  • Page 1 Tank TA26 B5397 Service Engineer’s Manual...
  • Page 3 TYAN retains the right to make changes to product descriptions and/or specifications at any time, without notice. In no event will TYAN be held liable for any direct or indirect, incidental or consequential damage, loss of use, loss of data or other malady resulting from errors or inaccuracies of information contained in this document.
  • Page 4 Federal Communications Commission (FCC) Notice for the USA Compliance Information State- ment (Declaration of Conformity Procedure) DoC FCC Part 15: This device complies with part 15 of the FCC Rules Operation is subject to the following conditions: 1) This device may not cause harmful interference, and 2) This device must accept any interference received including inter- ference that may cause undesired operation.
  • Page 5 About this Manual This manual provides you with instructions on installing your Tank TA26 B5397. This manual is intended for experienced users and integrators with hardware knowledge of personal computers. This manual consists of the following parts: Chapter 1: Provides an Introduction to the TA26 B5397 bare- bone, packing list, describes the external compo- nents, gives a table of key components, and provides block diagrams of the system.
  • Page 6 SAFETY INFORMATION Before installing and using the TA26 B5397, take note of the follow- ing precautions: – Read all instructions carefully. – Do not place the unit on an unstable surface, cart, or stand. – Do not block the slots and opening on the unit, which are pro- vided for ventilation.

  • Page 7: Table Of Contents

    Chapter 1: Overview 1.1 About the TYAN Tank TA26 B5397 ..... . . 1 1.2 Product Models ........1 1.3 Features .
  • Page 8 3.4.2 Removing the Motherboard ......41 3.4.3 Removing the CPU Heatsink Mounting Plates ..42 3.5 Replacing the Slim DVD-ROM .

  • Page 9: Chapter 1: Overview

    IT environment but also offers a smooth path for future application usage.B5397 TYAN is also proud to deliver the Tank TA26 B5397 in SAS flavor while supporting up to eight (8) hot-swap hard drives and one (1) slim DVD-ROM drive. The Tank TA26 B5397 uses TYAN’s latest tooling-made chassis featuring a robust...

  • Page 10: Features

    • One (1) PCI-E x8 slot (w/ x4 signals) Motherboard • Two (2) PCI-X 133/100MHz slots • TYAN Tempest i5400PW S5397 • One (1) PCI 32/33MHz slot • SSI/ Extended ATX (12” x 13”) • Supports total six (6) low-profile...
  • Page 11 • Automatic fan speed control • Chassis intrusion alert • Supports TYAN Server Management (TSM) • Optional TYAN SMDC M3295- 2/M3296, IPMI v2.0 compliant remote server management kit (Note: SMDC support will be available from S5397 R03 (PCB Rev. MOA) and beyond version.

  • Page 12: Unpacking

    1.4.1 Box Contents Component Description Industry standard 2U chassis, (8) hot-swap HDD bays TYAN Tempest i5400PW S5397 motherboard (pre-installed) Slim DVD-ROM drive (pre-installed) LED and USB control board (pre-installed) EPS 12V, 2U, 700W PSU with PFC (pre-installed) (A)

  • Page 13: Accessories

    If any items are missing or appear damaged, contact your retailer or browse to TYAN’s Web site for service: http://www.tyan.com. The Web site also provides information on other TYAN prod- ucts, plus FAQs, compatibility lists, BIOS settings, and more. 1 x TYAN Driver CD...
  • Page 14 FDD Rails Screw Pack FDD Power Cable Sliding Rail TYAN Logo Chapter 1: Overview...

  • Page 15: About The Product

    About the Product The following views show you the product. 1.5.1 System Front View Reset switch ID switch Power LED Power switch Warning LED HDD activity LED USB ports LAN LEDs ID LED HDD Tray DVD-ROM drive Power LEDs Hard Drive Bay x 8 HDD Tray Activity LEDs 1.5.2 System Rear View...

