Summary of Contents for TYAN Transport TA26 B2932

  • Page 1 Transport TA26 B2932 Service Engineer’s Manual...
  • Page 3 TYAN retains the right to make changes to product descriptions and/or specifications at any time, without notice. In no event will TYAN be held liable for any direct or indirect, incidental or consequential damage, loss of use, loss of data or other malady resulting from errors or inaccuracies of information contained in this document.
  • Page 4 Federal Communications Commission (FCC) Notice for the USA Compliance Information State- ment (Declaration of Conformity Procedure) DoC FCC Part 15: This device complies with part 15 of the FCC Rules Operation is subject to the following conditions: 1) This device may not cause harmful interference, and 2) This device must accept any interference received including inter- ference that may cause undesired operation.
  • Page 5 About this Manual This manual provides you with instructions on installing your Trans- port TA26 B2932. This manual is intended for experienced users and integrators with hardware knowledge of personal computers. This manual consists of the following parts: Provides an Introduction to the TA26 B2932 bare- Chapter 1: bone, packing list, describes the external compo- nents, gives a table of key components, and...
  • Page 6 SAFETY INFORMATION Before installing and using the TA26 B2932, take note of the follow- ing precautions: – Read all instructions carefully. – Do not place the unit on an unstable surface, cart, or stand. – Do not block the slots and opening on the unit, which are pro- vided for ventilation.

  • Page 7: Table Of Contents

    Chapter 1: Overview 1.1 About the TYAN Transport TA26 B2932 ....1 1.2 Product Models ........1 1.3 Features .
  • Page 8 3.4.2 Removing the Motherboard ......40 3.5 Replacing the Slim DVD-ROM ......41 3.6 Replacing the LED Control Board .

  • Page 9: Chapter 1: Overview

    TYAN is also proud to deliver the Transport TA26 B2932 in SAS flavor while supporting up to eight (8) hot-swap hard drives and one (1) slim DVD-ROM drive. The Transport TA26 B2932 uses TYAN’s latest tooling-made chassis featuring a...

  • Page 10: Features

    – D 660 x W423 x H 87 mm • Two (2) USB 2.0 ports • One 15-pin VGA port Motherboard • One 9-pin COM port • TYAN Thunder n3600M S2932 • Two RJ45 (Marvell 88E1121 PHY + • Extended ATX footprint (12” x 13”) nVIDIA MAC) Processors Front Panel Features •...
  • Page 11 Server Management • Automatic fan speed control • Chassis intrusion alert • Supports TYAN Server Management (TSM) • Optional TYAN SMDC M3291, IPMI v2.0 compliant remote server management kit Power Supply • EPS 12V, 2U, 600W with PFC for B2932T26W8H •...

  • Page 12: Unpacking

    1.4.1 Box Contents Component Description Industry standard 2U chassis, (8) hot-swap HDD bays TYAN Thunder n3600M S2932 motherboard (pre-installed) Slim DVD-ROM drive (pre-installed) LED and USB control board (pre-installed) EPS 12V, 2U, 600W PSU with PFC (pre-installed) (A) (B2932T26W8H models)

  • Page 13: Accessories

    If any items are missing or appear damaged, contact your retailer or browse to TYAN’s Web site for service: http://www.tyan.com. The Web site also provides information on other TYAN prod- ucts, plus FAQs, compatibility lists, BIOS settings, and more. 1 x TYAN Driver CD...
  • Page 14 FDD Rails Screw Pack FDD Power Cable Sliding Rail TYAN Logo Chapter 1: Overview...

  • Page 15: About The Product

    About the Product The following views show you the product. 1.5.1 System Front View Reset switch ID switch Power LED Power switch Warning LED HDD activity LED USB ports LAN LEDs ID LED HDD Tray DVD-ROM drive Power LEDs Hard Drive Bay x 8 HDD Tray Activity LEDs 1.5.2 System Rear View...

  • Page 16: Led Definitions

    1.5.3 LED Definitions Front Panel Color State Description Power Green Power ON Power OFF HDD Activity Amber Blinking HDD/DVD-ROM access activity No disk activity LAN1/LAN2/Linkage Green LAN linked Green Blinking LAN accessing No LAN linked Fail System fails Abnormal power off Normal Hot Swappable HDD Green...

