Implementing Secure Shell on Cisco IOS XR Software

Configuring the SSH Client

Perform this task to configure an SSH client.
SUMMARY STEPS
1.
2.
3.
4.
DETAILED STEPS
Command or Action
Step 1
configure
Example:
RP/0/RP0/CPU0:router# configure
Step 2
ssh client knownhost device:/filename
Example:
RP/0/RP0/CPU0:router(config)# ssh client
knownhost slot0:/server_pubkey
Step 3
exit
Example:
RP/0/RP0/CPU0:router(config)# exit
Step 4
ssh [vrf vrf-name] {ipv4-address | ipv6-address
| hostname} [username user-id} [cipher aes
{128-cbc | 192-cbc |256-cbc}] source-interface
type instance]
Example:
RP/0/RP0/CPU0:router# ssh vrf green 10.10.10.10
username user1234 cipher aes 192-cbc
source-interface loopback 0
OL-20382-01
configure
ssh client knownhost device:/filename
exit
ssh [vrf vrf-name] {ipv4-address | ipv6-address | hostname} [username user-id] [cipher aes
{128-cbc | 192-cbc | 256-cbc}] [source-interface type instance]
Cisco IOS XR System Security Configuration Guide for the Cisco CRS-1 Router
Purpose
Enters global configuration mode.
(Optional) Enables the feature to authenticate and check the
server public key (pubkey) at the client end.
Note The complete path of the filename is required. The
colon (:) and slash mark (/) are also required.
Exits global configuration mode, and returns the router to
EXEC mode.
Enables an outbound SSH connection.
To run an SSHv2 server, you must have a VRF. This
•
may be the default or a specific VRF. VRF changes are
applicable only to the SSH v2 server.
The SSH client tries to make an SSHv2 connection to
•
the remote peer. If the remote peer supports only the
SSHv1 server, the peer internally spawns an
SSHv1 connection to the remote server.
The SSHv1 client supports only the 3DES encryption
•
algorithm option, which is still available by default for
those SSH clients only.
If the hostname argument is used and the host has both
•
IPv4 and IPv6 addresses, the IPv6 address is used.
How to Implement Secure Shell
SC-207