  • Page 16: Led Definitions

    1.5.3 LED Definitions Front Panel Color State Description Power Green Power ON Power OFF HDD Activity Amber Blinking HDD/DVD-ROM access activity No disk activity LAN1/LAN2/Linkage Green LAN linked Green Blinking LAN accessing No LAN linked Fail System fails Abnormal power off Normal Hot Swappable HDD Green...

  • Page 17: Motherboard Layout

    1.5.4 Motherboard Layout Chapter 1: Overview...

  • Page 18: Jumpers & Connectors

    TYAN Fan Speed Header for Barebone TYAN LAN LED Header for Barebone TYAN LCM Header for Barebone USB Front Panel Header Audio Jack Header Aux. Power Header for TYAN Riser Card (M2061) Clear CMOS Jumper (Close 1-2) Default (Close 2-3) Clear CMOS...

  • Page 19: System Block Diagram

    1.5.6 System Block Diagram Chapter 1: Overview...

  • Page 20: Internal View

    1.5.7 Internal View FAN2 FAN1 FAN3 1. Memory Slots 8. DVD-ROM Cable 2. Power Connector 9. System Fans (Right to Left: FAN1, FAN2, FAN3) 3. Power Supply 10. Low Profile PCI-E Slots 4. Fan Duct 11. SO-DIMM TARO Card 5. SAS / SATA Backplane Socket 6.

  • Page 21: Chapter 2: Setting Up

    Chapter 2: Setting Up 2.0.1 Before You Begin This chapter explains how to install the CPU, CPU heatsink, memory modules, hard drives, and floppy drive. Instructions on inserting a PCI-E card are also given. Take note of the precautions mentioned in this section when installing your system.

  • Page 22: Precautions

    2.0.4 Precautions Components and electronic circuit boards can be damaged by discharges of static electricity. Working on a system that is connected to a power supply can be extremely dangerous. Follow the guidelines below to avoid damage to the Tank TA26 B5397 or injury to yourself. •...

  • Page 23: Installing Motherboard Components

    Installing Motherboard Components This section describes how to install components on to the motherboard, including CPU, memory modules and PCI-E card. 2.1.1 Removing the Chassis Cover Follow these instructions to remove the Tank TA26 B5397 chassis cover. 1. Turn the screw on the back side. Then slide the chassis cover in the direction of arrow.
  • Page 24 3. Unscrew the fan duct. Chapter 2: Setting Up...

  • Page 25: Installing The Cpu

    2.1.2 Installing the CPU Follow these instructions to install the CPU. 1. Remove the cover on the CPU socket. 2. Lift up the CPU lever to unlock the socket. Chapter 2: Setting Up...
  • Page 26 3. Open the socket in the direction as illustrated. 4. Place the CPU in the CPU socket, ensuring that pin 1 is located as shown below. 5. Close the cover and press the CPU socket lever down to secure the CPU. Chapter 2: Setting Up...
  • Page 27 6. Place theheatsink on top of the CPU and secure with four screws as shown below. Chapter 2: Setting Up...

  • Page 28: Installing The Memory

    2.1.3 Installing the Memory Follow these instructions to install the memory modules on the motherboard. 1. Locate the memory slots on the motherboard. 2. Press the memory slot locking levers in the direction of the arrows as shown below. 3. Insert the memory module into the slot as shown below. Chapter 2: Setting Up...
  • Page 29 4. When inserted properly, the memory slot locking levers lock automaticaly onto the indentations at the ends of the module. 5. Repeat these steps when installing a second memory module. Chapter 2: Setting Up...
  • Page 30 The following chart outlines the suggested rules for populating memory. Chapter 2: Setting Up...

  • Page 31: Installing Low Profile Pci-E Cards

    2.1.4 Installing Low Profile PCI-E Cards There are two PCI-E card slots in your TA26 B5397 system. Follow these instructions for PCI-E card installation. 1. Locate the PCI-E card slots on the motherboard. See “System Internal View” on page 14 for the PCI-E slot locations.