  • Page 17: Motherboard Layout

    1.5.4 Motherboard Layout Chapter 1: Overview...

  • Page 18: Jumpers & Connectors

    IPMB Pin Header PW1/ PW2/ PW3 Power Connectors LCM Pin Header (for barebone use only) J39/ J63 TYAN Front Panel 2 Connector (for barebone use only) Front Panel USB2.0 Connectors Primary IDE Connector Front Panel Header SGPIO Header (for barebone use only)

  • Page 19: System Block Diagram

    1.5.6 System Block Diagram Chapter 1: Overview...

  • Page 20: Internal View

    1.5.7 Internal View FAN3 FAN2 FAN1 1. CPU2 Memory Slots 9. Eight (8) SAS/SATA HDD trays 2. CPU2 10. DVD-ROM Cable 3. Power Supply 11. System Fans (Right to Left: 4. Power Connector FAN1, FAN2, FAN3) 5. CPU1 Memory Slots 12.

  • Page 21: Chapter 2: Setting Up

    Chapter 2: Setting Up 2.0.1 Before You Begin This chapter explains how to install the CPU, CPU heatsink, memory modules, hard drives, and floppy drive. Instructions on inserting a PCI card are also given. Take note of the precautions mentioned in this section when installing your system.

  • Page 22: Precautions

    2.0.4 Precautions Components and electronic circuit boards can be damaged by discharges of static electricity. Working on a system that is connected to a power supply can be extremely dangerous. Follow the guidelines below to avoid damage to the Transport TA26 B2932 or injury to yourself. •...

  • Page 23: Installing Motherboard Components

    Installing Motherboard Components This section describes how to install components on to the motherboard, including CPU, memory modules and PCI card. 2.1.1 Removing the Chassis Cover Follow these instructions to remove the Transport TA26 B2932 chassis cover. 1. Turn the screw on the back side. Then slide the chassis cover in the direction of arrow.

  • Page 24: Installing The Cpu

    2.1.2 Installing the CPU Follow these instructions to install the CPU. 1. Remove the one screw securing the pre-installed air duct. 2. Remove the air duct and locate the two CPU socket on the motherboard. 3. Remove the cover on the CPU socket. Chapter 2: Setting Up...
  • Page 25 4. Lift up the CPU lever to unlock the socket. 5. Open the socket in the direction as illustrated. 6. Place the CPU in the CPU socket, ensuring that pin 1 is located as shown below. Chapter 2: Setting Up...
  • Page 26 7. Close the cover and press the CPU socket lever down to secure the CPU. 8. Take out the new heatsink from the plastic case as shown (A). Then remove the protective cover to reveal the pre- applied thermal grease (B). 9.

  • Page 27: Installing The Memory

    2.1.3 Installing the Memory Follow these instructions to install the memory modules on the motherboard. 1. Remove the one screw securing the pre-installed air duct. 2. Remove the air duct and locate the memory slots on the motherboard. 3. Press the memory slot locking levers in the direction of the arrows as shown below.
  • Page 28 4. Align the memory module with the slot. The module has indentations that align with notches in the slots. 5. Insert the memory module into the slot as shown below. When inserted properly, the memory slot locking levers lock automatically onto the indentations at the ends of the module.
  • Page 29 The following chart outlines the suggested rules for populating memory. Single CPU installed Dual CPU installed (CPU1 only) (CPU1 and CPU2) Population Option CPU1_DIMM0 CPU1_DIMM1 CPU1_DIMM2 CPU1_DIMM3 CPU1_DIMM4 CPU1_DIMM5 CPU1_DIMM6 CPU1_DIMM7 CPU2_DIMM0 CPU2_DIMM1 CPU2_DIMM2 CPU2_DIMM3 CPU2_DIMM4 CPU2_DIMM5 CPU2_DIMM6 CPU2_DIMM7 NOTE: 1.

