Prerequisites to Implementing Secure Shell
The following prerequisites are required to implement Secure Shell:
•
•
•
•
•
•
Restrictions for Implementing Secure Shell
The following are some basic SSH restrictions and limitations of the SFTP feature:
•
•
•
Cisco IOS XR System Security Configuration Guide for the Cisco CRS-1 Router
SC-200
Prerequisites to Implementing Secure Shell, page SC-200
Restrictions for Implementing Secure Shell, page SC-200
Information About Implementing Secure Shell, page SC-201
How to Implement Secure Shell, page SC-204
Configuration Examples for Implementing Secure Shell, page SC-208
Additional References, page SC-209
You must be in a user group associated with a task group that includes the proper task IDs. The
command reference guides include the task IDs required for each command.
If you suspect user group assignment is preventing you from using a command, contact your AAA
administrator for assistance.
Download the required image on your router. The SSH server and SSH client require you to have a
a crypto package (data encryption standard [DES], 3DES and AES) from Cisco downloaded on your
router.
To run an SSHv2 server, you must have a VRF. This may be the default VRF or a specific VRF. VRF
changes are applicable only to the SSH v2 server.
Configure user authentication for local or remote access. You can configure authentication with or
without authentication, authorization, and accounting (AAA). For more information, see the
Authentication, Authorization, and Accounting Commands on Cisco IOS XR Software module in the
Cisco IOS XR System Security Command Reference publication and Configuring AAA Services on
Cisco IOS XR Software module in the Cisco IOS XR System Security Configuration Guide
publication.
AAA authentication and authorization must be configured correctly for Secure Shell File Transfer
Protocol (SFTP) to work.
A VRF is not accepted as inband if that VRF is already set as an out-of-band VRF. SSH v1 continues
to bind only to the default VRF.
In order for an outside client to connect to the router, the router needs to have an RSA (for SSHv1)
or DSA (for SSHv2) key pair configured. DSA and RSA keys are not required if you are initiating
an SSH client connection from the router to an outside routing device. The same is true for SFTP:
DSA and RSA keys are not required because SFTP operates only in client mode.
In order for SFTP to work properly, the remote SSH server must enable the SFTP server
functionality. For example, the SSHv2 server is configured to handle the SFTP subsystem with a line
such as /etc/ssh2/sshd2_config:
subsystem-sftp/usr/local/sbin/sftp-server
