NOTE: Because the Device Management Utility uses broadcast UDP
packets, configuration is only allowed when the device's password is
left empty.

Web Console Configuration

In addition to basic IP Address and subnet mask, specific device
settings can be set using an Internet browser, such as Internet
Explorer or Netscape etc.
If the IP Address of the adapter is already known (default is
192.168.0.10), enter it into the browser address line to launch the
Login Page.
The Login Page
Once the Login Page has been launched (as shown on page 6), the
following will be displayed:
System time elapsed
The time elapsed since the adapter was connected to the LAN will be
displayed here.
Firmware version
The installed firmware will be identified here by date code.
Serial number
The adapter serial number consists of five digits and a unique MAC
address used by the network in hexadecimal format.
Password (Setup login)
This field allows you to enter the administration password for
authentication. By default, the password is left empty. If you have
changed the password to something other than the default, press and
hold the Reset button (located next to the RJ45 port) for five seconds.
The adapter will power cycle; once it has been re-detected on the
network, the password will have been reset to default. Please note that
if there are more than three consecutive incorrect password attempts,
the login function will be disabled for 15 minutes. During this period,
even if the correct password is supplied, the login will not proceed
6
