HP ProLiant BL490c - G6 Server User Manual page 30

IMPORTANT:
bracket with the alignment holes in the heatsink.
To install a processor:
Update the system ROM.
1.
Locate and download the latest ROM version from the HP website (http://www.hp.com/support).
Follow the instructions on the website to update the system ROM.
Power down the server blade (on page 11).
2.
Remove the server blade (on page 12).
3.
Remove the access panel (on page 13).
4.
Remove the heatsink blank. Retain the heatsink blank for future use.
5.
Open the processor retaining latch and the processor socket retaining bracket.
6.
Remove the processor socket protective cover.
7.
When installing the heatsink, align the guide pins on the processor retention
Hardware options installation 30
