Avaya Solution & Interoperability Test Lab
Connecting Avaya 4600 Series IP Telephones and Avaya
Wireless LAN Access Points with the 3Com SuperStack 3
Switch 4400-PWR (Inline Power Ethernet Switch) - Issue 1.0
These Application Notes describe how to connect and configure Avaya 4600 Series IP
Telephones and Avaya wireless LAN access points with the 3Com SuperStack 3 Switch 4400-
PWR (inline power Ethernet switch). The various Avaya powering arrangements and the
commands for displaying and controlling the powering status of the switch ports are described
SZ; Reviewed:
WCH 3/19/2004
Abstract
Solution & Interoperability Test Lab Application Notes
©2004 Avaya Inc. All Rights Reserved.
.
1 of 14
3com-PoE-Config.doc

Advertisement

loading

Related Manuals for Avaya 4600 Series

Summary of Contents for Avaya 4600 Series

  • Page 1 Abstract These Application Notes describe how to connect and configure Avaya 4600 Series IP Telephones and Avaya wireless LAN access points with the 3Com SuperStack 3 Switch 4400- PWR (inline power Ethernet switch). The various Avaya powering arrangements and the commands for displaying and controlling the powering status of the switch ports are described SZ;...
  • Page 2 • AP 3 and AP 5 Access Points The Gen-1 Avaya 4612 and 4624 IP Telephones require the Avaya 30A Switch Base if power over Ethernet is required. Figure 2 shows the connections for the 30A switch base. The 4612 and 4624 telephones can be identified as Gen-1 or Gen-2 by inspecting the model number.
  • Page 3 Avaya 4630SW Avaya Gen-2 Telephones IP Screenphone 4606, 4612, 4624 IP Telephones Figure 1: Avaya 4600 Series IP Telephone and Wireless LAN Access Point Configurations with the 3Com SuperStack 3 Switch 4400-PWR To line jack of 4612/4624 IP Telephone To PC...

  • Page 4: Equipment And Software Validated

    Software Avaya 4602 IP Telephone Avaya 4602SW IP Telephone Avaya 4610SW IP Telephone Avaya 4620 IP Telephone with EU24 Button Expansion Module Avaya 4620SW IP Telephone with EU24 Button Expansion Module Avaya 4630SW IP Screenphone Avaya 4606 IP Telephone (Gen-2) 1.73...
  • Page 5 To access power configuration information, expand the folder Physical interface Power in the navigation panel as shown in Figure 4. SZ; Reviewed: Solution & Interoperability Test Lab Application Notes 5 of 14 WCH 3/19/2004 ©2004 Avaya Inc. All Rights Reserved. 3com-PoE-Config.doc...
  • Page 6 • Active — The port is currently delivering power. • Inactive — No device is currently requesting power from the port. SZ; Reviewed: Solution & Interoperability Test Lab Application Notes 6 of 14 WCH 3/19/2004 ©2004 Avaya Inc. All Rights Reserved. 3com-PoE-Config.doc...
  • Page 7 The following example can be used to verify that the switch can auto-detect the PDs and supply power to them. • Plug the Avaya 4620, 4612 and 4602SW IP phones into ports 1-3. • Click Refresh as shown in Figure 5. Figure 6 shows that all three IP telephones are automatically powered up, and the power status is changed to Active.
  • Page 8 • Select Guaranteed and enter the maximum power required by the device type in the text box that appears below. • Click Apply. Repeat for each type of device that needs guaranteed power. SZ; Reviewed: Solution & Interoperability Test Lab Application Notes 8 of 14 WCH 3/19/2004 ©2004 Avaya Inc. All Rights Reserved. 3com-PoE-Config.doc...
  • Page 9 Default 15.4 optional optional optional 15.4 Table 2: IEEE 802.3af-2003 Power Classes Figure 7: Port Inline Power Profile Configuration SZ; Reviewed: Solution & Interoperability Test Lab Application Notes 9 of 14 WCH 3/19/2004 ©2004 Avaya Inc. All Rights Reserved. 3com-PoE-Config.doc...
  • Page 10 For example, Figure 8 shows the power status for ports 1-3 after disabling inline power. Figure 8: Disable Inline Power Configuration Note the power state for ports 1-3 is changed to Disabled. SZ; Reviewed: Solution & Interoperability Test Lab Application Notes 10 of 14 WCH 3/19/2004 ©2004 Avaya Inc. All Rights Reserved. 3com-PoE-Config.doc...

  • Page 11: Verification Steps

    • Select Physical Interface -> Power -> Detail in the navigation panel. • From the Power Detail for Port drop-down box, select port 1. SZ; Reviewed: Solution & Interoperability Test Lab Application Notes 11 of 14 WCH 3/19/2004 ©2004 Avaya Inc. All Rights Reserved. 3com-PoE-Config.doc...
  • Page 12 • Select Physical Interface -> Power -> Detail in the navigation panel. • From the Power Detail for Port drop-down box, select port 1. SZ; Reviewed: Solution & Interoperability Test Lab Application Notes 12 of 14 WCH 3/19/2004 ©2004 Avaya Inc. All Rights Reserved. 3com-PoE-Config.doc...
  • Page 13 Figure 11. Figure 11: Port 1 Power is enabled 5. Conclusion The following Avaya IP telephones and wireless LAN access points were tested with the 3Com SuperStack 3 Switch 4400-PWR inline power switch, and were successfully powered: • IP telephones: •...
  • Page 14 2004 Avaya Inc. All Rights Reserved. © Avaya and the Avaya Logo are trademarks of Avaya Inc. All trademarks identified by ® and ™ are registered trademarks or trademarks, respectively, of Avaya Inc. All other trademarks are the property of their respective owners. The information provided in these Application Notes is subject to change without notice.
