IDEAL INDUSTRIES INC.
TECHNICAL MANUAL
MODEL: 61-362
The Service Information provides the following information
• Precautions and safety information
• Specifications
• Performance test procedure
• Calibration and calibration adjustment procedure
• Basic maintenance (replacing the battery and fuses)
Form number: 61362
Rev 1. date: May 2001
Form number 61362
rev 1 May 2002
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for IDEAL INDUSTRIES 61-362
Summary of Contents for IDEAL INDUSTRIES 61-362
- Page 1 IDEAL INDUSTRIES INC. TECHNICAL MANUAL MODEL: 61-362 The Service Information provides the following information • Precautions and safety information • Specifications • Performance test procedure • Calibration and calibration adjustment procedure • Basic maintenance (replacing the battery and fuses) Form number: 61362 Rev 1.
- Page 2 TABLE OF CONTENTS Page Title Introduction Precautions and Safety Information Safety Information Specifications General Specification Voltage Specifications Current Specifications Resistance Specifications Diode / Continuity Specifications Performance Verification Table 1 Verification 61-362 Calibration Replacing the Battery Replacing Fuses Form number 61362 rev 1 May 2002...
- Page 3 Caution The 61-362 serials contain parts that can be damaged by static discharge. Follow the standard practices for handling static sensitive devices. For additional information about IDEAL INDUSTRIES and its products, and services, visit IDEAL INDUSTRIES web site at: www.idealindustries.com...
- Page 4 Page 2 General specifications Model 61-362 Characteristics Description Display 3 ½ Digit LCD display Display Count 3200 count, maximum reading 3199 32 segment analog bar graph Over range Indication “OL” displayed Sampling Rate 2 time/second Operating Environment: 0°C to 50°C (32°F to 122°F) 70%RH Relative Humidity 0.05X x (accuracy) per °F (32°F to 65°F, 85°F to 122°F Temperature Coefficient...
- Page 5 Page 3 PERFORMANCE VERIFICAITONS Perform the following analysis, if the meter conforms to the limits listed in Table 1 the meter is functioning correctly. If the meter does not conform to any of the listed limits the calibration procedure must be performed.
- Page 6 Using a calibrated meter ensure the battery measures a minimum of 7.5 V dc. If the battery measures under 7.5V DC, replace the battery. Calibration Procedure It is recommended that all IDEAL meters undergo the following calibration procedure on an annual basis. 61-362 Calibration Procedure.
- Page 7 Page 5 Replacing Fuse (refer to Figure 3) 1. Disconnect the test leads and turn the range switch to “OFF”. 2. Remove the three screws holding the bottom case cover 3 Us a digital multimeter in low resistance {ohms} mode to check the two fuses mA input, 0.5A / 250V fast acting fuse.
