- Page 1 VuPoint™ M-Series Touchcomputer User Guide VuPoint™ M-Series LCD Multi-function Touchcomputer [19” model shown with optional accessories VuPoint M-Series]...
- Page 2 Elo Touch Solutions VuPoint™ M-Series Touchcomputer User Guide Multi-function Touchcomputer Revision B SW200069 1-800-ELOTOUCH (1-800-356-8682) www.elotouch.com VuPoint™ M-Series Touchcomputer User Guide ii...
- Page 3 Solutions to notify any person of such revisions or changes. Trademark Acknowledgments AccuTouch, Elo TouchSystems, Elo TouchSystems (logo), Elo, IntelliTouch, iTouch, Elo Touch Solutions Inc., Elo Touch Solutions, and Elo Touch Solutions (logo) are trademarks. Windows is a trademark of Microsoft Corporation.
-
Page 4: Warnings And Cautions
Warnings and Cautions Warning • Danger - Explosion hazard. Do not use in the presence of flammable anesthetics, and other flammable materials. • To prevent fire or shock hazards, do not immerse the unit in water or expose it to rain or moisture. •... - Page 5 Caution Power cord is used as a disconnection device. To de-energize equipment, disconnect the power cord. This unit must follow the national requirement and local state laws to dispose unit. Before connecting the cables to your Elo touchcomputer, make sure all components are powered OFF.
-
Page 6: Explanation Of Symbols
Explanation of Symbols: • This symbol alerts the user to important information concerning the operation and maintenance of this unit, which should be read carefully to avoid problems. • This symbol means DC Current. • This symbol means ON/OFF stand-by switch. •... - Page 7 Classification With respect to electrical shock, fire in accordance with ANSI/AAMI ES60601-1 and CAN/CSA- C22.2 No. 60601-1 E354528 07EG This touchcomputer is a Class I (GROUNDED) DEVICE. This touchcomputer is classified NO APPLIED PARTS EQUIPMENT. Protection against harmful ingress of water: INGRESS PROTECTION (IP21) This touchcomputer shall be classified as ORDINARY EQUIPMENT, not intended or evaluated for use in the presence of flammable anesthetic mixture...
- Page 8 European Standards and Classifications Standards: EN 60601-1-2: 2007 The EMC limits and test methods are referred to the following standards: Emission: Immunity CISPR 11: 2009+A1:2010 IEC 61000-4-2: 2008 EN55011: 2009+A1: 2010 IEC 61000-4-3: 2006+A1:2007+A2:2010 (Group 1, Class A) IEC 61000-3-2: IEC 61000-4-4: 2011 2005+A1:2008+A2:2009 IEC 61000-3-3;...
- Page 9 Guidance and manufacturer’s declaration-electromagnetic immunity for all EQUIPMENT AND SYSTEMS Guidance and manufacturer’s declaration-electromagnetic emissions The 15MX/19MX Touchcomputer for Healthcare Applications is intended for use in the electromagnetic environment specified below. The customer or the user of the 15MX/19MX Touchcomputer for Healthcare Applications should assure that it is used in such an environment.
- Page 10 Guidance and manufacturer’s declaration-electromagnetic immunity for all EQUIPMENT AND SYSTEMS Guidance and manufacturer’s declaration-electromagnetic immunity The 15MX/19MX Touchcomputer for Healthcare Applications is intended for use in the electromagnetic environment specified below. The customer, or the user of the 15MX/19MX Touchcomputer for Healthcare Applications, should assure that it is used in such an environment.
- Page 11 Guidance and manufacturer’s declaration-electromagnetic immunity for all EQUIPMENT AND SYSTEMS that are not LIFE-SUPPORTING Guidance and manufacturer’s declaration-electromagnetic immunity The 15MX/19MX Touchcomputer for Healthcare Applications is intended for use in the electromagnetic environment specified below. The user of the 15MX/19MX Touchcomputer for Healthcare Applications should assure that it is used in such an environment.
- Page 12 NOTE 1: At 80 MHz and 800 MHz, the higher frequency range applies. NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people. 3. Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy.
- Page 13 Recommended separation distances between portable and mobile RF communications equipment and the 15MX/19MX Touchcomputer for Healthcare Applications for all EQUIPTMENT AND SYSTEMS that are not LIFE-SUPPORTING The 15MX/19MX Touchcomputer for Healthcare Applications is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the 15MX/19MX Touchcomputer for Healthcare Applications can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications (equipment) and the 15MX/19MX Touchcomputer for Healthcare Applications as recommended below according to...