  • Page 30: Installing Pci-E Cards

    2.1.4 Installing PCI-E Cards The TA26 B2932 has six PCI card slots: 1 x PCI card slot 2 x PCI-E card slots 3 x PCI-X card slots Follow these instructions to install any of the above kinds of add-in cards in your TA26 B2932 system. 1.
  • Page 31 3. Lift up the bracket. 4. Insert a PCI/PCI-E/PCI-X card into the appropriate slot. Secure the card with the screw you removed from the bracket. Chapter 2: Setting Up...

  • Page 32: Installing Hard Drives

    2.1.5 Installing Hard Drives The TA26 B2932 supports up to eight serial SAS/SATA hard drives. Follow these instructions to install a hard drive. 1. Press the locking lever latch in the direction shown by the arrow below. The latch will pop open. 2.
  • Page 33 4. Remove the base. 5. Place a hard drive into the drive tray. 6. Screw the hard drive in place using 4 HDD screws. 7. Reinsert the tray into the bay and press the locking lever to secure. Chapter 2: Setting Up...

  • Page 34: Installing A Floppy Drive

    2.1.6 Installing a Floppy Drive This section describes how to install a floppy disk drive in the TA26 B2932 if required. Follow these instructions to install a floppy disk drive in the TA26 B2932. 1. Remove the top, left hand drive tray from the TA26 B2932 as shown.
  • Page 35 The FDD rails each have a flat side which should be Note: against the body of the floppy drive when installed. There is also a spring catch mechanism on the right hand rail (when looking at the floppy disk drive from the front). 3.
  • Page 36 5. Connect the other end of the power cable to the connec- tor (J37) on the backplane. 6. Connect the other end of the supplied FDD cable to the FDD slot (J10) on the motherboard. To release the floppy disk drive from the drive bay, Note: you will need to press the release catch inside the chassis.

  • Page 37: Rack Mounting

    Rack Mounting After installing the necessary components, the Transport TA26 B2932 can be mounted in a rack using the supplied rack mounting kit. Rack mounting kit Sliding Rails x 2 Mounting Ears x 2 Screws Kit x 1 Mounting Brackets x 4 (pre-installed) 2.2.1 Installing the Server in a Rack Follow these instructions to mount the TA26 B2932 into an industry standard 19"...
  • Page 38 Attaching the Inner Rails to the Unit 7. Screw the handles to each side of TA26 B2932 as shown using two (2) M4L6, S10C screws (A) from the supplied screws kit. 8. Attach the inner rails both sides of the unit using nine (9) M4-L5 screws (C) on each side.
  • Page 39 Installing Outer Rails to the Rack 1. Adjust the outer rail to match the length of the unit. 2. Secure the outer rail to the rack using 2 brackets and M6 screws (B) for each side. Secure the mounting brackets from outside, not inside, of the rack.
  • Page 40 Rackmounting the Server 1. Draw out the middle rail to the latch position. 2. Lift the unit and then insert the inner slide rails into the middle rails. 3. Push the unit in and press the latch key. Chapter 2: Setting Up...
  • Page 41 4. Push the whole system into the rack. 5. Secure the mounting handles of the unit to the rack. To avoid injury, it is strongly recommended that two Note: people lift the TA26 B2932 into the place while a third person screws it to the rack.
  • Page 42 Chapter 2: Setting Up...

  • Page 43: Chapter 3: Replacing Pre-Installed Components

    Chapter 3: Replacing Pre-Installed Components Introduction This chapter explains how to replace pre installed compo- nents including the motherboard, LED control board, USB adapter board, HDD, and DVD-ROM drive, etc. Take note of the precautions in this section when installing your system.

  • Page 44: Precautions

    3.1.3 Precautions Components and electronic circuit boards can be damaged by static electricity. Working on a system that is connected to a power supply can be extremely dangerous. Follow the guidelines below to avoid damage to the Transport TA26 B2932 or injury to yourself. •...

  • Page 45: Disassembly Flowchart

    Disassembly Flowchart The following flowchart outlines the disassembly procedure. Rear Components DIMMs Chassis top cover CPU/heatsink assembly Mainboard PCI card Power supply Mainboard Front Components Chassis top cover PCBs DVD-ROM Control Board Backplane The Transport TA26 B2932 should be always Note: powered off before disassembly.

