Rear and Left-Side Components (Continued)
Item Component
4 USB connectors (2)
5 DC power connector
6 RJ-45 network jack
7 RJ-11 modem jack
8 Infrared port
9 PC Card eject button
10 PC Card slot
11 Secure Digital (SD) slot Supports SD Memory Cards and MultiMedia
12 Audio line-out jack
13 Microphone input jack
14 Speaker
Maintenance and Service Guide
Table 1-4
Connect USB 1.1- and 2.0-compliant devices
to the notebook using a standard USB cable.
The right connector also functions as a
self-powered USB connector and allows an
optional External MultiBay to be connected
to the notebook using the External
MultiBay-Powered USB cable.
Connects an AC adapter or an optional
Automobile power adapter/charger, aircraft
power adapter, or DC cable.
Connects a network cable.
Connects a modem cable.
Links another IrDA-compliant device for
wireless communication.
Ejects an optional PC Card from the
PC Card slot.
Supports optional Type I or Type II 32-bit
(CardBus) or 16-bit PC Cards. The PC Card
slot also supports an optional Smart Card
Reader.
Cards.
Connects optional powered stereo speakers,
headphones, headset, or television audio.
Connects an optional monaural microphone.
Produces system sound.
Product Description
Function
1–13
