Implementing Management Plane Protection on Cisco IOS XR Software
Command or Action
Step 6
interface {type instance | all}
Example:
RP/0/RP0/CPU0:router(config-mpp-outband)# interface
GigabitEthernet 0/6/0/2
RP/0/RP0/CPU0:router(config-mpp-outband-Gi0_6_0_2)#
Step 7
allow {protocol | all} [peer]
Example:
RP/0/RP0/CPU0:router(config-mpp-outband-Gi0_6_0_2)#
allow TFTP peer
RP/0/RP0/CPU0:router(config-tftp-peer)#
Step 8
address ipv6 {peer-ip-address | peer
ip-address/length}
Example:
RP/0/RP0/CPU0:router(config-tftp-peer)# address ipv6
33::33
OL-20382-01
How to Configure a Device for Management Plane Protection
Purpose
Configures a specific out-of-band interface, or all
out-of-band interfaces, as an out-of-band interface.
Use the interface command to enter management
plane protection out-of-band configuration mode.
Use the all keyword to configure all interfaces.
•
Configures an interface as an out-of-band interface
for a specified protocol or all protocols.
Use the protocol argument to allow
•
management protocols on the designated
management interface.
Use the all keyword to configure the interface to
•
allow all the management traffic that is
specified in the list of protocols.
(Optional) Use the peer keyword to configure
•
the peer address on the interface.
Configures the peer IPv6 address in which
management traffic is allowed on the interface.
• Use the peer-ip-address argument to configure
the peer IPv6 address in which management
traffic is allowed on the interface.
Use the peer ip-address/length argument to
•
configure the prefix of the peer IPv6 address.
Cisco IOS XR System Security Configuration Guide for the Cisco CRS-1 Router
– HTTP or HTTPS
SNMP (also versions)
–
Secure Shell (v1 and v2)
–
TFTP
–
Telnet
–
SC-189