  • Page 46: Removing The Cover

    Removing the Cover Before replacing any parts you must remove the chassis cover. Follow these instructions to remove the cover of the Transport TA26 B2932 chassis cover. 1. Remove the screw on the back side. Then slide the chas- sis cover in the direction of arrow. 2.

  • Page 47: Replacing Motherboard Components

    Replacing Motherboard Components Follow these instructions to replace motherboard compo- nents, including the motherboard. 3.4.1 Disconnecting All Motherboard Cables Before replacing the motherboard or certain components, remove cables connected to the motherboard. Follow these instructions to remove all motherboard cabling. 1.

  • Page 48: Removing The Motherboard

    3.4.2 Removing the Motherboard After removing all of the aforementioned cables, follow these instructions to remove the motherboard from the chassis. 1. Remove the eight screws securing the motherboard to the chassis. 2. Remove the motherboard. Chapter 3: Replacing Pre-Installed Components...

  • Page 49: Replacing The Slim Dvd-Rom

    Replacing the Slim DVD-ROM Follow these instructions to replace the DVD-ROM. 1. Remove the FFC cable from the rear of the DVD-ROM drive. 2. Press the tab in the direction shown to release the DVD- ROM drive. 3. Push the DVD-ROM drive through the front of the TA26 B2932.
  • Page 50 4. Remove the two screws that secure DVD-ROM drive to the backplane. 5. Replace the DVD-ROM drive. 6. Secure the DVD-ROM to the backplane using two screws. Then replace the unit into the drive bay and con- nect the DVD-ROM FFC cable. Chapter 3: Replacing Pre-Installed Components...

  • Page 51: Replacing The Led Control Board

    Replacing the LED Control Board Follow these instructions to replace the LED control board. 1. Remove the screw securing the LED control board unit to the chassis. 2. Remove the connector cables from the backplane. 3. Slide back the LED control board bracket and lift free of the chassis.
  • Page 52 4. Remove the LED control board and USB cables from the LED control board and USB adapter board. 5. Remove the five screws securing the LED control board and USB adapter board to the bracket. 6. Release the LED control board and USB adapter board from bracket.

  • Page 53: Led Control Board Features

    3.6.1 LED Control Board Features S3 power switch SYSTEM HEADER S2 ID switch S1 reset switch D6 power LED D5 HDD LED D4 W/L LED D3 ID LED D2 LAN2 LED D1 LAN1 LED 3.6.2 LED Control Board Connector Pin Definitions JB1 2x12 Pin Output Connector LAN1 GR-LED + LAN1-LED -...

  • Page 54: Replacing The Backplane

    Replacing the Backplane Follow these instructions to replace the backplane in your TA26 B2932 system. 1. Remove all of cables connected to the backplane, includ- ing fan cables, DVD-ROM cables, LED control board cables, fan control cable, TYFP cable, USB cables, front panel LED cables, power cables, and SAS/SATA cables.
  • Page 55 2. Remove the ten screws to release the backplane. 3. Turn the locking keys at the base of the backplane as shown. 4. Pull out the backplane. 5. Place a new backplane in position and secure in place with the ten screws and locking keys released in step 2 and 3.

  • Page 56: M1220 Sas/Sata Backplane Features

    3.7.1 M1220 SAS/SATA Backplane Features Front View J35 2x7pin J13 29pin SAS J14 29pin SAS J15 29pin SAS J34 2x5pin LED J11 29pin SAS J12 29pin SAS J7 40pin cd-rom/B J33 2x12pin LED/B J5 2x5pin USB J36 2x7pin J8 29pin SAS J9 29pin SAS J10 29pin SAS Chapter 3: Replacing Pre-Installed Components...

  • Page 57: Rear View

    Rear View J1,J2,J3 big 4pin FAN1 4pin J25,J27,J29,J31 7pin secondary J6 TO J24,J26,J28,J30 CD-ROM 7pin primary FAN2 4pin J38 2x7pin tach and PWM J37 small 4pin FAN3 4pin J17,J19,J21,J23 J32 LED/B 7pin secondary J16,J18,J20,J22 7pin primary J4 USB OUT Chapter 3: Replacing Pre-Installed Components...