- Page 14 中国 RoHS 根据中国法律（电子信息产品污染控制管理办法），以下部分列出了该产品可能包含的 有毒和/或危险物质的名称和含量。 成分 有毒或危险物质和元素 名称 铅 (Pb) 汞 (Hg) 镉 (Cd) 六价 多溴 多溴 铬 苯酚 二苯 (Cr6+) (PBB) 醚 (PBDE) 塑料零件 金属零件 线缆和 电缆 组件 LCD 面板 触摸 屏 面板 PCBA 软件 （CD 等） O：指示该组件的所有同质材料中所含的这种有毒或危险物质的含量低于 SJ/T11363-2006 中的限制要求。 X：指示用于该组件的至少一种同质材料中所含的这种有毒或危险物质的含量高于...
-
Page 15: Table Of Contents
Table of Contents Chapter 1: Setup ..................1 Unpacking Your Touchcomputer ....................1 Calibrating the Touchscreen ......................17 Accessing the Hard Disk ........................18 Securing the M-Series AIO to a Mounting Bracket...............19 Chapter 2: Operation ................20 User Buttons...........................21 Using the Input/Output Panel......................24 Chapter 3: Options and Upgrades............ - Page 16 Regulatory Information ................35 Warranty ....................43 VuPoint™ M-Series Touchcomputer User Guide xvi...
-
Page 17: Chapter 1: Setup
C H A P T E R SETUP This chapter discusses how to set up and test your touchcomputer. For information on peripheral options, refer to Chapter 3, “Options and Upgrades.” Unpacking Your Touchcomputer Check that the following items are present and in good condition: VuPoint™... - Page 18 Windows XP Operating System ® ® Setting up Microsoft Windows XP If configured with an operating system, the initial setup of the operating system takes approximately 5-10 minutes. To set up the Microsoft Windows XP Operating System for the touchcomputer, connect a mouse and keyboard, turn on the touchcomputer by pressing the power button, and then follow the instructions on the screen.
- Page 19 Selecting the Language Windows uses English as the default language in menus and dialog boxes. You can change this language to suit your preferences at the screen below. Click Customize. The Regional and Language Options window appears. Select the Languages tab. The window shown below will appear. Select the desired language in the drop-down list labeled Language used in menus and dialogs.
- Page 20 Setting up the Computer Name and Password When the following window appears, you can change the Computer name and set an Administrator Password. Selecting the Time Zone When the following window appears, you can change the time zone, date, and time of the touchcomputer.
- Page 21 Network Settings Choose network setup as needed. Workgroup or Domain Setup Set a workgroup or join a domain. Select Next to finish. Windows setup completes the installation of the touchcomputer. VuPoint™ M-Series Touchcomputer User Guide 5...
- Page 22 Windows 7 Operating System Setting up Microsoft Windows 7 If configured with an operating system, the initial setup of the operating system takes approximately 5-10 minutes. To set up the Microsoft Windows 7 Operating System for the touchcomputer, connect a mouse and keyboard, turn on the touchcomputer by pressing the power button, and then follow the instructions on the screen.
- Page 23 Computer Name You can enter a new computer name if desired at this step. Microsoft License Terms If you agree with the license agreement, select “I accept the license terms” and select next. You cannot proceed without accepting. VuPoint™ M-Series Touchcomputer User Guide 7...
- Page 24 Set up Automatic Updates Select your Windows Updates setting preference. Date and Time Settings Set your date, time, and time zone settings and select next. VuPoint™ M-Series Touchcomputer User Guide 8...
- Page 25 Join a Wireless Network If wireless networking hardware is installed, you may join a wireless network at this time, select the wireless network you would like to connect to or select skip. Changing the Default Language of Windows 7 The method to load different languages in Windows 7 is as follows: 1.
- Page 26 3. Select Repair Your Computer. 4. The following menu will display after system loads, select Inject Language. VuPoint™ M-Series Touchcomputer User Guide 10...
- Page 27 Choose a language from the drop-down menu and click Inject Selected Language. 6. The below window will open, the process takes several minutes. When finished you will see confirmation of successful operation, press a key to exit. 7. Click Cancel to exit the Inject Language menu. 8.
-
Page 28: Recovering The Operating System
Recovering the Operating System If for any reason the touchcomputer’s operating system needs to be recovered to factory settings, you can apply a fresh install of your Windows operating system. PLEASE NOTE THAT ALL SETTINGS AND DATA WILL BE LOST DURING THIS PROCESS. - Page 29 4. Select Repair Your Computer Windows XP Menu: Windows 7 Menu: VuPoint™ M-Series Touchcomputer User Guide 13...
- Page 30 5. The following menu will display after system loads recovery utility. 6. Select Restore OS. Click Start button to recover your operating system. VuPoint™ M-Series Touchcomputer User Guide 14...
- Page 31 7. The following process will re-format the primary hard drive. Please back up your data before performing the recovery process. Confirm the warning message to continue. Once completed, click the Close button. VuPoint™ M-Series Touchcomputer User Guide 15...