  • Page 32: Installing Hard Drives

    2.1.5 Installing Hard Drives The TA26 B5397 supports up to eight serial SAS/SATA hard drives. Follow these instructions to install a hard drive. 1. Press the locking lever latch in the direction shown by the arrow below. The latch will pop open. 2.
  • Page 33 4. Remove the base. 5. Place a hard drive into the drive tray. 6. Screw the hard drive in place using 4 HDD screws. 7. Reinsert the tray into the bay and press the locking lever to secure. Chapter 2: Setting Up...

  • Page 34: Installing A Floppy Drive

    2.1.6 Installing a Floppy Drive This section describes how to install a floppy disk drive in the TA26 B5397 if required. Follow these instructions to install a floppy disk drive in the TA26 B5397. 1. Remove the top, left hand drive tray from the TA26 B5397 as shown.
  • Page 35 Note: The FDD rails each have a flat side which should be against the body of the floppy drive when installed. There is also a spring catch mechanism on the right hand rail (when looking at the floppy disk drive from the front). 3.
  • Page 36 5. Connect the other end of the power cable to the connec- tor (J37) on the backplane. 6. Connect the other end of the supplied FDD cable to the FDD slot on the motherboard. Note: To release the floppy disk drive from the drive bay, you will need to press the release catch inside the chassis.

  • Page 37: Rack Mounting

    Rack Mounting After installing the necessary components, the Tank TA26 B5397 can be mounted in a rack using the supplied rack mounting kit. Rack mounting kit Sliding Rails x 2 Mounting Ears x 2 Screws Kit x 1 Mounting Brackets x 4 (pre-installed) 2.2.1 Installing the Server in a Rack Follow these instructions to mount the TA26 B5397 into an industry standard 19"...
  • Page 38 Attaching the Inner Rails to the Unit 7. Screw the handles to each side of TA26 B5397 as shown using two (2) M4L6, S10C screws (A) from the supplied screws kit. 8. Attach the inner rails both sides of the unit using nine (9) M4-L5 screws (C) on each side.
  • Page 39 Installing Outer Rails to the Rack 1. Adjust the outer rail to match the length of the unit. 2. Secure the outer rail to the rack using 2 brackets and M6 screws (B) for each side. Secure the mounting brackets from outside, not inside, of the rack.
  • Page 40 Rackmounting the Server 1. Draw out the middle rail to the latch position. 2. Lift the unit and then insert the inner slide rails into the middle rails. 3. Push the unit in and press the latch key. Chapter 2: Setting Up...
  • Page 41 4. Push the whole system into the rack. 5. Secure the mounting handles of the unit to the rack. Note: To avoid injury, it is strongly recommended that two people lift the TA26 B5397 into the place while a third person screws it to the rack.
  • Page 42 NOTE Chapter 2: Setting Up...

  • Page 43: Chapter 3: Replacing Pre-Installed Components

    Chapter 3: Replacing Pre-Installed Components Introduction This chapter explains how to replace pre installed compo- nents including the motherboard, LED control board, USB adapter board, HDD, and DVD-ROM drive, etc. Take note of the precautions in this section when installing your system.

  • Page 44: Precautions

    3.1.3 Precautions Components and electronic circuit boards can be damaged by static electricity. Working on a system that is connected to a power supply can be extremely dangerous. Follow the guidelines below to avoid damage to the Tank TA26 B5397 or injury to yourself.

  • Page 45: Disassembly Flowchart

    Disassembly Flowchart The following flowchart outlines the disassembly procedure. Rear Components DIMMs Chassis top cover CPU/heatsink assembly Mainboard PCI-E card Power supply Mainboard Front Components Chassis top cover PCBs DVD-ROM Control Board Backplane Note: The Tank TA26 B5397 should be always powered off before disassembly.

  • Page 46: Removing The Cover

    Removing the Cover Before replacing any parts you must remove the chassis cover. Follow these instructions to remove the cover of the Tank TA26 B5397 chassis cover. 1. Turn the screw on the back side. Then slide the chassis cover in the direction of arrow. 2.
  • Page 47 3. Unscrew the fan duct. Chapter 3: Replacing Pre-Installed Components...

