Removing and Replacing the Optical Drive (some models)

CAUTION:
computer.
NOTE: An optical drive is a CD-ROM, CD-R/RW, DVD-ROM, DVD+R/RW, or CD-RW/DVD Combo
drive.
To remove an optical drive:
1. Remove/disengage any security devices that prohibit opening the computer.
2. Remove all removable media, such as compact discs, from the computer.
3. Turn off the computer properly through the operating system, then turn off any external devices.
4. Disconnect the power cord from the power outlet and disconnect any external devices.
CAUTION:
long as the system is plugged into an active AC outlet. You must disconnect the power cord to
avoid damage to the internal components of the computer.
5. If the computer is on a stand, remove the computer from the stand.
6. Remove the computer cover.
7. Disconnect the power cable (1) and data cable (2) from the rear of the optical drive.
Figure 2-24
ENWW
All removable media should be taken out of a drive before removing the drive from the
Regardless of the power-on state, voltage is always present on the system board as
Disconnecting the Optical Drive Power and Data Cables
Installing and Removing Drives 29