- Page 32 9. The system will return to the main menu of the Elo Recovery Solution. Click the Exit button to restart your system. 10. The system will restart to Windows Setup, please refer to “Setting up Microsoft® Windows XP” for Windows XP and “Setting up Microsoft Windows 7”...
-
Page 33: Calibrating The Touchscreen
Calibrating the Touchscreen The touchscreen is pre-calibrated for accurate touch response. If for any reason the touchscreen needs to be recalibrated, right-click the Elo icon in the Taskbar and then click “Properties.” The following window opens. Calibration is not applicable on projective capacitive touchscreen NOTE: models. -
Page 34: Accessing The Hard Disk
Accessing the Hard Disk The hard disk is factory installed and located under the hard disk cover on the back of the unit. To access the hard drive remove the one screw holding the cover in place and remove the hard drive bracket to access the hard drive if necessary. Remove this screw to gain access to the hard disk. -
Page 35: Securing The M-Series Aio To A Mounting Bracket
Securing the M-Series AIO to a Mounting Bracket Use the four pre-tapped holes to secure the touchcomputer to the mounting bracket. The holes are designed to work with ISO metric M4 screws. Mounting screws are not included. Select the length screw that will provide adequate thread engagement to provide a reliable connection to the mounting bracket. -
Page 36: Chapter 2: Operation
C H A P T E R OPERATION This chapter describes the user button functions and I/O panel. All adjustments made to the user buttons are reset upon a power cycle to the touchcomputer. VuPoint™ M-Series Touchcomputer User Guide 20... -
Page 37: User Buttons
User Buttons User buttons are capacitive buttons. Use of finger or appropriate stylus is required for proper function. Power Button The power button function is different depending on the state of the touchcomputer. When the touchcomputer is booted into an operating system the power button will turn off and on the display backlight ... - Page 38 Screen Brightness Function Touch the screen brightness icon and use the +/- function adjustment icons to adjust the intensity. Current setting is displayed in-between +/- icons Audio Volume Function Touch the audio volume icon and use the +/- function adjustment icons to adjust the intensity. Current setting is displayed in-between +/- icons.
- Page 39 Function Lock Out Press and hold the night light icon and the plus adjustment icon for 3 seconds to lock out the function buttons. The icons will blink to confirm. When function lock out is enabled the function button illumination will disable, the function buttons will not respond in this state.
-
Page 40: Using The Input/Output Panel
Using the Input/Output Panel To access the input/output (I/O) ports, remove the cable cover on left side of the back of the unit. Install the I/O cables in the respective ports and use plastic cable ties to fasten the cables to the cable restraints shown below. Below are the I/O descriptions and location of the cable restraints: Note: As a safety precaution, always leave the cable cover attached when the system is powered on. -
Page 41: Chapter 3: Options And Upgrades
C H A P T E R OPTIONS AND UPGRADES Peripherals and Accessories The following peripherals and accessories are available for the M-Series touchcomputers. Magnetic stripe reader (MSR)* Wireless adapter Solid State Drive (SSD)* Webcam Barcode Scanner (2D area array)* ... -
Page 42: Magnetic Stripe Reader (Msr)
Magnetic Stripe Reader (MSR) A magnetic stripe reader (MSR) is an optional M-Series touchcomputer peripheral. Software application and drivers can be found on the web at: www.elotouch.com The MSR is a USB 2.0 device that reads all three data stripes on standard credit cards or driver’s licenses conforming to ISO/ANSI standards. -
Page 43: Wireless Card
Wireless Card A wireless adapter is a standard peripheral in the M-Series touchcomputer. Typical specifications for the wireless card are: Mini PCI-E module IEEE 802.11 a/b/g/n compliant Solid State Drive A solid state drive can be used to replace the original hard disk drive. This addition provides additional performance and is more mechanically reliable in harsh environments. -
Page 44: Barcode Scanner
5fps max @ 2.0 megapixels (1600x1200); Auto Frame Rate 24fps max @ VGA mode (640x480) Field Of View (FOV) 66° Focus Range 40cm ~ Infinity Barcode Scanner A 2D area array barcode scanner is an optional M-Series touchcomputer peripheral. The barcode scanner has integrated illumination and is compatible with many barcode symbologies. -
Page 45: Rfid Reader
RFID Reader An RFID reader is an optional M-Series touchcomputer peripheral. If installed, the RFID reader is capable of reading tags presented within a few centimeters of the symbol shown below on the front of M-Series touchcomputer. Compatible RFID standards are shown below: ... -
Page 46: Usb Handset
USB Handset A USB Handset is an optional M-Series touchcomputer peripheral. Included in the kit is a bracket and handset cradle that is required for correct function. Part number: E709063 TV Tuner A USB TV Tuner kit is available as an optional accessory. There are three options available. -