  • Page 58: M1220 Sas/Sata Backplane Connector Pin Definitions

    3.7.2 M1220 SAS/SATA Backplane Connector Pin Definitions J32, J33 2x12pin LED board connector LAN1 LED + (link/active) LAN1 LED - (link/active) Reserved Reserved LAN2 LED + (link/active) LAN2 LED - (link/active) Reserved Reserved Reserved Reserved ID-LED + ID-LED - W-LED + W-LED - M/B HDD LED + M/B HDD LED -...
  • Page 59 DIOR IORDY CSEL DMACK INTRQ IOCS16 PDIAG CS1FX CS3FX DASP Fan Signal Related Connector Pin Definitions The FAN signal naming is based on HW circuit Note: design only. It might be different from the system fan name. FAN1, FAN2, FAN3: 4-pin Fan connector VDD +12V TACH J1, J2 and J3 power big 4-pin connector...
  • Page 60 J4, J5 USB 2x5pin connector USB1 power + USB2 power + USB1 DATA - USB2 DATA - USB1 DATA + USB2 DATA + USB1 GND USB2 GND Key pin None J37 power small 4-pin connector +12V J36 HDD LED pin out PLED1 ALED1 ALED1 +...
  • Page 61 J35 HDD LED pin out PLED6 + ALED6 - ALED6 + PLED7 + ALED7 - ALED7 + PLED8 + ALED8 - ALED8 + None J38 2x7pin FAN tach and PWM pin out FAN1 tach Reserved FAN2 tach Reserved FAN3 tach Reserved Reserved Reserved...

  • Page 62: Replacing The System Fan

    Replacing the System Fan Follow these instructions to replace the cooling fans in your TA26 B2932 system. 1. Locate the fan connector on the backplane and unplug the fan cable as shown below. 2. Take the fan away from the chassis. 3.

  • Page 63: Replacing The Power Supply

    Replacing the Power Supply Follow these instructions to replace the power supply in your TA26 B2932 system. 3.9.1 Standard Power Supply 1. Remove the chassis cover. See “Removing the Cover” on page 38 for more details. 2. Detach the power cables from the motherboard and backplane.
  • Page 64 4. Remove the two screws attaching the power supply to the chassis interior and lift out the unit. 5. Lift the power supply free from the chassis. 6. Replace a new power supply into the chassis following the above steps in reverse. Chapter 3: Replacing Pre-Installed Components...

  • Page 65: Optional 1+1 Redundant Power Supply

    3.9.2 Optional 1+1 Redundant Power Supply If the optional 1+1 redundant power supply is fitted, either of the two units can be hot swapped. Follow these instructions to replace a single power unit with a redundant power supply unit. Before proceeding, remove the new redundant Note: power supply from its packaging.
  • Page 66 3. Screw the bracket to the rear of the power supply casing. 4. Insert the redundant power supply casing into the chas- sis, making sure it is aligned as shown. 5. Screw the casing to the chassis exterior. Chapter 3: Replacing Pre-Installed Components...
  • Page 67 6. Screw the casing to the chassis interior. 7. Fix the redundant power supply switch to the chassis rear window with two Hex #6-32 screws. 8. Insert the new power supply unit and secure by turning the locking screw. Chapter 3: Replacing Pre-Installed Components...
  • Page 68 9. Re-attach all power supply connector cables to the moth- erboard and backplane. Chapter 3: Replacing Pre-Installed Components...

  • Page 69: Appendix I: Bios Differences

    Appendix I: BIOS Differences The BIOS of B2932 is similar to the BIOS of S2932. There is only one menu different. See the following for the differences in BIOS between B2932 and S2932. For a complete review of S2932 BIOS, refer to the motherboard manual. B2932 Advanced/Hardware Health Configuration BIOS Setup Utility Advanced...
  • Page 70 S2932 Advanced/Hardware Health Information BIOS Setup Utility Advanced Hardware Health Configuration Enables Hardware Health Monitoring Device. H/W Health Function [Enabled] CPUFAN1, 2 FAN1,2 PWM Control [Disabled] FAN3, FAN4, FAN5 PWM Control [Disabled] FAN Fail LED Indicator [Disabled] Hardware Health Event Monitoring Select Screen Select Item Mainboard Voltages Report...

