7, Windows Vista, Windows XP, Windows 2000, ME and Windows 98. 1 Insert the Elo CD-ROM in your computer’s CD-ROM drive. If Windows 2000 or Windows 98 starts the Add New Hardware Wizard, do the following: 2 Choose Next.

  • Page 15: Installing Apr Usb Touch Driver For Windows 7, Windows Vista And Windows Xp

    Installing APR USB Touch Driver for Windows 7, Windows VISTA and Windows XP Insert the Elo CD-ROM in your computer’s CD-ROM driver. Follow the directions on the screen to complete the APR 3.1 driver setup for your version of Windows. Do not plug USB cable until software is fully loaded. When finished, plug USB cable and alignment data is transferred.

  • Page 16: Operation

    C H A P T E R PERATION About Touchmonitor Adjustments Your touchmonitor will not likely require adjustment. However, variations in video output and application may require adjustments to the touchmonitor to optimize the quality of the display. For best performance, your touchmonitor should be operating in native resolution, that is 1024 x 768 at 80k-75 Hz.

  • Page 17: Side Panel Controls

    Side Panel Controls Control Function 1 Menu/Exit Display/Exits the OSD menus. 1. Enter contrast of the OSD. 2. Increase value of the adjustment item. 3. Move OSD selection clockwise. 1. Enter brightness adjustment. 2. Decrease value of the adjustment item. 3.

  • Page 18: Controls And Adjustment

    Controls and Adjustment OSD Menu Functions To Display and Select the OSD Functions: 1. Press the Menu key to activate the OSD menu. 2. Use to move clockwise, or counterclockwise through the menu. Press the “Select” key, the parameter will be highlighted when selected. 3.

  • Page 19: Osd Control Options

    OSD Control Options Control Description Brightness Increases or decreases brightness Contrast Increases or decreases contrast H-Position Moves the screen left or right V-Position Moves the screen up or down Phase Increases or decreases the snow noise of the image after auto adjustment is made.

  • Page 20: Preset Modes

    Preset Modes To reduce the need for adjustment for different modes, the monitor has default setting modes that are most commonly used as given in the table below. If any of these display modes are detected, the monitor automatically adjusts the picture size and centering. When none of the mode is matched, the user can store their preferred modes in the user modes.

  • Page 21: Power Management System

    Power Management System The monitor is equipped with the power management function which automatically reduces the power consumption when not in use. Power Mode Consumption <30W Sleep <3W <1W It is recommend to switch the monitor off when it is not in use for a long time. NOTE: The monitor automatically goes through the Power Management System (PMS) steps when it is idle.

  • Page 22: Intellitouch Plus Touch Technology

    IntelliTouch Plus Touch Technology When connected to Windows 7 computers, the touchmonitor can report 2 simultaneous touches. The IntelliTouch Plus touchscreen can be re-calibrated to your displayed video image, if needed, through the Calibration function in the Elo driver control panel. The IntelliTouch Plus driver will only support multiple monitor if they are all using the IntelliTouch Plus touch technology.

  • Page 23: Projected-Capacitive Touch Technology

    Projected-Capacitive Touch Technology When connected to Windows 7 computers, the touchmonitor can report 2 simultaneous touches. When connected to Windows XP computers, the touchmonitor reports single touches. No additional drivers are required for this technology to work, it uses Windows HID drivers. No calibration is required for this technology.

  • Page 24: Troubleshooting

    C H A P T E R ROUBLESHOOTING If you are experiencing trouble with your touchmonitor, refer to the following table. If the problem persists, please contact your local dealer or the Elo service center. Solutions to Common Problems Problem Suggestion(s) The monitor does not respond 1.

  • Page 25: Appendix A Native Resolution

    A P P E N D I X ATIVE ESOLUTION The native resolution of a monitor is the resolution level at which the LCD panel is designed to perform best. For the LCD touchmonitor, the native resolution is 1024 x 768 for the 15 inch size.
  • Page 26 As an example, a SVGA resolution LCD panel has 800 pixels horizontally by 600 pixels vertically. Input video is also represented by the same terms. XGA input video has a format of 1024 pixels horizontally by 768 pixels vertically. When the input pixels contained in the video input format match the native resolution of the panel, there is a one to one correspondence of mapping of input video pixels to LCD pixels.

  • Page 27: Appendix B Touchmonitor Safety

    A P P E N D I X OUCHMONITOR AFETY This manual contains information that is important for the proper setup and maintenance of your touchmonitor. Before setting up and powering on your new touchmonitor, read through this manual, especially Chapter 2 (Installation), and Chapter 3 (Operation). 1 To reduce the risk of electric shock, follow all safety notices and never open the touchmonitor case.

  • Page 28: Care And Handling Of Your Touchmonitor

    Care and Handling of Your Touchmonitor The following tips will help keep your touchmonitor functioning at the optimal level. • To avoid risk of electric shock, do not disassemble the brick power supply or display unit cabinet. The unit is not user serviceable. Remember to unplug the display unit from the power outlet before cleaning.

  • Page 29: Technical Specifications

    A P P E N D I X ECHNICAL PECIFICATIONS C-31...

  • Page 30: Touchmonitor Specifications

    Touchmonitor Specifications Model 1515L LCD Display 15” TFT Active Matrix Panel Display Size 304.(H) x 228.(V) mm Pixel Pitch 0.297(H) x 0.297(V) mm Display Mode VGA 640 x 350 (70Hz) VGA 720 x 400 (70Hz) VGA 640 x 480 (60 / 72/ 75Hz)

  • Page 31: 15" Lcd Touchmonitor (1515L) Dimensions

    15" LCD Touchmonitor (1515L) Dimensions 60.4 C-33...
  • Page 32 EGULATORY NFORMATION I. Electrical Safety Information: A) Compliance is required with respect to the voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified herein will likely result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed.
  • Page 33 D) General Information to all Users: This equipment generates, uses and can radiate radio frequency energy. If not installed and used according to this manual the equipment may cause interference with radio and television communications. There is, however, no guarantee that interference will not occur in any particular installation due to site-specific factors.
  • Page 34 III. Agency Certifications The following certifications have been issued for this monitor: • Australia C-Tick • Canada cUL • Canada IC • China CCC (Asia models only) • China RoHS (Asia models only) • Europe CE • Japan VCCI • United States FCC •...

  • Page 35: Warranty

    ARRANTY Except as otherwise stated herein or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the touchmonitors and components of the product is 3 (three) years. Seller makes no warranty regarding the model life of components.
  • Page 36 THESE REMEDIES SHALL BE THE BUYER’S EXCLUSIVE REMEDIES FOR BREACH OF WARRANTY. EXCEPT FOR THE EXPRESS WARRANTY SET FORTH ABOVE, SELLER GRANTS NO OTHER WARRANTIES, EXPRESS OR IMPLIED BY STATUTE OR OTHERWISE, REGARDING THE PRODUCTS, THEIR FITNESS FOR ANY PURPOSE, THEIR QUALITY, THEIR MERCHANTABILITY, THEIR NONINFRINGEMENT, OR OTHERWISE.

  • Page 37: Product Information

    Check out Our Website! www.elotouch.com Get the latest... • Product information • Specifications • News on upcoming events • Press release • Software drivers • Touchmonitor Newsletter Getting in Touch with us To find out more about TE’s extensive range of Elo touch solutions, visit our website at www.elotouch.com or simply call the of- fice nearest you: North America Germany...