  • Page 48: Replacing Motherboard Components

    Replacing Motherboard Components Follow these instructions to replace motherboard compo- nents, including the motherboard. 3.4.1 Disconnecting All Motherboard Cables Before replacing the motherboard or certain components, remove cables connected to the motherboard. Follow these instructions to remove all motherboard cabling. 1.

  • Page 49: Removing The Motherboard

    3.4.2 Removing the Motherboard After removing all of the aforementioned cables, follow these instructions to remove the motherboard from the chassis. 1. Remove ten mainboard screws and one fan duct screw securing the motherboard to the chassis. 2. Remove the mainboard from the chassis. Chapter 3: Replacing Pre-Installed Components...

  • Page 50: Removing The Cpu Heatsink Mounting Plates

    3.4.3 Removing the CPU Heatsink Mounting Plates Follow these instructions to remove the CPU Heasink mount- ing plates. 1. Remove the eight CPU Heatsink mounting plate stand- offs. They are the stand-offs to which you mount the CPU heatsink. 2. Take out the black mylar from the chassis. 3.

  • Page 51: Replacing The Slim Dvd-Rom

    Replacing the Slim DVD-ROM Follow these instructions to replace the DVD-ROM. 1. Remove the FFC cable from the rear of the DVD-ROM drive. 2. Press the tab in the direction shown to release the DVD- ROM drive. 3. Push the DVD-ROM drive through the front of the TA26 B5397.
  • Page 52 4. Remove the two screws that secure DVD-ROM drive to the backplane. 5. Replace the DVD-ROM drive. 6. Secure the DVD-ROM to the backplane using two screws. Then replace the unit into the drive bay and con- nect the DVD-ROM FFC cable. Chapter 3: Replacing Pre-Installed Components...

  • Page 53: Replacing The Led Control Board

    Replacing the LED Control Board Follow these instructions to replace the LED control board. 1. Remove the screw securing the LED control board unit to the chassis. 2. Remove the connector cables from the backplane. 3. Slide back the LED control board bracket and lift free of the chassis.
  • Page 54 4. Remove the LED control board and USB cables from the LED control board and USB adapter board. 5. Remove the five screws securing the LED control board and USB adapter board to the bracket. 6. Release the LED control board and USB adapter board from bracket.

  • Page 55: Led Control Board Features

    3.6.1 LED Control Board Features S3 power switch SYSTEM HEADER S2 ID switch S1 reset switch D6 power LED D5 HDD LED D4 W/L LED D3 ID LED D2 LAN2 LED D1 LAN1 LED 3.6.2 LED Control Board Connector Pin Definitions JB1 2x12 Pin Output Connector LAN1 GR-LED + LAN1-LED -...

  • Page 56: Replacing The Backplane

    Replacing the Backplane Follow these instructions to replace the backplane in your TA26 B5397 system. 1. Remove all of cables connected to the backplane, includ- ing fan cables, DVD-ROM cables, LED control board cable, fan control cable, TYFP cable, USB cables, front panel LED cables, power cables, and SAS/SATA cables.
  • Page 57 2. Remove the ten screws to release the backplane. 3. Turn the locking keys at the base of the backplane as shown. 4. Pull out the backplane. 5. Place a new backplane in position and secure in place with the ten screws and locking keys released in step 2 and 3.

  • Page 58: M1220 Sas/Sata Backplane Features

    3.7.1 M1220 SAS/SATA Backplane Features Front View J35 2x7pin J13 29pin SAS J14 29pin SAS J15 29pin SAS J34 2x5pin LED J11 29pin SAS J12 29pin SAS J7 40pin cd-rom/B J33 2x12pin LED/B J5 2x5pin USB J36 2x7pin J8 29pin SAS J9 29pin SAS J10 29pin SAS Chapter 3: Replacing Pre-Installed Components...

  • Page 59: Rear View

    Rear View J1,J2,J3 big 4pin FAN1 4pin J25,J27,J29,J31 7pin secondary J6 TO J24,J26,J28,J30 CD-ROM 7pin primary FAN2 4pin J38 2x7pin tach and PWM J37 small 4pin FAN3 4pin J17,J19,J21,J23 J32 LED/B 7pin secondary J16,J18,J20,J22 7pin primary J4 USB OUT Chapter 3: Replacing Pre-Installed Components...