Page 47: Ac Cable
AC Cable A country specific AC cable can be used to replace the original AC Cable. There are two options. UK-HK 1.8 Meter AC cable Part number: E010063 Japan 1.8 Meter AC cable Part number: E520117 VuPoint™ M-Series Touchcomputer User Guide 31... -
Page 48: Chapter 4: Safety And Maintenance
C H A P T E R SAFETY AND MAINTENANCE Safety Important information regarding the proper setup and maintenance of your touchcomputer: To reduce the risk of electric shock, follow all safety notices and never open the touchcomputer case. ... -
Page 49: Care And Handling
Care and Handling The following tips help keep your touchcomputer functioning at the optimal level. Power down the unit and disconnect from the electrical mains prior to engaging in any cleaning activities. Take care to ensure no leakage of solution into the system. IF ANY FLUID INGRESS INTO THE UNIT DURING CLEANING IS SUSPECTED, DO NOT POWER ON THE UNIT. -
Page 50: Chapter 5: Technical Support
For touch computer specifications go to www.elotouch.com Not all operating systems or options are supported in all regions. Please NOTE: contact your local Elo TouchSystems representative for details. Technical Assistance There are two methods to obtain contact information for technical assistance on the touchcomputer: ... -
Page 51: Regulatory Information
REGULATORY INFORMATION I. Electrical Safety Information A) Compliance is required with respect to the voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified herein may result in improper operation, damage to the equipment, invalidation of warranty, or a fire hazard if the requirements are not followed. - Page 52 provided cords and cabling may compromise electrical safety or CE Mark Certification for emissions or immunity as required by the following standards: This Electronic Equipment is required to have a CE Mark on the manufacturer’s label which means that the equipment has been tested to the following Directives and Standards: This equipment has been tested to the requirements for the CE Mark as required by EMC 2004/108/EC and LVD 2006/95/EC indicated in European Standards EN55022,...
- Page 53 cord ground may increase RF emission levels and may also present a lethal shock hazard to the user.) If you need additional help, consult your dealer, manufacturer, or an experienced radio or television technician. Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 54 Exposure to radio frequency radiation The radiated output power of this device is far below the FCC radio frequency exposure limits. Nevertheless, the device shall be used in such a manner that the potential for human contact during normal operation is minimized. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20 cm (8 inches) during normal operation.
- Page 55 This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/EC: EN 60950-1: 2006+A11: 2009+A1: 2010+A12: 2011 Safety of Information Technology Equipment EN 50364: 2010 Limitation of human exposure to electromagnetic fields from devices operating in...
- Page 56 services; Part 17: Specific conditions for 2,4 GHz wideband transmission systems and 5 GHz high performance RLAN equipment This device is a wideband transmission system (transceiver), intended for use in all EU member states and EFTA countries, except in France and Italy where restrictive use applies.
- Page 57 Hierbij verklaart Elo Touch Solutions, Inc. dat het toestel 15MX/19MX Nederlands Touchcomputer in overeenstemming is met de essentiële eisen en de [Dutch] andere relevante bepalingen van richtlijn 1999/5/EG. Malti Hawnhekk, Elo Touch Solutions, Inc., jiddikjara li dan 15MX/19MX Touchcomputer jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti [Maltese] oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.
- Page 58 IV. Ingress Protection The 15MX/19MX Touchcomputer is designed to have an ingress protection rating of IP21 over the range of angles shown in the diagram below. VuPoint™ M-Series Touchcomputer User Guide 42...
- Page 59 WARRANTY Except as otherwise stated herein or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. With the exception of the negotiated warranty periods; the warranty for the touchcomputer and components of the product is 3 years.
- Page 60 THESE REMEDIES SHALL BE THE BUYER’S EXCLUSIVE REMEDIES FOR BREACH OF WARRANTY. EXCEPT FOR THE EXPRESS WARRANTY SET FORTH ABOVE, SELLER GRANTS NO OTHER WARRANTIES, EXPRESS OR IMPLIED BY STATUTE OR OTHERWISE, REGARDING THE PRODUCTS, THEIR FITNESS FOR ANY PURPOSE, THEIR QUALITY, THEIR MERCHANTABILITY, THEIR NONINFRINGEMENT, OR OTHERWISE.
- Page 61 19 options, adding, 25 box contents, 1 peripherals adding, 25 cables included, 1 phone number, Elo TouchSystems, 34, 46 calibration, 17 ports accessing, 24 certifications, 41, 42 regulatory information, 35 Changing Language of Windows 7, 9 Select a Language, 11...
-
Page 62: Product Information
www.elotouch.com Get the latest... Product information Specifications News on upcoming events Press release Software drivers Touchcomputer Newsletter Getting in Touch with Elo To find out more about the extensive range of Elo touch solutions, visit www.elotouch.com or simply call the office nearest you: North America Europe...
