Release 4.1 Enhancements - Lucent Technologies MERLIN LEGEND Release 6.0 Pocket Reference

DEFINITY ECS Release 6
System Description Pocket Reference 555-230-211

Release 4.1 Enhancements

Single-Line Telephone Enhancements
The following enhancements are added to the single-line
telephones:
Disable Transfer. Through centralized programming, the
system manager can disable the ability to transfer calls by
removing all but one SA or ICOM button from the telephone.
No Transfer Return. When a handset bounces in its cradle, the
MERLIN LEGEND system interprets this as a switchhook flash
and attempts to transfer a call. This causes unintended ringing
at the user's phone. In Release 4.0, a flash followed by an on-
hook state when a dial tone is present causes the call to be
disconnected.
Forward Disconnect. All ports on 012 and 016 modules now
send forward disconnect to all devices connected to them when
forward disconnect is received from the CO. This is a non-
administrable operation.
System Security
Greater system security is achieved by requiring a 7-digit
maintenance password when using SPM to perform remote
administration via the Remote Access Feature.
Release 4.1 Enhancements
Release 4.1 includes all Release 4.0 functionality plus the
enhancements listed below. There are no hardware changes in
Release 4.1.
Coverage Timers Programmed for Individual Extensions
Beginning with Release 4.1, coverage timers, which control the
duration of the delay before calls are sent to each level of
coverage, are changed as follows:
The Group Coverage Ring Delay (1-9 rings) is programmed
—
on individual extensions and replaces the Coverage Delay
Interval programmed system-wide in previous releases.
The Primary Cover Ring Delay (1-6 rings) and Secondary
—
Cover Ring Delay (1-6 rings) programmed on individual
extensions replace the Delay Ring Interval programmed
system-wide in previous releases.
These enhancements allow the system manager to customize
coverage call delivery to match individual extensions' call-
handling requirements.
Issue 2
January 1998
Page 12
