- Page 1 Gigabit Ethernet Adapter For 4600 & 5600 Series IP Phones 16-601543 Issue 1 September 2006 For all IP Telephone documentation, go to Http://www.avaya.com/support...
-
Page 2: Important User Safety Instructions
The most careful attention has been devoted to quality standards in the manufacture of your new Gigabit Ethernet Adapter. Safety is a major factor in the design of every Avaya Product. But, safety is YOUR responsibility too. Please read carefully the helpful tips listed below. These suggestions will enable you to take full advantage of this product. -
Page 3: Warranty
However, information is subject to change. Warranty Avaya Inc. provides a limited warranty on this product. Refer to your sales agreement to establish the terms of the limited warranty. In addition, Avaya's standard warranty language as well as information regarding support for this product, while under warranty, is available through the following Web site: http://www.avaya.com/support... -
Page 4: European Union Declarations Of Conformity
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio / TV technician for help. Declaration of Conformity (DoC) statement is available on the Avaya external web site: http://support.avaya.com/elmodocs2/DoC European Union Declarations of Conformity Avaya Inc. -
Page 5: Sources Of Information
Other IP phones may also work but are not supported. Gigabit Ethernet Adapter IEEE 802.3 standard. Note the Avaya-Cajun P580 Gigabit card does not support the Carrier Extend Signal and should not be used Gigabit Ethernet Adapter in conjunction with this Note: Failure to use and install as directed could result in injury. -
Page 6: Maintenance
1151C1/C2 Power Supply 6 Feet Gigabit Adapter Power Cable(4600&5600 IP Phones only) When purchasing an 1151C1/C2, an additional A/C power cord is required. Avaya has several available to meet regional plug configurations. Consult your Authorized Avaya deal for details. Note: Class 0 devices may also require use of the local power supply, depending on their power rating. - Page 7 What will we do: If your Avaya product is defective in material and workmanship and is returned within one year of date it was purchased, we will repair it or, at our option, replace it at no charge to you.
- Page 8 Figure 2 Powering Option for 4602SW, 5602SW, 4602SW+, 5602SW+, 4610SW, 5610SW IP phones Note: These Telephone models are powered over network cabling from a central location using an IEEE 802.3af compliant switch or power supply as 1151C1/C2 Power Supply. The use of PoE and local power simultaneously is not supported and will prevent the adapter from working properly, nor is it intended to serve as a fail-over option.
- Page 9 Figure 3 Powering Option for 4620, 4620SW, 5620SW, 4621SW, 5621SW, 4622SW, 4625SW IP Telephones Note: These Telephone models are powered over network cabling from a central location using an IEEE 802.3af compliant switch or power supply as 1151C1/C2 Power Supply. The use of PoE and local power simultaneously is not supported and will prevent the adapter from working properly, nor is it intended to serve as a fail-over option.
- Page 10 Figure 4 Powering Option for 4630SW IP Telephone with PoE Switch Note: This Telephone model is powered over network cabling from a central location using an IEEE 802.3af compliant switch or power supply as 1151C1/C2 Power Supply. The use of PoE and local power simultaneously is not supported and will prevent the adapter from working properly, nor is it intended to serve as a fail-over option.
- Page 11 Troubleshooting Q&A Gigabit Ethernet Adapter If your does not function properly, before you send it to the dealer requesting service, please follow the troubleshooting guide first, it could help you solve the problem. Q: The Power Indicator LED is not illuminated. Gigabit Ethernet Adapter A1: This means your is not correctly powered.
