Elo TouchSystems 1520 Quick Installation Manual

1
CABLE CONNECTIONS:
For easiest access, place monitor
screen-side down (place on soft
cloth to prevent scratches). Remove
two security screws with Alan
wrench (tool provided)
and slide cover off.
2
After cables are attached to the
Touchcomputer, slide cover on and
route cables through the opening in the
cable cover. Re-install security screws.
ON-SCREEN DISPLAY BUTTONS
www.elotouch.com
Quick Installation Guide
1520 15" All-in-One Touchcomputer
MENU: opens up the menu
ARROWS: navigate menu options
SELECT: choose menu options
POWER: turn system on/off
3
After all appropriate
cables are attached,
turn on power to the
Touchcomputer. Make
changes to the screen
image with the on-
screen buttons (see
below).
THE 1520 15"
TOUCHCOMPUTER
when combined with
an operating system
operates as a standard
PC. Touch the screen
to navigate, no mouse
is required.
