Destination setting:
• Destination IP Address: The server IP Address and socket port
• Destination socket port: The server socket port would be
• Connection: The connection can be selected in two modes, Auto or
• Serial I/O setting: Baud rate, parity, data bits, stop bits
• Serial I/O Interface: RS-232: TxD, RxD for data stream, no flow
• Packet mode of serial input: Packet mode could be in enabled/
would be connected in TCP client and
UDP client mode for a certain server IP
Address.
connected in TCP Client and UDP Client
mode for a certain serial port.
Manual.
Baud rate: 300 - 115200bps
Parity: None, Even, Odd
Data Bits: 7,8
Stop Bit: 1 or 2
control
RS-232 (RTS/CTS): TxD, RxD for data stream,
RTS/CTS for flow control
RS-232 (RTS/CTS, DTR/DSR): TxD, RxD for
data stream, RTS/CTS for flow control. DTR
for socket status, DSR for socket open/close
control
RS-485 (Half duplex): Half duplex RS-485
interface
RS-422 (Full duplex): Full duplex RS-422
interface
disabled mode. If packet mode is enabled,
the data input from UART will be deferred
until the input buffer is full, or NETRS2321E
9