  • Page 60: M1220 Sas/Sata Backplane Connector Pin Definitions

    3.7.2 M1220 SAS/SATA Backplane Connector Pin Definitions J32, J33 2x12pin LED board connector LAN1 LED + (link/active) LAN1 LED - (link/active) Reserved Reserved LAN2 LED + (link/active) LAN2 LED - (link/active) Reserved Reserved Reserved Reserved ID-LED + ID-LED - W-LED + W-LED - M/B HDD LED + M/B HDD LED -...
  • Page 61 DIOR IORDY CSEL DMACK INTRQ IOCS16 PDIAG CS1FX CS3FX DASP Fan Signal Related Connector Pin Definitions Note: The FAN signal naming is based on HW circuit design only. It might be different from the system fan name. FAN1, FAN2, FAN3: 4-pin Fan connector VDD +12V TACH J1, J2 and J3 power big 4-pin connector...
  • Page 62 J4, J5 USB 2x5pin connector USB1 power + USB2 power + USB1 DATA - USB2 DATA - USB1 DATA + USB2 DATA + USB1 GND USB2 GND Key pin None J37 power small 4-pin connector +12V J36 HDD LED pin out PLED1 ALED1 ALED1 +...
  • Page 63 J35 HDD LED pin out PLED6 + ALED6 - ALED6 + PLED7 + ALED7 - ALED7 + PLED8 + ALED8 - ALED8 + None J38 2x7pin FAN tach and PWM pin out FAN1 tach Reserved FAN2 tach Reserved FAN3 tach Reserved Reserved Reserved...

  • Page 64: Replacing The System Fan

    Replacing the System Fan Follow these instructions to replace the cooling fans in your TA26 B5397 system. 1. Locate the fan connector on the backplane and unplug the fan cable as shown below. 2. Take the fan away from the chassis. 3.

  • Page 65: Replacing The Power Supply

    Replacing the Power Supply 3.9.1 Standatd Power Supply Follow these instructions to replace the power supply in your TA26-B5397 system. 1. Remove the chassis cover. See “Removing the Cover” on page 38 for more details. 2. Detach the power cables from the motherboard and backplane.
  • Page 66 4. Remove the two screws attaching the power supply to the chassis interior and lift out the unit. 5. Lift the power supply free from the chassis. 6. Replace a new power supply into the chassis following the above steps in reverse. Chapter 3: Replacing Pre-Installed Components...

  • Page 67: Optional 1+1 Redundant Power Supply

    3.9.2 Optional 1+1 Redundant Power Supply If the optional 1+1 redundant power supply is fitted, either of the two units can be hot swapped. Follow these instructions to replace a single power unit with a redundant power supply unit. Note: Before proceeding, remove the new redundant power supply from its packaging.
  • Page 68 2. Lift the power supply free from the chassis. 3. Lift the bracket free from the chassis. 4. Screw the bracket to the rear of the redundant power supply cage. Chapter 3: Replacing Pre-Installed Components...
  • Page 69 5. Insert the redundant power supply cage into the chassis. 6. Screw the cage to the chassis exterior. 7. Screw the cage to the chassis interior. Chapter 3: Replacing Pre-Installed Components...
  • Page 70 8. Insert the new power supply unit and secure by turning the locking screw. Chapter 3: Replacing Pre-Installed Components...
  • Page 71 9. Reattach all power supply connector cables to the moth- erboard and backplane. Chapter 3: Replacing Pre-Installed Components...
  • Page 72 NOTE Chapter 3: Replacing Pre-Installed Components...

  • Page 73: Appendix I: Bios Differences

    Appendix I: BIOS Differences The BIOS of B5397 is similar to the BIOS of S5397. There is only one menu different. See the following for the differences in BIOS between B5397 and S5397. For a complete review of S5397 BIOS, refer to the motherboard manual. Table of Differences S5397 Mainboard B5397 Barebone...