  • Page 71: Appendix Ii: Cable Connection Tables

    Appendix II: Cable Connection Tables SAS/SATA Cable Table 1: TA26 B2932 Model M1220 SAS/SATA Connects to Motherboard Backplane SAS0 SAS1 SAS2 SAS3 SAS4 SAS5 SAS6 SAS7 FAN Cable Table 2: System Fan to Backplane M1220 SAS/SATA System Fan Connects to Backplane Fan 1 FAN1 4-pin connector...
  • Page 72 Power Supply Cable Table 3: Power Supply to Motherboard Power Supply Connects to Motherboard P1 24-pin power cable PW1 24-pin connector P2 8-pin power cable PW2 8-pin connector P3 4-pin power cable PW3 4-pin connector Table 4: Power Supply to Backplane M1220 SAS/SATA Power Supply Connects to...
  • Page 73 Table 7: System Internal LED Cables to Backplane M1220 SAS/SATA Connects to TA26 B2932 System Backplane (Front side) J34 2x5pin LED System Internal J35 2x7pin LED LED Cables J36 2x7pin LED Table 8: DVD-ROM Related Cable M1220 SAS/SATA Connects to DVD-ROM Backplane Backplane DVD-ROM Backplane...

  • Page 74: Appendix Iii: Installing The Smdc Card

    Appendix III: Installing the SMDC Card The following provides you with the information on installing M3291 SMDC card into a PCI or PCI-X slot in your TA26 B2932 system. 1. Locate the TX/RX and RTS/CTS switch jumpers (J3 and J4) on the SMDC card, and place the jumper caps to close pins 5-8.
  • Page 75 4. Unscrew the bracket from the slot as shown. Lift up the bracket. 5. Connect the other end of SMDC cable to the SMDC con- nector (J18) on the motherboard. 6. Place the SMDC card in the PCI or PCI-X slot as shown.
  • Page 76 7. Secure the PCI bracket with the screw you removed from the card slot cover. Cable Connection Table SMDC Card (M3291) Connects to Motherboard J1 connector J17 SMDC connector...

  • Page 77: Appendix Iv: Fru Parts Table

    Appendix IV: FRU Parts Table Model Item Picture Quantity Description Number TYAN S2932WG2 Motherboard S2932WG2NR Motherboard Chassis unit, Chassis Unit CCHA-0090 Maryang2000 Top cover, Mitac CCCV-0020 Maryang2000 Chassis & Metal Parts HDD Carrier, CHDT-0030 External 80x80x38mm, CFAN-0250 FFC0812DE-7N20 60x60x38mm, CFAN-0200...
  • Page 78 Model Item Picture Quantity Description Number PCB ASSY; 2U, Storage 8BAY, SAS M1220 Backplane BACKPLANE M1220 Heat Sink & CHSK-0280 CPU Cooler Cooler AIR_DUCT; Air Duct CADT-0160 PC+ABS, for TA26 R2W-5600P3V, 600W 1+1 CPSU-0180 redundant, for B2932T26W8HR Power Supply P2M-6600P, 600W Single Power CPSU-0170 Supply, for...
  • Page 79 Model Item Picture Quantity Description Number HDD LED Cable CCBL-0090 Assembly, 10-pin, 200mm, for TA26 HDD LED Cable CCBL-0100 Assembly, 14-pin, 200mm, for TA26 Control Board Cable, TYFP1/TYFP2, CCBL-0111 TYFP1 375mm/TYFP2 315mm Chassis Intrusion CCBL-0144 Cable L=800mm USB cable, MB to CCBL-0750 backplane, 300mm, for TA26...

  • Page 80: Technical Support

    (which can have expensive consequences). If these options are not available for you then TYAN Com- puter Corporation can help.Besides designing innovative and quality products for over a decade, TYAN has continuously offered customers service beyond their expectations.
  • Page 81 RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed pre- paid. TYAN will pay to have the board shipped back to you. TYAN Transport TA26 B2932 User’s Manual v1.0 Document part No. D1867-100...
