SE7221BK1-E Technical Product Specification
Feature
Language English
French
German
Italian
Spanish
9.5.2

Advanced menu

Feature
Processor Configuration
IDE Configuration
Floppy Configuration
Super IO Configuration
USB Configuration
PCI Configuration
Memory Configuration
9.5.2.1 Processor configuration sub-menu

Table 44. BIOS Setup, Processor configuration sub-menu options

Feature
Manufacturer Intel
Brand String N/A
Frequency N/A
FSB Speed N/A
Cache L1 N/A
Cache L2 N/A
Cache L3 N/A
Processor Retest Enabled
Disabled
Max CPUID Value Enabled
Limit
Disabled
Options
Use [ENTER], [Up Arrow], [Down
Arrow] to select language.

Table 43. BIOS Setup, Advanced Menu Options

Options Help Text
N/A Configure processors.
N/A Configure the IDE device(s).
N/A Configure the Floppy drive(s).
N/A Configure the Super I/O Chipset.
N/A Configure the USB support.
N/A Configure PCI devices.
N/A Configure memory devices.
Options
N/A
N/A
N/A
N/A
N/A
N/A
N/A
If enabled, all processors will be
activated and retested on the next
boot. This option will be
automatically reset to disabled on the
next boot.
This should be enabled in order to
boot legacy OSes that cannot
support processors with extended
CPUID functions.
Help Text
Help Text
Description
Select the current default language
used by BIOS.
Description
Selects submenu.
Selects submenu.
Selects submenu.
Selects submenu.
Selects submenu.
Selects submenu.
Selects submenu.
Description
Displays processor manufacturer
string
Displays processor brand ID string
Displays the calculated processor
speed
Displays the processor front-side bus
speed.
Displays cache L1 size.
Displays cache L2 size.
Displays cache L3 size. Visible only
if the processor contains an L3
cache.
Rearms the processor sensors.
Only displayed if the Intel®
Management Module is present.
43
