Self-Testing

Hyper Terminal for TCP/IP WinSock

After completing the wiring and parameter settings, it is advisable to
confirm that all settings are correct.
To use a single computer to test if NETRS2321E is performing
properly:
1. Initiate a Hyper Terminal from the Start Menu in Windows. This can
be done by clicking on the Start button, selecting All Programs, then
Accessories, Communications and finally Hyper Terminal.
2. Provide a terminal name and click on OK.
3. At the "Connect to" screen that follows, select the TCP/IP(Winsock)
option, and click OK. Enter the NETRS2321E IP Address in the Host
Address Field, and the Socket port number set for Serial Port 1 in
the Port number field (e.g. 4660). The Socket type of Serial Port 1
should be TCP Server:
15