  • Page 74: Appendix Ii: Cable Connection Tables

    Appendix II: Cable Connection Tables SAS/SATA Cable Table 1: TA26 B5397 Model M1220 SAS/SATA Connects to Motherboard Backplane mini SAS0~3 mini SAS4~7 FAN Cable Table 2: System Fan to Backplane M1220 SAS/SATA System Fan Connects to Backplane Fan 1 FAN1 4-pin connector Fan 2 FAN2 4-pin connector Fan 3...
  • Page 75 Power Supply Cable Table 3: Power Supply to Motherboard Power Supply Connects to Motherboard P24 24-pin power PW2 24-pin connector cable PA 8-pin power cable PW4 8-pin connector PB 4-pin power cable PW1 4-pin connector PC 4-pin power cable PW3 4-pin connector Table 4: Power Supply to Backplane M1220 SAS/SATA Power Supply...
  • Page 76 Table 6: Backplane to LED Control Board M1220 SAS/SATA Connects to LED Control Board Backplane (Rear side) J33 2x12pin LED/B JB1 SYSTEM HEADER J5 2x5pin USB Table 7: System Internal LED Cables to Backplane M1220 SAS/SATA Connects to TA26 B5397 System Backplane (Front side) J34 2x5pin LED System Internal...

  • Page 77: Appendix Iii: Installing The So-Dimm Card

    Appendix III: Installing the SO-DIMM Card The following provides you with the information on installing the M3295-2/M3296 SMDC card into your TA26 B5397 sys- tem. 1. Locate the SO-DIMM TARO card socket on the mother- board. See “System Internal View” on page 14 for the SO-DIMM socket location.
  • Page 78 4. When inserted properly, the SO-DIMM socket locking levers lock automaticaly onto the indentations at the ends of the TARO card. Appendix...
  • Page 79 Appendix IV: FRU Parts List TA26-B5397 FRU Parts Item Model Number Part Number Picture Quantity Description TYAN S5397WAG2NRF Motherboard S5383WG4NR Motherboard Chassis Unit CCHA-0090 432731500003 TA26 2U Chassis Chassis Top CCCV-0020 340731500032 Top Cover for TA26 Chassis Cover Drive Tray...
  • Page 80 TA26-B5397 FRU Parts Item Model Number Part Number Picture Quantity Description CHSK-0330 343772500003 LGA771 CPU Heatsink Heat Sink & CHSB-0080 342748500001 CEK Spring for LGA771 Cooler CHSB-0120 340772500001 CPU Backplane Kit CPCA-0270 Front Control Board SAS/SATA 8-port Backplane, Dual M1220 Host CPCA-0080 Front Control Board...
  • Page 81 TA26-B5397 FRU Parts Item Model Number Part Number Picture Quantity Description CEAR-0100 340731500062 Mounting Ear Left Rack Mounting CEAR-0110 340731500063 Mounting Ear Right Part CRAL-0040 340755700002 Slide Rail Kit CCBL-0310 332810000280 A/C Power Cord, 2440mm, US Type A/C Power Cord, 1800mm, Germany CCBL-0300 332810000281 Type...
  • Page 82 TA26-B5397 FRU Parts Item Model Number Part Number Picture Quantity Description CCBL-0111 422763200001 Control Board Cable USB Internal Cable, MB to CCBL-0358 422763200005 Backplane, 300mm USB Cable, Backplane to LED CCBL-0359 422763200006 Board, 130mm CCBL-0120 422732600018 LED Board Cable, 253mm CCBL-0433 422740900009 DVD ROM Cable, 395mm...

  • Page 83: Technical Support

    (which can have expensive consequences). If these options are not available for you then TYAN Com- puter Corporation can help.Besides designing innovative and quality products for over a decade, TYAN has continuously offered customers service beyond their expectations.
  • Page 84 RMA number should be prominently displayed on the outside of the shipping carton and the package should be mailed pre- paid. TYAN will pay to have the board shipped back to you. TYAN Tank TA26 B5397 User’s Manual v1.0 Document part No. D1941-100...
